Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 30400-MG9-004 | IGNITER UNIT | ||
| 30400-MG9-005 | IGNITER UNIT | ||
| 30501-MG9-000 | STAY A, IGNITION COIL | ||
| 30502-MG9-000 | STAY B, IGNITION COIL | ||
| 2 | 30510-MA6-013 | COIL, IGNITION | 2 |
| 4 | 30700-KR3-670 | CAP ASSY., NOISE SUPPRESSOR | 4 |
| 4 | 30700-MB9-153 | CAP ASSY., NOISE SUPPRESSOR | 4 |
| 30705-MG9-770 | SEAL, R. SUPPRESSOR | ||
| 30706-MG9-770 | SEAL, L. SUPPRESSOR | ||
| 1 | 30750-MG9-P00 | WIRE SET, IGNITION (1-1) | 1 |
| 1 | 30750-MG9-405 | WIRE, IGNITION | 1 |
| 1 | 30751-MG9-000 | WIRE SET, IGNITION (1-1) | 1 |
| 1 | 30750-MG9-P00 | WIRE SET, IGNITION (2-2) | 1 |
| 1 | 30752-MG9-000 | WIRE SET, IGNITION (2-2) | 1 |
| 1 | 30750-MG9-P00 | WIRE SET, IGNITION (3-3) | 1 |
| 1 | 30753-MG9-000 | WIRE SET, IGNITION (3-3) | 1 |
| 1 | 30750-MG9-P00 | WIRE SET, IGNITION (4-4) | 1 |
| 1 | 30754-MG9-000 | WIRE SET, IGNITION (4-4) | 1 |
| 31600-MG9-000 | RECTIFIER ASSY., REGULATE | ||
| 31600-MG9-010 | RECTIFIER ASSY., REGULATE | ||
| 31605-MG9-000 | STAY, REGULATE RECTIFIER | ||
| 31606-MG9-000 | GUIDE, WIRE HARNESS | ||
| 31610-MG9-931 | FILTER KIT, RADIO NOISE (Optional). | ||
| 31620-ML8-770 | FILTER, REGULATE RECTIFIER (Optional). | ||
| 31630-ML8-770 | FILTER, LINE (Optional). | ||
| 1 | 32727-PE1-660 | BAND, TUBE (Optional). | 1 |
| 35220-MB9-781 | CANCEL UNIT, TURN SIGNAL | ||
| 35228-MG9-000 | STAY, CANCEL UNIT | ||
| 35229-MB9-781 | RUBBER | ||
| 36010-PA6-004 | JOINT, THREE WAY | ||
| 36034-PD1-000 | PLUG, SEALING | ||
| 36100-MB1-701 | RELAY, FUEL CUT | ||
| 36101-MG9-000 | SUSPENSION, FUEL CUT RELAY | ||
| 36130-MC7-003 | RELAY, MAIN | ||
| 36135-MG9-000 | STAY, MAIN RELAY | ||
| 1 | 38301-MG9-671 | FLASHER, COMBINATION | 1 |
| 1 | 38301-MG9-681 | RELAY, TURN SIGNAL (MITSUBA) | 1 |
| 2 | 38301-MG9-672 | FLASHER, COMBINATION (DENSO) | 2 |
| 2 | 38301-MG9-681 | RELAY, TURN SIGNAL (MITSUBA) | 2 |
| 38305-MG9-000 | STAY, TURN SIGNAL RELAY | ||
| 38305-MG9-870 | STAY, RELAY (B) | ||
| 1 | 38306-GE7-000 | SUSPENSION, TURN SIGNAL RELAY | 1 |
| 1 | 38306-GE7-008 | SUSPENSION, TURN SIGNAL RELAY (DENSO) | 1 |
| 1 | 38306-292-000 | SUSPENSION, TURN SIGNAL RELAY | 1 |
| 38306-MG9-680 | SUSPENSION, TURN SIGNAL RELAY | ||
| 38306-MG9-771 | SUSPENSION, TURN SIGNAL RELAY | ||
| 38306-MG9-772 | SUSPENSION, TURN SIGNAL RELAY | ||
| 38308-MG9-000 | HOLDER, CONNECTOR | ||
| 83121-MG9-770 | HOLDER, CONNECTOR | ||
| 90105-MG9-871 | NUT, FLANGE CAP (5MM) (Optional). | ||
| 1 | 90651-MA6-720 | BAND, WIRE HARNESS (Optional). | 1 |
| 2 | 93892-06012-08 | SCREW-WASHER (6X12) | 2 |
| 93892-06028-1H | SCREW-WASHER (6X28) | ||
| 4 | 93901-22320 | SCREW, TAPPING (3X12) (Optional). | 4 |
| 1 | 94101-05700 | WASHER, PLAIN (5MM) (Optional). | 1 |
| 4 | 94101-06800 | WASHER, PLAIN (6MM) | 4 |
| 1 | 95001-35003-60M | BULK HOSE, FUEL (3.5X3000) (3.5X100) | 1 |
| 1 | 95001-35003-60M | BULK HOSE, FUEL (3.5X3000) (3.5X110) | 1 |
| 4 | 95002-02650 | CLIP, TUBE (B6.5) | 4 |
| 3 | 95700-06010-07 | BOLT, FLANGE (6X10) | 3 |
| 3 | 95701-06010-07 | BOLT, FLANGE (6X10) | 3 |
| 1 | 95700-06010-08 | BOLT, FLANGE (6X10) | 1 |
| 1 | 95701-06010-08 | BOLT, FLANGE (6X10) | 1 |
| 2 | 95700-06012-00 | BOLT, FLANGE (6X12) | 2 |
| 2 | 95701-06012-00 | BOLT, FLANGE (6X12) | 2 |
| 2 | 95700-06035-00 | BOLT, FLANGE (6X35) | 2 |
| 2 | 95701-06035-00 | BOLT, FLANGE (6X35) | 2 |
