Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 44190-31J20-YKV | COVER, FUEL TANK CENTER FOR YU1 | ||
| 44190-31J20-YKV | COVER, FUEL TANK CENTER | ||
| 44190-31J20-4TX | COVER, FUEL TANK CENTER FOR YVB | ||
| 44190-31J20-4TX | COVER, FUEL TANK CENTER | ||
| 1 | 44190-31J20-PGZ | (GRAY) FOR AJP | 1 |
| 1 | 44190-31J20-PGZ | (GRAY) | 1 |
| 68120-31J00-BT2 | .TAPE,FUEL TANK COVER,R FOR YU1 | ||
| 68120-31J00-BT3 | .TAPE,FUEL TANK COVER,R FOR YVB | ||
| 1 | 68120-31J00-BT4 | .TAPE,FUEL TANK COVER,R FOR AJP | 1 |
| 44170-31J40-YKV | COVER, FUEL TANK SIDE RH FOR YU1 | ||
| 44170-31J40-YKV | COVER, FUEL TANK SIDE RH | ||
| 44170-31J40-4TX | COVER, FUEL TANK SIDE RH FOR YVB | ||
| 44170-31J40-4TX | COVER, FUEL TANK SIDE RH | ||
| 44170-31J40-PGZ | COVER, FUEL TANK SIDE RH FOR AJP | ||
| 44170-31J40-PGZ | COVER, FUEL TANK SIDE RH | ||
| 68125-31J10-BT2 | .TAPE, FUEL TANK COVER RH FOR YU1 | ||
| 68125-31J10-BT3 | .TAPE, FUEL TANK COVER RH FOR YVB | ||
| 1 | 68125-31J10-BT4 | .TAPE, FUEL TANK COVER RH FOR AJP | 1 |
| 44180-31J40-YKV | (BLACK) FOR YU1 | ||
| 44180-31J40-YKV | (BLACK) | ||
| 44180-31J40-4TX | (BLACK) FOR YVB | ||
| 44180-31J40-4TX | (BLACK) | ||
| 1 | 44180-31J40-PGZ | COVER, FUEL TANK SIDE LH FOR AJP | 1 |
| 1 | 44180-31J40-PGZ | COVER, FUEL TANK SIDE LH | 1 |
| 68135-31J10-BT2 | .TAPE, FUEL TANK COVER LH FOR YU1 | ||
| 68135-31J10-BT3 | .TAPE, FUEL TANK COVER LH FOR YVB | ||
| 1 | 68135-31J10-BT4 | .TAPE, FUEL TANK COVER LH FOR AJP | 1 |
| 1 | 44270-31J00 | COVER, FUEL TANK FRONT RH | 1 |
| 1 | 45517-31J00 | .TAPE, FUEL TANK COVER | 1 |
| 1 | 44280-31J00 | COVER, FUEL TANK FRONT LH | 1 |
| 2 | 44612-13600 | CUSHION (25X35X4) CUT AS REQUIRED | 2 |
| 2 | 44277-01H00 | CUSHION, TANK COVER NO.1 | 2 |
| 2 | 94642-10GA0 | CUSHION (15X15X2) | 2 |
| 2 | 44176-31J00 | CUSHION (5X120X6) | 2 |
| 2 | 44177-31J00 | CUSHION, TANK COVER SIDE NO.2 | 2 |
| 2 | 44178-31J00 | CUSHION (5X180X5) | 2 |
| 3 | 09139-06172 | SCREW (6X10) | 3 |
| 4 | 09139-05074 | BOLT (5X13) | 4 |
| 2 | 09148-05052 | NUT (M5) | 2 |
| 6 | 03241-0516B | SCREW | 6 |
| 1 | 68281-47HA0 | EMBLEM,S | 1 |
| 2 | 09409-08326 | CLIP (10.5X14.3) | 2 |
| 2 | 68111-47HA0 | EMBLEM, S | 2 |
| 4 | 09409-06314 | CLIP (5.9X20.5) | 4 |
| 2 | 44552-24B00 | MOLDING,FUEL TANK (L:110) | 2 |
| 1 | 45289-05H00 | CUSHION,STEERING LOCK | 1 |
| SPECIAL NOTE | COLOR:KEL=YVB(BLACK)/YSF(BLUE) COLOR : | ||
| SPECIAL NOTE | COLOR:KEL=YVB(BLACK)/YSF(BLUE) AJP=YWW(WHITE),YKY(BLUE) |
