Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1341363 | N/A,USE COMPONENTS (Incl. 1-67)(AA) | ||
| 1341374 | N/A,USE COMPONENTS (Incl. all less 49)(FB) | ||
| 3 | 3233788 | TRIPLE LIP SEAL | 3 |
| 17 | 3233252 | SCREW | 17 |
| 3233610 | GEARCASE,LH (AA) | ||
| 3233763 | Discontinued (FB) | ||
| 4 | 3233529 | KNOCK PIPE | 4 |
| 4 | 3233019 | BEARING | 4 |
| 3233756 | Discontinued | ||
| 3233036 | Discontinued | ||
| 1 | 3233770 | GEAR-16T W/19T SPLINE (AA) | 1 |
| 3233755 | GEAR-14/19T (FB) | ||
| 4 | 3233018 | BEARING | 4 |
| 2 | 3233961 | NUT-LOCK HEX FLANGE NYLON 5/16 (AA) | 2 |
| ------- | WASHER | ||
| 2 | 3233153 | BELLCRANK | 2 |
| 2 | 3233045 | RETAINING RING | 2 |
| 2 | 3233040 | WASHER | 2 |
| 1 | 8360009-600 | LINE,FUEL,1/8 ID,600 CM. | 1 |
| 3233037 | VENT | ||
| 8 | 3233749 | SCREW | 8 |
| 3234019 | SWITCH-GEAR INDICATION 3 POS (Qty. 2 for FB) | ||
| 3233902 | GEARCASE,RH (AA) | ||
| 1 | 3233765 | GEARCASE-MAIN (FB) | 1 |
| 3233711 | Discontinued | ||
| 1 | 3233872 | NYLON WASHER | 1 |
| 3233628 | WASHER | ||
| 1 | 3233732 | ENGAGEMENT DOG, LOW (AA) | 1 |
| 1 | 3233758 | ENGAGEMENT-LOW/PARK (FB) | 1 |
| 2 | 3233306 | RETAINING RING | 2 |
| 3 | 3233619 | WASHER,THRUST | 3 |
| 1 | 3233631 | GEAR,35T (AA) | 1 |
| 3233760 | GEAR-36T (FB) | ||
| 2 | 3233103 | BEARING, NEEDLE | 2 |
| 3233602 | SHIFT FORK | ||
| 3233598 | SHAFT REVERSE (AA) | ||
| 3233761 | SHAFT-REVERSE (FB) | ||
| 3233012 | WASHER | ||
| 1 | 3233014 | NEEDLE BEARING | 1 |
| 3233599 | Discontinued | ||
| 1 | 3233029 | RING,RETAINING | 1 |
| 3234020 | ENGAGEMENT-DOG,HIGH/REV 12 PNT | ||
| 1 | 3233600 | GEAR, 30T | 1 |
| 1 | 3233613 | SPACER | 1 |
| 3233601 | GEAR,HELICAL,40T | ||
| 3233708 | Discontinued (FB) | ||
| 1 | 3233309 | BRACKET INTERLOCK | 1 |
| 1 | 3233032 | SPRING | 1 |
| 3233308 | PIN,INTERLOCK | ||
| 3233747 | SCREW-TAPPING,W/LOCK WASHER | ||
| 3233612 | Discontinued (AA) | ||
| 3233709 | GEAR,HELICAL,48T (FB) | ||
| 4 | 3233608 | SCREW (Qty. 8 for FB) | 4 |
| 3233609 | COVER,BEARING | ||
| 1 | 3233106 | SNAP RING | 1 |
| 1 | 3233607 | BALL BEARING | 1 |
| 3234912 | SUBASM-GRND SPIRL BVL(411467) [Incl. 52] | ||
| 3233605 | SHIFT,FORK,LOW (AA) | ||
| 1 | 3233759 | FORK-SHIFT,LOW/PARK (FB) | 1 |
| 3234001 | GEAR INDICATION SWITCH (AA) | ||
| 3233757 | PLATE-PARKLOCK (FB) | ||
| 3233620 | SPROCKET,12T (AA) | ||
| 1 | 3233873 | SPROCKET-22T/18T (FB) | 1 |
| 3234912 | SUBASM-GRND SPIRL BVL(411467) [Incl. 47] | ||
| 3233622 | SHAFT,REAR OUTPUT | ||
| 1 | 3233582 | BUTTON,THRUST | 1 |
| 1 | 3233583 | SHIM, .450 X .265 | 1 |
| 3233781 | COVER-OUTPUT,FRONT | ||
| 1 | 3233777 | HEX FLANGE PLUG | 1 |
| 3234035 | WASHER-.625X.382X.060 | ||
| 1 | 3233611 | SHIM KIT | 1 |
| 1 | 3233625 | OUTPUT SHAFT, FRONT | 1 |
| 3233093 | Discontinued (AA) | ||
| 1 | 3233844 | SPROCKET, 22 TOOTH (FB) | 1 |
| 3233626 | ROLLER CHAIN,24P (AA) | ||
| 1 | 3233784 | CHAIN-SILENT,REXNORD (FB) | 1 |
| 1 | 3233552 | GARLOCK BUSHING | 1 |
| 3233624 | SHIFT SHAFT | ||
| 3233627 | Discontinued | ||
| 2 | 3233548 | O-RING | 2 |
| 3233618 | RING,RETAINING | ||
| 1 | 3233357 | SPACER | 1 |
