Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 705600987 | LH Front Caliper Includes 10 TO 10b | 1 |
| 1 | 219800237 | Brake Pad Kit Not shown | 1 |
| 1 | 219800238 | Spring/Pin/Clip Kit Not shown | 1 |
| 1 | 705600988 | RH Front Caliper Inclus 20 TO 20b | 1 |
| 4 | 207506556 | Hex Flange Screw M10 X 65 | 4 |
| 1 | 705601774 | RH Front Flexible Brake Line | 1 |
| 2 | 293650256 | Clamp | 2 |
| 1 | 293750008 | Tie Wrap 368 mm | 1 |
| 4 | 207561634 | Hex. Flange Screw M6 X 16, Scotch Grip | 4 |
| 4 | 414920600 | Washer | 4 |
| 2 | 705601201 | Banjo Bolt/ Bleeder | 2 |
| 2 | 705601190 | Bleeder Bolt Cap | 2 |
| 1 | 705601773 | LH Front Flexible Brake Line Includs 65 TO 65a | 1 |
| 2 | 705601631 | Front Brake Disk | 2 |
| 1 | 705601632 | Rear Brake Disk | 1 |
| 5 | 250001054 | Hex. Flange Screw M10 X 25 | 5 |
| 1 | 705600989 | Rear Caliper Includes 90 TO 90d | 1 |
| 1 | 219800239 | Brake Pad Kit Not shown | 1 |
| 1 | 219800240 | Spring/Pin/Clip Kit Not shown | 1 |
| 1 | 219800241 | Rear Cable Support Kit Not shown | 1 |
| 1 | 219800242 | Rear Dust Cover Not shown | 1 |
| 1 | 705601746 | Rear Brake Caliper Support | 1 |
| 2 | 207523056 | Hex. Flange Screw M12 X 30, Scotch Grip | 2 |
| 1 | 705601675 | Flexible Brake Line Rear | 1 |
| 1 | 705601201 | Banjo Bolt/ Bleeder | 1 |
| 1 | 705601190 | Bleeder Bolt Cap | 1 |
| 2 | 414920600 | Washer | 2 |
| 3 | 207662054 | Hex. Flange Screw M6 X 20 | 3 |
| 1 | 233261494 | Hex. Flange Elastic Nut M6 | 1 |
| 1 | 706202587 | Cable Guide | 1 |
| 1 | 705600722 | Tandem Cylinder Master | 1 |
| 2 | 207583044 | Hex. Flange Screw M8 X 30, Scotch Grip | 2 |
| 1 | 705503085 | Tension Spring | 1 |
| 1 | 232081414 | Hex. Nut M8 | 1 |
| 1 | 705600716 | Bellow | 1 |
| 1 | 509000442 | Oeticker Gear Clamp, 25.6-706R | 1 |
| 2 | 210261250 | Hex. Flange Screw M6 X 12 | 2 |
| 5 | 705601513 | Rigid Tube Support | 5 |
| 1 | 705601157 | Tandem Rigid Tube | 1 |
| 1 | 705601158 | Tandem Rigid Tube | 1 |
| 2 | 507032551 | Banjo Bolt | 2 |
| 1 | 705601159 | Rear Brake Rigid Tube | 1 |
| 1 | 705601526 | Master Cylinder Reservoir Ass'y Includes 500 TO 500f | 1 |
| 1 | 219800350 | Diaphragm Cover Ass'y Includes 500c | 1 |
| XXXX | Not Available As Spare Part - Diaphragm Not available seperately | ||
| 2 | 705601073 | Oil Level Sensor | 2 |
| XXXX | Not Available As Spare Part - Float Not available seperately | ||
| 1 | 705601294 | Spindle Lock | 1 |
| 2 | 710002033 | Connector Holder | 2 |
| 1 | 219704415 | Hose 4.32Mm 3000Mm Long | 1 |
| 2 | 705601790 | Formed Hose | 2 |
| 2 | 709000571 | Hose Support | 2 |
| 4 | 293650047 | Crimp Clamp, 15.3-706R | 4 |
| 1 | 705601786 | Brake Pedal | 1 |
| 1 | 705014023 | Rubber Pad | 1 |
| 1 | 705601847 | Link Rod Assembly | 1 |
| 1 | 705601789 | Rocker Rear | 1 |
| 1 | 705601822 | Rocker Front | 1 |
| 1 | 705601340 | MASTER CYLINDER TIE-ROD END | 1 |
| 1 | 706204402 | Stopper | 1 |
| 1 | 705600468 | Piston Rod | 1 |
| 2 | 709402394 | Bearing, Sleeve | 2 |
| 2 | 709401733 | Bearing, Sleeve | 2 |
| 1 | 705601584 | Brake Switch Spring | 1 |
| 1 | 710005480 | Switch Brake | 1 |
| 1 | 705014735 | Axle, Rocker | 1 |
| 1 | 207561244 | Hex. Flange Screw M6 X 12, Scotch Grip | 1 |
| 1 | 705600502 | Bleeder Screw | 1 |
| 1 | 707001058 | Parking Brake Cable | 1 |
| 1 | 515175507 | Open Clamp | 1 |
| 1 | 210262050 | Hexagonal Head Screw | 1 |
| 1 | 705600768 | Front Pulley Cable Includes 800 TO 800b | 1 |
| 2 | 705600458 | Bearing | 2 |
| 1 | 233201464 | Hex. Flange Elastic M10 x 1.5 | 1 |
| 1 | 293900087 | Bushing | 1 |
| 1 | 207604054 | Hex. Flange Screw M10 X 40 | 1 |
| 3 | 233281414 | Hex. Flange Elastic Nut M8 | 3 |
| 1 | 207685554 | Hex. Flange Screw M8 X 55 | 1 |
| 1 | 207684054 | Hex. Flange Screw M8 X 40 | 1 |
| 2 | 250000714 | Flange Screw M6 X 26 | 2 |
| 2 | 233261466 | Hex. Flange Elastic Nut M6 | 2 |
