Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 271001381 | HOUSING ASSY Includes 1 to 5 | ||
| 4 | 211100033 | Square Nut M8 | 4 |
| 1 | 271000653 | Wear Ring | 1 |
| 4 | 250000040 | Hex. Plastite Screw #10 X 3/8" | 4 |
| 4 | 234051600 | Flat Washer M5, Stainless | 4 |
| 1 | 293200087 | Neoprene Seal | 1 |
| 1 | 271000785 | Water Outlet | 1 |
| 1 | 271000965 | Impeller Shaft | 1 |
| 2 | 293350017 | Needle Bearing | 2 |
| 1 | 293350020 | THRUST WASHER | 1 |
| 1 | 293350022 | Thrust-Bearing | 1 |
| 1 | 267000094 | Oil Seal | 1 |
| 1 | 219704456 | Était/Was 293800038 Loctite 518, 50 ml | 1 |
| 219704461 | LUBRICANT LOCTITE LB 8150 236ML | ||
| 267000201 | Stainless Steel Impeller | ||
| 1 | 271000516 | Impeller Boot | 1 |
| 1 | 271000517 | Impeller Ring | 1 |
| 293600011 | Redline Pump Oil, 75W90, 12 x 6 oz | ||
| 1 | 293300011 | O-Ring | 1 |
| 293550032 | Jet Pump Bearing Grease, 110 G | ||
| 271001250 | IMPELLER COVER | ||
| 1 | 271001124 | PUSHER ASS?Y | 1 |
| 1 | 271001107 | SLIDER | 1 |
| 1 | 271001108 | SPRING | 1 |
| 3 | 205562560 | Socket Head Screw M6 X 25, Scotch Grip | 3 |
| 3 | 234061600 | Stainless, Flat Washer M6 | 3 |
| 1 | 211500001 | Pipe Plug Socket Head 1/8-27 Npt | 1 |
| 1 | 219704454 | Was 293800013 Loctite 56765 | 1 |
| 1 | 219704458 | Was 293800041 Loctite Primer 7649 | 1 |
| 1 | 267000187 | VENTURI, BLACK Premium | 1 |
| 267000189 | Venturi, Black Base | ||
| 2 | 271001133 | Siphon Tube | 2 |
| 2 | 293300013 | O-Ring | 2 |
| 3 | 207285060 | Hex. Screw M8 X 50, Scotch Grip Premium | 3 |
| 4 | 207285060 | Hex. Screw M8 X 50, Scotch Grip Base | 4 |
| 4 | 234081600 | Stainless, Flat Washer 8 mm Base | 4 |
| 3 | 234081600 | Stainless, Flat Washer 8 mm Premium | 3 |
| 1 | 234082600 | Flat Washer 8 mm, Stainless Premium | 1 |
| 2 | 234181601 | Lock Washer 8 mm, Stainless | 2 |
| 1 | 207286560 | HEX. SCREW M8 X 65, SCOTCH GRIP Premium | 1 |
| 1 | 267000081 | STEERING NOZZLE, BLACK Premium | 1 |
| 267000183 | Steering Nozzle, Black Base | ||
| 1 | 293900001 | Venturi Bushing Base | 1 |
| 1 | 293900010 | Plastic Bushing Base | 1 |
| 2 | 207383060 | Hex. Screw M8 X 30, Scotch Grip Base | 2 |
| 2 | 211000127 | Socket Head Screw M8 X 10, Scotch Grip Premium | 2 |
| 2 | 293050001 | Flat Washer M8.5 x 18 Base | 2 |
| 2 | 271000122 | Steering Nozzle Sleeve Base | 2 |
