Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 269001254 | Kart Seat Ass'y, Black Includes 1 to 24, Viper Red B-176 | ||
| 269001311 | Yellow, Kart Seat Ass'y Includes 1 to 24, Yellow B-244 | ||
| 269001144 | Seat Base | ||
| 1 | 219902454 | WARNING LABEL, KART SEAT | 1 |
| 1 | 269001167 | KART SEAT PLATE | 1 |
| 2 | 205062560 | Socket Head Screw M6 X 25 | 2 |
| 2 | 234062600 | Flat Washer M6, Stainless | 2 |
| 2 | 232561600 | Hex. Elastic Stop Nut M6 | 2 |
| 269001260 | Seat Ring | ||
| 1 | 293730006 | Black, Dart | 1 |
| 269001157 | RH Seat Corner | ||
| 269001158 | LH Seat Corner | ||
| 6 | 708000006 | Rubber Stopper | 6 |
| 1 | 269001150 | PINE SUPPORT | 1 |
| 4 | 205062560 | Socket Head Screw M6 X 25 | 4 |
| 8 | 234062600 | Flat Washer M6, Stainless | 8 |
| 4 | 232561600 | Hex. Elastic Stop Nut M6 | 4 |
| 1 | 269001149 | PINE | 1 |
| 1 | 269001152 | PINE HANDLE | 1 |
| 1 | 269001151 | PINE SPRING | 1 |
| 1 | 232561600 | Hex. Elastic Stop Nut M6 | 1 |
| 1 | 234061600 | Stainless, Flat Washer M6 | 1 |
| 2 | 234001600 | Flat Washer 10 mm, Stainless | 2 |
| XXXX | Not Available As Spare Part - Velcro 1/2, Black | ||
| 219902477 | BRP Logo, Vinyl | ||
| 269001156 | LATCH BASE | ||
| 204070036 | LATCH COVER | ||
| 269700017 | Latch Spring | ||
| 2 | 207064060 | Hex. Screw M6 X 40 | 2 |
| 2 | 414436900 | Black Snap Cap | 2 |
| 4 | 234061600 | Stainless, Flat Washer M6 | 4 |
| 1 | 291002036 | SEAT HOOK | 1 |
| 2 | 207063560 | Hex. Screw M6 X 35 | 2 |
| XXXX | Not Available As Spare Part - RH Foot Peg Ass'y Includes 38 to 44 | ||
| XXXX | Not Available As Spare Part - LH Foot Peg Ass'y Includes 38 to 44 | ||
| 291002042 | Upper Foot Peg RH | ||
| 291002043 | Upper Foot Peg LH | ||
| 291002123 | Foot Peg Foam RH | ||
| 291002122 | Foot Peg Foam LH | ||
| 4 | 293730006 | Black, Dart | 4 |
| 293850084 | Elastic Rope 4.3 mm | ||
| 291002215 | RH Upper Carpet | ||
| 291002217 | LH Upper Carpet | ||
| 291002216 | RH Lower Carpet | ||
| 291002218 | LH Lower Carpet | ||
| 291002132 | RH Foot Peg Holder | ||
| 1 | 291002131 | LH FOOT PEG HOLDER | 1 |
| 2 | 291001040 | Bumper Plug, Black | 2 |
| 2 | 250000207 | Plastite Torx Screw #10 X 7/8" | 2 |
| 1 | 219704366 | Was 293200062 Seal | 1 |
| 269001261 | Seat Latch | ||
| 2 | 204130095 | BUSHING | 2 |
| 1 | 269001197 | SEAT LATCH SHAFT | 1 |
| 2 | 293370010 | Circlip 7mm | 2 |
| 1 | 269001153 | SEAT LATCH SPRING | 1 |
| 269001164 | SEAT LATCH CAP | ||
| 1 | 293830005 | Rubber Bumper | 1 |
| 293750029 | Cable Clamp | ||
| 2 | 293750030 | HOOK | 2 |
