Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 274001553 | Engine Exhaust Manifold | 1 |
| 12 | 420641198 | Torx Flange Screw M6 X 45 | 12 |
| 2 | 275500664 | Retainer Engine 1503 NA 4-TEC | 2 |
| 1 | 270001002 | Engine Cover Ass'y Engine 1630 ACE HO | 1 |
| 1 | 234082600 | Flat Washer 8 mm, Stainless | 1 |
| 1 | 207382560 | Hex. Screw M8 X 25, Scotch Grip | 1 |
| 1 | 270000886 | Rubber Mount | 1 |
| 3 | 250200018 | Cone Washer | 3 |
| 3 | 250000782 | Hexagonal Head Cap Screw M8 X 45 | 3 |
| 4 | 270000770 | Shim 1.3 mm | 4 |
| 1 | 270000882 | Rubber Mount | 1 |
| 2 | 250200018 | Cone Washer | 2 |
| 2 | 250000782 | Hexagonal Head Cap Screw M8 X 45 | 2 |
| 2 | 270000762 | Shim 1.3 mm | 2 |
| 1 | 273000342 | Airbox Base Engine 1500 HO ACE, 1630 ACE HO | 1 |
| 1 | 273000354 | Airbox Base Engine 1503 NA 4-TEC | 1 |
| 1 | 273000373 | Airbox Cover Engine 1500 HO ACE, 1630 ACE HO | 1 |
| 1 | 273000371 | Airbox Cover Engine 1503 NA 4-TEC | 1 |
| 1 | 273000234 | Breather Valve Engine 1503 NA 4-TEC | 1 |
| 1 | 273000359 | Intake Hose Engine 1500 HO ACE, 1630 ACE HO | 1 |
| 1 | 273000358 | Intake Hose Engine 1503 NA 4-TEC | 1 |
| 273000322 | HOSE CONNECTOR Engine 1500 HO ACE, 1630 ACE HO | ||
| 273000295 | HOSE CONNECTOR Engine 1503 NA 4-TEC | ||
| 2 | 273000290 | Air Silencer Hose | 2 |
| 1 | 219903177 | Air Silencer Notice Decal | 1 |
| 6 | 708000759 | Rubber Stopper | 6 |
| 5 | 250000287 | Flange Torx Screw K40 X 16 | 5 |
| 1 | 270000949 | Formed Hose Engine 1503 NA 4-TEC | 1 |
| 1 | 270000950 | Formed Hose Engine 1500 HO ACE, 1630 ACE HO | 1 |
| 1 | 293650051 | Tridon Gear Clamp | 1 |
| 273000233 | HOSE INTAKE Engine 1500 HO ACE, 1630 ACE HO | ||
| 1 | 293650179 | Tridon Clamp | 1 |
| 1 | 273000328 | Hose Intake, Rear Engine 1500 HO ACE, 1630 ACE HO | 1 |
| 1 | 273000234 | Breather Valve Engine 1500 HO ACE, 1630 ACE HO | 1 |
| 1 | 293650179 | Tridon Clamp Engine 1500 HO ACE, 1630 ACE HO | 1 |
| 1 | 276000335 | Intercooler Engine 1630 ACE HO | 1 |
| 1 | 276000397 | Intercooler Engine 1500 HO ACE | 1 |
| 1 | 271001942 | Anode Zinc | 1 |
| 1 | 273000338 | Inlet Hose Engine 1630 ACE HO | 1 |
| 1 | 273000367 | Inlet Hose Engine 1500 HO ACE | 1 |
| 1 | 293650244 | Tridon Gear Clamp Engine 1500 HO ACE, 1630 ACE HO | 1 |
| 1 | 273000339 | Outlet Hose Engine 1630 ACE HO | 1 |
| 1 | 273000368 | Outlet Hose Engine 1500 HO ACE | 1 |
| 2 | 293850094 | Fuel Tank Strap Engine 1500 HO ACE, 1630 ACE HO | 2 |
| 1 | 293850093 | Fuel Tank Strap Engine 1630 ACE HO | 1 |
| 1 | 293850123 | Fuel Tank Strap Engine 1500 HO ACE | 1 |
| 1 | 293850095 | Fuel Tank Strap Engine 1630 ACE HO | 1 |
| 1 | 293830178 | Pad-Rubber Engine 1500 HO ACE, 1630 ACE HO | 1 |
| 2 | 293730016 | Black, Dart Engine 1500 HO ACE, 1630 ACE HO | 2 |
| 1 | 293750002 | Tie Wrap 142 mm | 1 |
| 2 | 293750002 | Tie Wrap 142 mm Engine 1630 ACE HO | 2 |
