Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 710005842 | Voltage Regulator | 1 |
| 1 | 278003012 | Starter Relay | 1 |
| 515179081 | 12 VOLT 18AH Battery Includes 340 to 340a | ||
| 1 | 250000282 | Battery Bolt Kit | 1 |
| 4 | 293150123 | Pop Rivet 3/16" | 4 |
| 1 | 278003473 | Battery Support | 1 |
| 1 | 293850095 | Fuel Tank Strap | 1 |
| 2 | 232561200 | Elastic Stop Nut M6, Brass | 2 |
| 1 | 295100710 | USB Charger Cable Ass'y Includes 1020 to 1020a | 1 |
| 1 | 710005857 | Connector USB wih Cable | 1 |
| 1 | 295100710 | USB Charger Cable Ass'y | 1 |
| 1 | 250000399 | Hexagonal Cap Screw M6 X35 | 1 |
| 1 | 278003451 | Ground Battery Cable | 1 |
| 1 | 207361260 | Hex. Screw M6 X 12, Scotch Grip | 1 |
| 1 | 234061600 | Stainless Flat Washer M6 | 1 |
| 1 | 278003369 | Starter Cable | 1 |
| 1 | 232561200 | Elastic Stop Nut M6, Brass | 1 |
| 1 | 278002284 | LH Throttle Sensor | 1 |
| 3 | 207361260 | Hex. Screw M6 X 12, Scotch Grip | 3 |
| 3 | 234061600 | Stainless Flat Washer M6 | 3 |
| 3 | 278003564 | Retainer | 3 |
| 1 | 278004097 | Full Size Multifunction Color Gauge | 1 |
| 1 | 278003899 | External GPS Module | 1 |
| 2 | 250000399 | Hexagonal Cap Screw M6 X35 | 2 |
| 1 | 278003976 | Bent Deflector | 1 |
| 1 | 278002283 | Throttle Position Sensor | 1 |
| 1 | 278003821 | Switch | 1 |
| 1 | 278003474 | RH Switch Keypad | 1 |
| 1 | 515179239 | Terminal_Dess One-Wire Open | 1 |
| 1 | 278002963 | Safety Nut (DESS Switch) | 1 |
| 1 | 278003684 | Multiple Accessory Harness Not Shown | 1 |
| 1 | 278003734 | Connectors Support Not Shown | 1 |
| 1 | 211000023 | Hex. Screw 10-14 X 7/8” | 1 |
| 1 | 295100975 | Echo Sounder Switch Kit | 1 |
| 1 | 278003974 | Echo Sounder Wiring Harness Includes 3010 to 3010a | 1 |
| 1 | 278003975 | Power Supply Cable | 1 |
| 293830193 | Polyurethane Hose | ||
| 1 | 293730040 | Mount Dart | 1 |
| 1 | 295100972 | Transducer Includes 3050 to 3050a | 1 |
| 1 | 292002447 | Seal | 1 |
| 1 | 278003982 | Echo sounder Wiring Harness | 1 |
| 1 | 278004018 | Pump Wiring Harness Includes 3200 to 3200d | 1 |
| 1 | 515178954 | Housing | 1 |
| 3 | 278004017 | Switch | 3 |
| 3 | 515177246 | Shrink Tubing, 6 mm | 3 |
| 1 | 278003996 | Module Minuterie | 1 |
| 278004142 | Switch Trim | ||
| 1 | 278003538 | O.T.A.S. Sensor | 1 |
| 1 | 278003986 | Seat Wiring Harness | 1 |
| 1 | 278004014 | Battery Support | 1 |
| 4 | 293150186 | Pop Rivet 3/16 | 4 |
| 2 | 207162060 | Hex. Forming Screw M6 X 20 | 2 |
| 2 | 250200114 | Sealing Washer | 2 |
| 2 | 234062600 | Flat Washer M6, Stainless | 2 |
| 515179081 | 12 VOLT 18AH Battery Includes 3340 to 3340a | ||
| 1 | 278004007 | Secondary Battery Wiring Harness | 1 |
| 1 | 278004030 | Support Régulateur De Tension | 1 |
| 1 | 207362060 | Hex. Screw M6 X 20, Scotch Grip | 1 |
| 1 | 278003400 | Safety Lanyard Ass'y, RFID | 1 |
