Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2 | 17245-107-000 | RUBBER, AIR CLEANER HOUSING MOUNTING | 2 |
| 2 | 17245-107-010 | RUBBER, AIR CLEANER HOUSING MOUNTING | 2 |
| 2 | 17611-MB1-000 | CUSHION, FR. FUEL TANK | 2 |
| 1 | 37220-439-007 | LOCK, FILLER LID | 1 |
| 1 | 37222-463-000 | SPRING, LOCK KEY SETTING | 1 |
| 50432-MG9-300 | SEAL, TOOL TRAY | ||
| 4 | 61104-428-000 | COLLAR, FR. FENDER | 4 |
| 61105-428-000 | COLLAR, RR. FENDER | ||
| 1 | 77251-342-000 | BAG, SERVICE BOOK | 1 |
| 83100-MG9-770ZA | SHELTER ASSY. *R114CU* (CANDY WINE BERRY RED-U) | ||
| 83100-MG9-770ZB | SHELTER ASSY. *PB123PA* (PEARL SIREN BLUE-A) | ||
| 83100-MG9-770ZC | SHELTER ASSY. *NH136MU* (SENIOR GRAY METALLIC) | ||
| 83101-MG9-770ZB | SHELTER, R. SIDE *PB123PA* (PEARL SIREN BLUE-A) | ||
| 83101-MG9-770ZC | SHELTER, R. SIDE *NH136MU* (SENIOR GRAY METALLIC) | ||
| 83101-MG9-770ZA | SHELTER, R. SIDE *R114CU* (CANDY WINE BERRY RED-U) | ||
| 83102-MG9-770ZB | SHELTER, L. SIDE *PB123PA* (PEARL SIREN BLUE-A) | ||
| 83102-MG9-770ZC | SHELTER, L. SIDE *NH136MU* (SENIOR GRAY METALLIC) | ||
| 83102-MG9-770ZA | SHELTER, L. SIDE *R114CU* (CANDY WINE BERRY RED-U) | ||
| 83105-MG9-000 | SPACER, FR. SHELTER | ||
| 83106-MG9-000 | SPACER, RR. SHELTER | ||
| 83108-MG9-770 | RUBBER, SHELTER SIDE | ||
| 83111-MG9-770 | FRAME A, SHELTER | ||
| 83113-MG9-770 | STAY, R. SHELTER | ||
| 83114-MG9-770 | STAY, L. SHELTER | ||
| 83115-MG9-000ZA | SHELTER, TOP *R114CU* (CANDY WINE BERRY RED-U) | ||
| 83115-MG9-000ZB | SHELTER, TOP *PB123PA* (PEARL SIREN BLUE-A) | ||
| 83115-MG9-000ZD | SHELTER, TOP *NH136MU* (SENIOR GRAY METALLIC) | ||
| 83116-MG9-000 | FRAME B, SHELTER | ||
| 83117-MG9-000ZA | LID, SHELTER *R114CU* (CANDY WINE BERRY RED-U) | ||
| 83117-MG9-000ZB | LID, SHELTER *PB123PA* (PEARL SIREN BLUE-A) | ||
| 83117-MG9-000ZD | LID, SHELTER *NH136MU* (SENIOR GRAY METALLIC) | ||
| 1 | 83119-MG9-000 | COLLAR, LOCK SETTING | 1 |
| 83123-463-000 | HOLDER, SPRING | ||
| 83124-463-000 | SPRING, SHELTER LID | ||
| 83127-MG9-000 | WEATHERSTRIP, SHELTER | ||
| 83130-MG9-770 | DRIP, SHELTER | ||
| 83135-463-000 | COVER, SPRING | ||
| 83137-463-000 | SPRING A, TOP SHELTER OPENING | ||
| 83138-463-000 | SPRING B, TOP SHELTER OPENING | ||
| 83139-MG9-000 | RUBBER, TOP SHELTER TAIL | ||
| 2 | 83140-463-000 | ROLLER, OPENER SPRING | 2 |
| 83141-MG9-000 | LOCK, TOP SHELTER | ||
| 83171-MG9-770 | PANEL, R. FR. BLIND | ||
| 83171-MG9-770ZC | PANEL, R. FR. BLIND *NH105* (MAT BLACK) | ||
| 83172-MG9-770 | PANEL, L. FR. BLIND | ||
| 83172-MG9-770ZC | PANEL, L. FR. BLIND *NH105* (MAT BLACK) | ||
| 83173-MG9-770 | CAP, BLIND | ||
| 83173-MG9-770ZC | CAP, BLIND *NH105* (MAT BLACK) | ||
| 83501-MG9-010 | TRAY, TOOL | ||
| 83501-ML8-700 | TRAY, TOOL | ||
| 83901-MG9-770 | STAY, R. FR. BLIND SETTING | ||
| 83902-MG9-770 | STAY, L. FR. BLIND SETTING | ||
| 83910-MG9-770 | COVER, R. CONNECTOR HOLDER | ||
| 83911-MG9-770 | COVER, L. CONNECTOR HOLDER | ||
| 87123-MB9-000 | EMBLEM, TOP SHELTER (GOLDWING) | ||
| 2 | 87411-538-910 | RUBBER, RR. EMBLEM SETTING | 2 |
| 87507-371-671 | LABEL, RESERVE TANK | ||
| 87508-415-670 | MARK, RADIATOR CAUTION | ||
| 87512-461-770 | MARK, ACCESSORIES & LOADING CAUTION | ||
| 87560-181-760ZC | MARK, DRIVE CAUTION *A73* (GOLD) | ||
| 2 | 90313-567-000 | NUT, SPEED (3MM) | 2 |
| 18 | 93401-06010-08 | BOLT-WASHER (6X10) | 18 |
| 18 | 93491-06010-08 | BOLT-WASHER (6X10) | 18 |
| 2 | 93401-06012-00 | BOLT-WASHER (6X12) | 2 |
| 2 | 93491-06012-00 | BOLT-WASHER (6X12) | 2 |
| 2 | 93401-06016-00 | BOLT-WASHER (6X16) | 2 |
| 2 | 93491-06016-00 | BOLT-WASHER (6X16) | 2 |
| 1 | 93401-06020-07 | BOLT-WASHER (6X20) | 1 |
| 1 | 93491-06020-07 | BOLT-WASHER (6X20) | 1 |
| 4 | 93903-25280 | SCREW, TAPPING (5X12) | 4 |
| 4 | 94050-06080 | NUT, FLANGE (6MM) | 4 |
| 4 | 95700-06010-07 | BOLT, FLANGE (6X10) | 4 |
| 4 | 95701-06010-07 | BOLT, FLANGE (6X10) | 4 |
| 4 | 95700-06022-00 | BOLT, FLANGE (6X22) | 4 |
| 4 | 95701-06022-00 | BOLT, FLANGE (6X22) | 4 |
