Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 291003897 | Deck Nose | 1 |
| 3 | 241142560 | Hex. Flange Screw K40 X 25 | 3 |
| 3 | 234042600 | Flat Washer 4 mm, Stainless | 3 |
| 1 | 291003096 | Swim Platform Carpet | 1 |
| 1 | 291003573 | Front Carpet LH | 1 |
| 1 | 291003574 | Front Carpet RH | 1 |
| 1 | 291003575 | Front Center Carpet LH | 1 |
| 1 | 291003577 | Rear Center Carpet LH | 1 |
| 1 | 291003576 | Front Center Carpet RH | 1 |
| 1 | 291003578 | Rear Center Carpet RH | 1 |
| 1 | 291003062 | Rear Carpet LH | 1 |
| 1 | 291003063 | Rear Carpet RH | 1 |
| 1 | 293730011 | Black, Dart | 1 |
| 1 | 291004276 | Console | 1 |
| 1 | 293830005 | Rubber Bumper | 1 |
| 3 | 293150123 | Pop Rivet 3/16" | 3 |
| 3 | 293150186 | Pop Rivet 3/16 | 3 |
| 1 | 291004488 | Gulfstream Blue Bezel Ass'y Includes 60 TO 60b | 1 |
| 1 | 291003090 | Mirror RH, With Double-Face Tape | 1 |
| 1 | 291003091 | Mirror LH, With Double-Face Tape | 1 |
| 1 | 291004271 | Deep Black, Mirror Support | 1 |
| 2 | 293150016 | Rivet 1/8" | 2 |
| 2 | 293000014 | Black, Snap Cap | 2 |
| 1 | 292000933 | U-Clamp | 1 |
| 2 | 293050001 | Flat Washer M8.5 x 18 | 2 |
| 1 | 291001386 | Black, Finition Plate | 1 |
| 2 | 234082600 | Flat Washer 8 mm, Stainless | 2 |
| 2 | 232581200 | Hex. Elastic Nut M8 Brass | 2 |
| 1 | 291004625 | Black, Rear Handle Ass'y Includes 470 TO 470f | 1 |
| 1 | 291003877 | Stud Seat | 1 |
| 1 | 232100600 | Hex. Jam Nut M10 | 1 |
| 1 | 234002600 | Flat Washer 10 mm, Stainless | 1 |
| 1 | 269002125 | Seat Stud Spacer | 1 |
| 269002126 | SEAT STUD SUPPORT | ||
| 1 | 232501200 | Elastic Stop Nut M10, Brass | 1 |
| 1 | 219704378 | Gasket 3000Mm Long | 1 |
| 2 | 207065060 | Hex. Screw M6 X 50 | 2 |
| 8 | 234062600 | Flat Washer M6, Stainless | 8 |
| 4 | 232561200 | Elastic Stop Nut M6, Brass | 4 |
| 4 | 207164060 | Hex. Screw M6 X 40 | 4 |
| 2 | 250200022 | Flat Washer M6.6 X 22 | 2 |
| 1 | 269502140 | Deep Black, Glove Door Ass'y Includes 840 TO 840b | 1 |
| 1 | 264000091 | Black, Latch | 1 |
| 1 | 293250236 | Gasket | 1 |
| 8 | 293730006 | Black, Dart | 8 |
| 1 | 269502284 | Blue RH Cosmetic Panel | 1 |
| 1 | 269502285 | Blue LH Cosmetic Panel | 1 |
| 4 | 211000023 | Hex. Screw 10-14 X 7/8” | 4 |
| 1 | 291004277 | Front Bumper | 1 |
| 2 | 250000399 | Hexagonal Cap Screw M6 X35 | 2 |
| 291004451 | Black, Side Bumper Cut to desired length if needed | ||
| 1 | 291004278 | Black, Corner Bumper | 1 |
| 1 | 291004279 | Black, Corner Bumper | 1 |
| 291004451 | Black, Side Bumper | ||
| 6 | 250001007 | Screw Torx M6.81 X 30 | 6 |
| 1 | 291004572 | Divider Ass'y | 1 |
| 1 | 269502111 | Holding Strap | 1 |
| 1 | 291004273 | Deep Black, Body Deflector | 1 |
