Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 12361-035-000 | CAP, TAPPET ADJUSTING HOLE | 1 |
| 12361-300-000 | CAP, VALVE ADJ. | ||
| 12361-371-980 | CAP, VALVE ADJ. | ||
| 41300-MG9-010 | GEAR ASSY., FINAL DRIVEN | ||
| 41300-MG9-020 | GEAR ASSY., FINAL DRIVEN | ||
| 41300-MG9-030 | GEAR ASSY., FINAL DRIVEN | ||
| 41301-MG9-000 | CASE, FINAL GEAR Use up to Frame SN EA016176 | ||
| 41301-MG9-010 | CASE, FINAL GEAR | ||
| 41301-MG9-010 | CASE, FINAL GEAR Use up to Frame SN EA016176 | ||
| 1 | 41306-MB0-010 | CAP, BREATHER | 1 |
| 1 | 41306-MB0-020 | CAP, BREATHER | 1 |
| 41306-ME5-305 | BREATHER ASSY. | ||
| 41310-MG9-000 | GEAR SET, FINAL | ||
| 41321-MG9-000 | COVER, GEAR CASE | ||
| 41324-MG9-000 | PLATE, DUST GUARD | ||
| 41331-MG9-000 | RETAINER, BEARING | ||
| 1 | 41332-415-000 | LOCK A, BEARING ADJUSTING (SINGLE TAB) | 1 |
| 1 | 41333-415-000 | LOCK B, BEARING ADJUSTING (DOUBLE TABS) | 1 |
| 41410-MG9-000 | JOINT, PINION | ||
| 41433-MG9-000 | HOLDER, O-RING | ||
| 1 | 41436-MB0-310 | PIN, RING GEAR STOPPER | 1 |
| 1 | 41437-MB0-310 | SHIM A, STOPPER PIN (0.10) | 1 |
| 1 | 41438-MB0-310 | SHIM B, STOPPER PIN (0.15) | 1 |
| 1 | 41450-MG9-000 | SHIM A, PINION GEAR (1.32) | 1 |
| 1 | 41451-MG9-000 | SHIM B, PINION GEAR (1.38) | 1 |
| 1 | 41452-MG9-000 | SHIM C, PINION GEAR (1.44) | 1 |
| 1 | 41453-MG9-000 | SHIM D, PINION GEAR (1.50) | 1 |
| 1 | 41454-MG9-000 | SHIM E, PINION GEAR (1.56) | 1 |
| 1 | 41455-MG9-000 | SHIM F, PINION GEAR (1.62) | 1 |
| 1 | 41456-MG9-000 | SHIM G, PINION GEAR (1.68) | 1 |
| 1 | 41510-MB0-003 | WASHER, SPECIAL (35X40) | 1 |
| 1 | 41530-MG9-000 | SPACER A, RING GEAR (1.82) | 1 |
| 1 | 41531-MG9-000 | SPACER B, RING GEAR (1.88) | 1 |
| 1 | 41532-MG9-000 | SPACER C, RING GEAR (1.94) | 1 |
| 1 | 41533-MG9-000 | SPACER D, RING GEAR (2.00) | 1 |
| 1 | 41534-MG9-000 | SPACER E, RING GEAR (2.06) | 1 |
| 1 | 41535-MG9-000 | SPACER F, RING GEAR (2.12) | 1 |
| 1 | 41536-MG9-000 | SPACER G, RING GEAR (2.18) | 1 |
| 1 | 41537-MG9-000 | SPACER H, RING GEAR (2.24) | 1 |
| 1 | 41538-MG9-000 | SPACER I, RING GEAR (2.30) | 1 |
| 1 | 42625-MAH-000 | COLLAR B, RR. DISTANCE | 1 |
| 1 | 42625-MB4-000 | COLLAR B, RR. DISTANCE | 1 |
| 1 | 90013-883-000 | BOLT, FLANGE (6X12) (CT200) | 1 |
| 1 | 90109-371-000 | BOLT, SEALING (8MM) | 1 |
| 6 | 90133-MB0-000 | BOLT, FLANGE (8X27) | 6 |
| 90134-371-000 | BOLT, FLANGE (10X38) | ||
| 1 | 90305-MB4-003 | NUT, U (18MM) | 1 |
| 1 | 90381-MB0-010 | NUT, HEX. (16MM) | 1 |
| 1 | 90471-580-000 | GASKET (8MM) | 1 |
| 90509-MG9-000 | WASHER, STOPPER | ||
| 1 | 91051-MG9-003 | BEARING, RADIAL BALL (16013) (C3) | 1 |
| 1 | 91051-MN5-003 | BEARING, RADIAL BALL (65X100X11) (TOYO) | 1 |
| 91052-MG9-003 | BEARING, RADIAL BALL (6007) (C3) | ||
| 1 | 91061-MG9-004 | BEARING, RADIAL BALL (63/28) (KOYO) | 1 |
| 1 | 91061-MN5-004 | BEARING, RADIAL BALL (30X76X19) (TOYO) | 1 |
| 1 | 91061-MT3-003 | BEARING, RADIAL BALL (QJ3/28V1) | 1 |
| 91062-MG9-003 | BEARING, NEEDLE (20X35X18) | ||
| 91062-MG9-013 | BEARING, NEEDLE (20X35X18) | ||
| 91261-MG9-003 | OIL SEAL (35X54X8) | ||
| 1 | 91262-MG9-003 | OIL SEAL (39X56X7) (ARAI) | 1 |
| 1 | 91262-MG9-004 | OIL SEAL (39X56X7) (NOK) | 1 |
| 91265-MG9-003 | OIL SEAL (65X85X7) (ARAI) | ||
| 91265-MG9-004 | OIL SEAL (65X85X7) (NOK) | ||
| 1 | 91302-001-020 | O-RING (30.8MM) | 1 |
| 1 | 91356-MG9-003 | O-RING (39.5X2.4) (ARAI) | 1 |
| 1 | 91356-MG9-004 | O-RING (39.5X2.4) (NOK) | 1 |
| 1 | 91359-MG9-003 | O-RING (64.5X3.5) (ARAI) | 1 |
| 1 | 91359-MG9-004 | O-RING (64.5X3.5) (NOK) | 1 |
| 4 | 91700-MG9-000 | BOLT, STUD (8X42) | 4 |
| 4 | 92900-08025-0E | BOLT, STUD (8X25) | 4 |
| 1 | 92000-06012 | BOLT, HEX. (6X12) | 1 |
| 1 | 92101-06012 | BOLT, HEX. (6X12) | 1 |
| 1 | 92101-06012-0A | BOLT, HEX. (6X12) | 1 |
