Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2 | 93500-06016-0G | SCREW, PAN (6X16) | 2 |
| 33750-MG9-771 | GARNISH, RR. TRUNK | ||
| 33753-MG9-771 | GARNISH | ||
| 33756-MG9-771 | STAY, RR. GARNISH TRUNK | ||
| 33804-MG9-771 | REFLECTOR ASSY., TRUNK | ||
| 33805-MG9-771 | REFLECTOR ASSY., TRUNK | ||
| 80112-443-850 | COLLAR, FENDER COVER | ||
| 81110-MG9-770ZB | TRUNK ASSY. (LOWER) *PB123PA* (PEARL SIREN BLUE-A) (AVAILABLE BY COMPONENTS) | ||
| 81111-MG9-770ZB | TRUNK ASSY. (LOWER) *PB123PA* (PEARL SIREN BLUE-A) | ||
| 81110-MG9-770ZE | TRUNK ASSY. (LOWER) *NH136MU* (SENIOR GRAY METALLIC) (AVAILABLE BY COMPONENTS) | ||
| 81111-MG9-770ZE | TRUNK ASSY. (LOWER) *NH136MU* (SENIOR GRAY METALLIC) | ||
| 811A1-ML8-670ZA | TRUNK SET (LOWER) *R114CU* (CANDY WINE BERRY RED-U) (AVAILABLE BY COMPONENTS) | ||
| 81110-MG9-680ZA | TRUNK ASSY. (LOWER) *R114CU* (CANDY WINE BERRY RED-U) (AVAILABLE BY COMPONENTS) | ||
| 81110-MG9-770ZA | TRUNK ASSY. (LOWER) *R114CU* (CANDY WINE BERRY RED-U) (AVAILABLE BY COMPONENTS) | ||
| 81111-MG9-770ZA | TRUNK ASSY. (LOWER) *R114CU* (CANDY WINE BERRY RED-U) | ||
| 81111-MG9-770ZM | TRUNK (LOWER) *R114CU* (CANDY WINE BERRY RED-U) | ||
| 81112-MG9-770ZB | COVER, TRUNK (LOWER) *PB123PA* (PEARL SIREN BLUE-A) | ||
| 81112-MG9-770ZE | COVER, TRUNK (LOWER) *NH136MU* (SENIOR GRAY METALLIC) | ||
| 81112-MG9-770ZA | COVER, TRUNK (LOWER) *R114CU* (CANDY WINE BERRY RED-U) | ||
| 81113-MG9-770 | BRACKET, TRUNK HINGE | ||
| 81114-MG9-770 | STIFFENER, R. HINGE | ||
| 81115-MG9-770 | STIFFENER, L. HINGE | ||
| 81116-MG9-770 | PLATE, HINGE STIFFENER | ||
| 81118-MG9-770 | RUBBER, RR. TRUNK CENTER | ||
| 81119-MG9-770 | RUBBER, RR. TRUNK | ||
| 81120-MG9-770ZA | TRUNK ASSY. (UPPER) *R114CU* (CANDY WINE BERRY RED-U) | ||
| 81120-MG9-770ZB | TRUNK ASSY. (UPPER) *PB123PA* (PEARL SIREN BLUE-A) | ||
| 81120-MG9-770ZC | TRUNK ASSY. (UPPER) *NH136MU* (SENIOR GRAY METALLIC) | ||
| 81121-MG9-770ZA | TRUNK (UPPER) *R114CU* (CANDY WINE BERRY RED-U) | ||
| 81121-MG9-770ZB | TRUNK ASSY. (UPPER) *PB123PA* (PEARL SIREN BLUE-A) | ||
| 81121-MG9-770ZC | TRUNK ASSY. (UPPER) *NH136MU* (SENIOR GRAY METALLIC) | ||
| 81122-MG9-770 | STIFFENER, R. TRUNK LOCK | ||
| 1 | 81123-MG9-770 | STIFFENER, L. TRUNK LOCK | 1 |
| 81125-MG9-770ZA | SEAT, BACK (TYPE1) | ||
| 81125-MG9-770ZB | SEAT, BACK (TYPE2) | ||
| 81128-MG9-770 | EMBLEM, TRUNK (UPPER) | ||
| 81129-MG9-770 | HOOK, TRUNK LOCK | ||
| 81130-MG9-770 | HINGE, TRUNK | ||
| 81134-MG9-770 | WASHER, HINGE | ||
| 81135-MG9-770 | RUBBER, HINGE | ||
| 81170-MG9-771 | LOCK ASSY., TRUNK | ||
| 81180-MG9-770 | BAG, TRUNK (INNER) | ||
| 81216-ME2-770 | RUBBER, SADDLEBAG CUSHION | ||
| 81223-MG9-770 | PLATE, LOCK SETTING | ||
| 81242-MG9-770 | FLOOR MAT, TRUNK | ||
| 81245-463-770 | COLLAR, SADDLEBAG SETTING | ||
| 81247-463-770 | RUBBER B, SADDLEBAG SETTING | ||
| 81420-MG9-770 | RUBBER, TRUNK SEAL | ||
| 87520-MG9-770 | LABEL, TRUNK SADDLEBAG CAUTION | ||
| 90108-MG9-770 | GROMMET, SCREW (4MM) | ||
| 2 | 90201-428-900 | NUT, CAP (6MM) | 2 |
| 6 | 93500-04010-0G | SCREW, PAN (4X10) | 6 |
| 8 | 93500-05012-0G | SCREW, PAN (5X12) | 8 |
| 8 | 93901-34320 | SCREW, TAPPING (4X12) | 8 |
| 3 | 93903-24280 | SCREW, TAPPING (4X10) | 3 |
| 6 | 94021-04070-0S | NUT, CAP (4MM) | 6 |
| 2 | 94021-06070-0S | NUT, CAP (6MM) | 2 |
| 4 | 95700-06028-00 | BOLT, FLANGE (6X28) | 4 |
| 4 | 96000-06028-00 | BOLT, FLANGE (6X28) | 4 |
| 4 | 96001-06028-00 | BOLT, FLANGE (6X28) | 4 |
| 4 | 95701-06028-00 | BOLT, FLANGE (6X28) | 4 |
