Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 708200959 | LH Bumper Trim | 1 |
| 2 | 250000759 | Torx Truss Pt K40 X 16 | 2 |
| 1 | 708200960 | RH Bumper Trim | 1 |
| 1 | 710006760 | Accessory Lighting Harness | 1 |
| 3 | 414227300 | Clip | 3 |
| 1 | 708400406 | Lighting Harness Connector Cap | 1 |
| 2 | 250001123 | Hex. Flange Screw K40 X 16 | 2 |
| 1 | 710004901 | Connector Plug | 1 |
| 1 | 414227300 | Clip | 1 |
| 1 | 707000995 | Pressure And Temperature Sensor | 1 |
| 1 | 207662554 | Hex. Flange Screw M6 X 25 | 1 |
| 1 | 269500725 | M6 Nut Housing Ass'y Includes 7r to 7r2 | 1 |
| 1 | 269500252 | M6 Nut Housing Ass'y | 1 |
| 1 | 232561600 | Hex. Elastic Stop Nut M6 | 1 |
| 1 | 710004764 | AAPTS Harness | 1 |
| 1 | 705003464 | Cap | 1 |
| 1 | 705012290 | Storage Box Ass'y Includes 100 to 100h | 1 |
| 8 | 293740028 | Dual Lock Velcro Washer 3/4" | 8 |
| 2 | 390401400 | Rivet | 2 |
| 2 | 234031600 | Flat Washer 3 mm, Stainless Steel | 2 |
| 1 | 293830005 | Rubber Bumper | 1 |
| 8 | 269500725 | M6 Nut Housing Ass'y Includes 120 to 120b | 8 |
| 1 | 705004628 | Battery Cover Ass'Y Includes 130 to 130c | 1 |
| 2 | 293740028 | Dual Lock Velcro Washer 3/4" | 2 |
| 2 | 250000767 | Torx Truss Screw M6 X 12 | 2 |
| 2 | 705011444 | Fuse Cover Ass'y | 2 |
| 1 | 710002858 | Rubber Plug | 1 |
| 1 | 708400166 | Cap | 1 |
| 1 | 708201071 | Deep Black, Upper Box Support | 1 |
| 1 | 705003911 | Spring | 1 |
| 1 | 705007379 | Latch | 1 |
| 2 | 207663544 | Hex. Flange Screw M6 X 35 | 2 |
| 2 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 2 |
| 1 | 293250529 | Neoprene Seal 1420MM | 1 |
| 8 | 293150230 | Tuflok Plastic Rivet | 8 |
| 2 | 207661644 | Hex. Flange Screw M6 X 16 | 2 |
| 2 | 232561434 | Elastic Stop Nut M6 | 2 |
| 1 | 219704387 | Gasket 4100Mm Long | 1 |
| 1 | 219704424 | Vinyl Tubing, Low Temp 3000Mm Long | 1 |
| 1 | 708201076 | Deep Black, Front Bumper | 1 |
| 1 | 708201124 | Upper Bumper Trim | 1 |
| 4 | 250000760 | Torx Screw Truss Head K50X20 T20 | 4 |
| 2 | 250000755 | Torx Screw M6 X 16 | 2 |
| 4 | 293150230 | Tuflok Plastic Rivet | 4 |
| 1 | 708201084 | Sensor Support | 1 |
| 2 | 250001131 | Torx Truss PT K40 x 12 | 2 |
| 1 | 708200879 | Deep Black, LH Inner Air Scoop | 1 |
| 3 | 250001131 | Torx Truss PT K40 x 12 | 3 |
| 2 | 250000712 | Torx Screw M6 X 20 | 2 |
| 1 | 708200880 | Deep Black, RH Inner Air Scoop | 1 |
| 1 | 708201086 | Deep Black, LH Exterior Scoop | 1 |
| 1 | 293150230 | Tuflok Plastic Rivet | 1 |
| 1 | 708201087 | Deep Black, RH Exterior Scoop | 1 |
| 2 | 708200970 | Black Epoxy, Air Scoop Grille | 2 |
| 4 | 705004838 | Flat Clip | 4 |
| 1 | 708200951 | Petrol, Front Hood | 1 |
| 1 | 705002223 | Lug | 1 |
| 2 | 232180600 | Hex. Jam Nut M8 | 2 |
| 1 | 234081410 | Flat Washer 8 mm | 1 |
| 1 | 233281464 | Elastic Flange Nut M8 | 1 |
| 1 | 708200886 | Black, Hood Hinge | 1 |
| 4 | 207561244 | Hex. Flange Screw M6 X 12, Scotch Grip | 4 |
| 1 | 705003322 | Spacer | 1 |
| 1 | 230663084 | Hex. Flange Screw M6 X 130 | 1 |
| 1 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 1 |
| 4 | 210262050 | Hexagonal Head Screw | 4 |
| 2 | 207662044 | Hex. Flange Screw M6 X 20 | 2 |
| 1 | 517305742 | Hood Cable | 1 |
