Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 277001234 | LH END CAP Premium | 1 |
| 277001311 | Prop Rod Hold | ||
| 2 | 293150043 | Pop Rivet 3/16" | 2 |
| 1 | 277001310 | PROP ROD | 1 |
| 293720075 | Shock Washer | ||
| 1 | 234061600 | Stainless, Flat Washer M6 | 1 |
| 4 | 277001312 | END ASS'Y Includes 6 to 7 | 4 |
| 4 | 293900055 | BUSHING | 4 |
| 2 | 293150092 | Pop Rivet 3/16” | 2 |
| 2 | 277001294 | RUBBER BUMPER | 2 |
| 277001348 | Pole Float | ||
| 277001377 | Beam | ||
| 1 | 277001349 | BUMPER SUPPORT | 1 |
| 5 | 234062600 | Flat Washer M6, Stainless | 5 |
| 5 | 205561260 | Socket Head Screw M6 X 12, Scotch Grip | 5 |
| 277001340 | Support | ||
| 4 | 207161660 | Hex. Screw M6 X 16 | 4 |
| 8 | 207065060 | Hex. Screw M6 X 50 | 8 |
| 12 | 234061600 | Stainless, Flat Washer M6 | 12 |
| 12 | 232561600 | Hex. Elastic Stop Nut M6 | 12 |
| 1 | 277001228 | STIFFENER | 1 |
| 277001341 | Spring Hook | ||
| 277001342 | Cylindrical Nut | ||
| 2 | 234062100 | Flat Washer 6 mm | 2 |
| 1 | 234062600 | Flat Washer M6, Stainless | 1 |
| 1 | 207169060 | Hex. Screw M6 X 90 | 1 |
| 1 | 277001230 | MOUNT BRIGE | 1 |
| 4 | 269500252 | M6 Nut Housing Ass'y Includes 27 to 28 | 4 |
| 4 | 232061600 | Hex. Nut M6 | 4 |
| 2 | 708000006 | Rubber Stopper | 2 |
| 277001231 | Retainer Plate | ||
| 2 | 293150013 | Pop Rivet 3/16" | 2 |
| 4 | 232581600 | Hex. Elastic Nut M8 | 4 |
| 4 | 234081600 | Stainless, Flat Washer 8 mm | 4 |
| 277001232 | Tube | ||
| 2 | 277001233 | RETAINER CLAMP ANODIZED | 2 |
| 4 | 205562060 | Socket Head Screw M6 X 20, Scotch Grip | 4 |
| 4 | 234061600 | Stainless, Flat Washer M6 | 4 |
| 1 | 414115200 | Tie-Rap 180 mm | 1 |
| 1 | 277001380 | LH END CAP Base | 1 |
| 4 | 293730016 | Dart, Black | 4 |
| 277001274 | AXLE CAP Premium | ||
| 1 | 277001235 | RH END CAP Premium | 1 |
| 1 | 277001381 | RH END CAP Base | 1 |
| 277001315 | Spring | ||
| 277001237 | Spring Guide | ||
| 1 | 277001395 | INNER COVER | 1 |
| 10 | 293150067 | Rivet | 10 |
| 1 | 293730018 | Mount Dart | 1 |
| 277001221 | Upper Steering Cover | ||
| 3 | 269501166 | Nut Housing Ass'y Includes 50 to 51 | 3 |
| 3 | 232561200 | Elastic Stop Nut M6, Brass | 3 |
| 3 | 234062600 | Flat Washer M6, Stainless | 3 |
| 3 | 207162060 | Hex. Forming Screw M6 X 20 | 3 |
| 277001224 | Cover Pole Yellow B-244 | ||
| 277001418 | Pole Cover Viper Red B-176 | ||
| 2 | 293730010 | Black Dart | 2 |
| 2 | 204000081 | Pop Rivet 3/16" | 2 |
| 1 | 277001268 | LOWER STEERING COLUMN TRIM | 1 |
| 291001519 | Bumper Plug, Black Base | ||
| 3 | 205961660 | SOCKET HEAD SCREW M6, SCOTCH GRIP | 3 |
| 277001304 | Lower Pole Foam | ||
| 277001317 | Middle Pole Foam | ||
| 277001314 | Upper Pole Foam | ||
| 277001350 | RH Pole Foam | ||
| 277001383 | Rear Foam Pole |
