Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 277001963 | Steering Column | 1 |
| 1 | 277001653 | Wear Ring | 1 |
| 1 | 277001953 | Gauge Support | 1 |
| 1 | 277001613 | Gauge Support Cover | 1 |
| 1 | 277001630 | Gauge Trim, Black | 1 |
| 1 | 277001904 | Black Steering Pad | 1 |
| 1 | 277001921 | Handle Bar Foam | 1 |
| 1 | 277001626 | Housing Cover LH Package LTD | 1 |
| 1 | 277001860 | Housing Cover LH Package Standard | 1 |
| 1 | 277001887 | Red, Knob Switch | 1 |
| 1 | 277001944 | Throttle Handle | 1 |
| 2 | 293900091 | Bushing | 2 |
| 1 | 241142560 | Hex. Flange Screw K40 X 25 | 1 |
| 1 | 234042600 | Flat Washer 4 mm, Stainless | 1 |
| 1 | 277001945 | Reverse Handle | 1 |
| 1 | 277001625 | Housing Cover RH | 1 |
| 1 | 277001888 | Grey Knob Switch | 1 |
| 2 | 277001863 | Insert Grip Handle | 2 |
| 1 | 277001946 | Deep Black, RH Handle Grip | 1 |
| 1 | 277001958 | Deep Black, LH Handle Grip | 1 |
| 2 | 234062600 | Flat Washer M6, Stainless | 2 |
| 2 | 250000002 | Hex. Screw M6 X 30, Scotch Grip | 2 |
| 2 | 277000203 | Black, Cap | 2 |
| 1 | 277001969 | Steering Cover | 1 |
| 1 | 277002019 | Support Ass'y Includes 460 to 460b | 1 |
| 2 | 269501166 | Nut Housing Ass'y | 2 |
| 1 | 232561200 | Elastic Stop Nut M6, Brass | 1 |
| 1 | 277001654 | Spacer | 1 |
| 2 | 207163560 | Hex. Screw M6 X 35 | 2 |
| 1 | 207064060 | Hex. Screw M6 X 40 | 1 |
| 2 | 234061600 | Stainless Flat Washer M6 | 2 |
| 1 | 277001180 | Ball Joint | 1 |
| 1 | 277001602 | Steering Cable | 1 |
| 1 | 293720083 | Grommet Model with Suspension | 1 |
| 1 | 293830063 | Rubber Washer | 1 |
| 2 | 277001527 | Half Ring | 2 |
| 1 | 277001729 | Steering Cable Lock | 1 |
| 1 | 219704454 | Was 293800013 Loctite 56765 | 1 |
| 1 | 277001582 | Wiper Rod | 1 |
| 1 | 211100056 | Hex. Nut 1/4"-28 | 1 |
| 1 | 277000775 | Ball Joint | 1 |
| 1 | 207063560 | Hex. Screw M6 X 35 | 1 |
| 1 | 277001583 | End Piece | 1 |
| 1 | 234061600 | Stainless Flat Washer M6 | 1 |
| 1 | 277001655 | Thrust Support Ass'y Includes 680 to 680b | 1 |
| 2 | 207165060 | Hex. Screw M6 X 50 | 2 |
| 1 | 277001942 | Steering Support Includes 710 to 710b | 1 |
| 1 | 277001741 | Wear Ring | 1 |
| 2 | 277001605 | Steering Support Pivot | 2 |
| 2 | 207168060 | Hex Screw M6 X 80 | 2 |
| 1 | 277001658 | Handle Ass'y Includes 780 to 780c | 1 |
| 2 | 293830005 | Rubber Bumper | 2 |
| 277001616 | LOCK | ||
| 2 | 277001652 | Pivot | 2 |
| 2 | 207064060 | Hex. Screw M6 X 40 | 2 |
