Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 291002316 | ANTI SLIP MAT_DECK | 1 |
| 1 | 291002382 | RH CENTER REAR CARPET | 1 |
| 1 | 291002383 | LH CENTER REAR CARPET | 1 |
| 291002384 | RH CENTER FRONT CARPET | ||
| 291002385 | LH Center Front Carpet | ||
| 1 | 291002386 | RH FRONT CARPET | 1 |
| 1 | 291002387 | LH FRONT CARPET | 1 |
| 1 | 291001758 | RH ANTI-SKID | 1 |
| 291001759 | LH Anti-Skid | ||
| 2 | 293150016 | Rivet 1/8" | 2 |
| 2 | 293000014 | Black, Snap Cap | 2 |
| 1 | 292000011 | U-CLAMP STD, LTD | 1 |
| 1 | 292000933 | U-Clamp WAKE | 1 |
| 2 | 293050001 | Flat Washer M8.5 x 18 WAKE | 2 |
| 1 | 291002351 | Hook STD, LTD | 1 |
| 1 | 291001386 | Black, Finition Plate STD, LTD | 1 |
| 1 | 296000309 | Silicone Sealant 51388, 300 ml | 1 |
| 291001747 | Retainer Plate | ||
| 2 | 232581200 | Hex. Elastic Nut M8 Brass | 2 |
| 269501527 | RH Front Moulding STD, WAKE | ||
| 2 | 293730006 | Black, Dart | 2 |
| 8 | 241142560 | Hex. Flange Screw K40 X 25 | 8 |
| 250200055 | WASHER 4.3 MM, NYLON | ||
| XXX | Not Available As Spare Parts | ||
| 269501529 | LH Front Moulding STD, WAKE | ||
| 291001942 | BUMPER NOSE, BLACK | ||
| 4 | 250000236 | TORX SCREW 10-14 X 1-1/8 | 4 |
| 291001519 | Bumper Plug, Black | ||
| 2 | 291001040 | Bumper Plug, Black | 2 |
| 2 | 291002503 | Side Bumper | 2 |
| 52 | 293150005 | Pop Rivet 3/16" | 52 |
| 291002504 | Side Bumper Trim WAKE | ||
| 291002505 | Side Bumper Trim STD, LTD | ||
| 1 | 291002242 | REAR BUMPER, BLACK | 1 |
| 8 | 293150005 | Pop Rivet 3/16" | 8 |
| 291001484 | Rear Bumper Trim, Viper Red WAKE | ||
| 1 | 291002325 | REAR BUMPER TRIM, GREY STD, LTD | 1 |
| 2 | 291002244 | Bumper Corner | 2 |
| 6 | 293150013 | Pop Rivet 3/16" | 6 |
| 6 | 291000339 | Bumper Plug, Black | 6 |
| 1 | 269501031 | Cover Trim, Black | 1 |
| 3 | 293730006 | Black, Dart | 3 |
| 1 | 269500968 | GLOVE BOX STD, WAKE | 1 |
| 1 | 269501648 | GLOVE BOX DOOR STD, WAKE | 1 |
| 1 | 269500553 | Latch, Black | 1 |
| 1 | 211400008 | Pin STD, WAKE | 1 |
| 1 | 291000922 | Latch Spring | 1 |
| 2 | 211100002 | Push Nut STD, WAKE | 2 |
| 293250126 | GASKET STD, WAKE | ||
| 293250127 | GASKET | ||
| 1 | 294000744 | TOOL KIT | 1 |
| 529017300 | FORK WRENCH | ||
| 529035731 | Socket Wrench | ||
| 529000004 | SCREW DRIVER | ||
| 1 | 293250151 | Seal WAKE | 1 |
| 1 | 291002276 | RETRACTABLE SPRING PIN WAKE | 1 |
| 1 | 206560860 | SOCKET SET SCREW M6 X 8 WAKE | 1 |
| 1 | 293800060 | Loctite 243, 10 ml WAKE | 1 |
| 2 | M5340464 | Gaine Poignee *Grip-Handle WAKE | 2 |
| 291002089 | Welded Support WAKE | ||
| 291002095 | Welded Ski Pole WAKE | ||
| 293300106 | X-ring WAKE | ||
| 1 | 291002099 | UPPER SLEEVE WAKE | 1 |
| 1 | 291002100 | LOWER SLEEVE WAKE | 1 |
| 1 | 219902218 | WARNING DECAL (WAKE BAR) WAKE | 1 |
| 2 | 205484060 | Socket Head Screw M8 X 40 WAKE | 2 |
| 2 | 234081600 | Stainless, Flat Washer 8 mm WAKE | 2 |
| 2 | 293830037 | Rubber Washer WAKE | 2 |
| 2 | 250200011 | Flat Washer 8 mm, Stainless WAKE | 2 |
| 2 | 232581200 | Hex. Elastic Nut M8 Brass WAKE | 2 |
