Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 269502481 | Perforated Upper Hood Includes 10 to 10a | 1 |
| 1 | 269502394 | Outer Skin | 1 |
| 3 | 250000399 | Hexagonal Cap Screw M6 X35 | 3 |
| 1 | 269502555 | Inner Skin | 1 |
| 1 | 269502267 | LH Latch | 1 |
| 1 | 269502536 | Pin | 1 |
| 1 | 269502268 | Latch Spring | 1 |
| 1 | 293830005 | Rubber Bumper | 1 |
| 1 | 269502299 | RH Latch | 1 |
| 1 | 277002322 | DESS Key Support | 1 |
| 1 | 250001196 | Plastite Torx Screw #10 X 7/8" | 1 |
| 1 | 269502426 | Shock Absorber Assembly Includes 150 to 150b | 1 |
| 2 | 269501984 | Shock Absorber End Fitting | 2 |
| 1 | 269502274 | LH Mirror Glass | 1 |
| 1 | 269502427 | Deep Black, LH Mirror Cover | 1 |
| 1 | 269502551 | Echo Sounder Support | 1 |
| 1 | 269502375 | Deep Black, Echosounder Deflector | 1 |
| 2 | 293830005 | Rubber Bumper | 2 |
| 1 | 269502385 | LH Latch Base | 1 |
| 3 | 250000827 | Screw-Torx Truss Cone HD.M6X50 | 3 |
| 1 | 269502386 | RH Latch Base | 1 |
| 1 | 269502450 | Upper Windshield Trim | 1 |
| 2 | 250001144 | Plastite Torx Screw Cone HD. M6.81X | 2 |
| 1 | 269502505 | Shock Absorber HPG | 1 |
| 1 | 232581200 | Hex. Elastic Nut M8 Brass | 1 |
| 1 | 234082600 | Flat Washer 8 mm, Stainless | 1 |
| 1 | 250001225 | Torx Screw M8 X 30 | 1 |
| 2 | 269801254 | Rubber Stopper | 2 |
| 1 | 269801253 | Molded Guide | 1 |
| 2 | 250000466 | Torx Screw Plastite M6 | 2 |
| 2 | 250001230 | Socket Head Screw M6 X 50 | 2 |
| 2 | 269502544 | Nut Housing M6 | 2 |
| 1 | 269801275 | Windshield Ass'y | 1 |
| 1 | 269502526 | Joint | 1 |
| 2 | 269502529 | Joint | 2 |
| 1 | 269801090 | Windshield Support | 1 |
| 1 | 269801117 | Central Pivot Arm | 1 |
| 6 | 250001231 | Plastite Torx Screw M6.81X25 | 6 |
| 1 | 269801251 | Windshield Latch | 1 |
| 2 | 250001231 | Plastite Torx Screw M6.81X25 | 2 |
| 2 | 269801250 | Socket | 2 |
| 2 | 205464060 | Socket Screw M6 X 40 | 2 |
| 1 | 269801309 | Air Deflector | 1 |
| 1 | 250001231 | Plastite Torx Screw M6.81X25 | 1 |
| 1 | 269502282 | Shock Base | 1 |
| 3 | 250000879 | Plastite Torx Screw M6.81X30 | 3 |
| 1 | 264000144 | Bin Compartment | 1 |
| 3 | 250001138 | Plastite Screw Torx Cone HD.M6.81X3 | 3 |
| 2 | 250000879 | Plastite Torx Screw M6.81X30 | 2 |
| 1 | 293250478 | Gasket | 1 |
| 2 | 269502325 | Adjustment Hook | 2 |
| 3 | 269502493 | Strap | 3 |
| 1 | 264000132 | Glove Box Door | 1 |
| 1 | 264000133 | Glove Box Latch | 1 |
| 1 | 250001119 | Screw K40 X 10 | 1 |
| 1 | 293250403 | Gasket | 1 |
| 1 | 269502538 | Glove Box Trim | 1 |
| 1 | 293150230 | Tuflok Plastic Rivet | 1 |
| 1 | 264000158 | Box Cover | 1 |
| 2 | 269501718 | Clip | 2 |
| 1 | 293250591 | Gasket | 1 |
| 1 | 264000135 | Sealed Compartment Foam | 1 |
| 1 | 264000137 | Vent Membrane | 1 |
| 1 | 250000399 | Hexagonal Cap Screw M6 X35 | 1 |
| 1 | 211000023 | Hex. Screw 10-14 X 7/8” | 1 |
