Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 3 | 234042600 | Flat Washer 4 mm, Stainless | 3 |
| 3 | 241142560 | Hex. Flange Screw K40 X 25 | 3 |
| 291002818 | DECK NOSE | ||
| 1 | 291004291 | Carpet | 1 |
| 1 | 291003580 | LH Front Carpet Model RXT 260, RXT 260 RS | 1 |
| 291004285 | ANTI SLIP MAT FL Model RXT-X 300, RXT-X RS 300 | ||
| 291003581 | ANTI SLIP MAT FR Model RXT 260, RXT 260 RS | ||
| 291004286 | ANTI SLIP MAT FR Model RXT-X 300, RXT-X RS 300 | ||
| 291004299 | ANTI SLIP MAT CTRL L Model RXT 260, RXT 260 RS | ||
| 291004287 | ANTI SLIP MAT CTRL L Model RXT-X 300, RXT-X RS 300 | ||
| 1 | 291004300 | Carpet Model RXT 260, RXT 260 RS | 1 |
| 291004288 | ANTI SLIP MAT CTRL R Model RXT-X 300, RXT-X RS 300 | ||
| 1 | 291004289 | Carpet | 1 |
| 1 | 291004290 | Carpet | 1 |
| 1 | 291004336 | Carpet | 1 |
| 1 | 291004337 | Carpet | 1 |
| 291004295 | LH SPACER | ||
| 291004296 | RH SPACER | ||
| 6 | 250000879 | Plastite Torx Screw M6.81X30 | 6 |
| 293250259 | GASKET | ||
| 293250365 | NEOPRENE SEAL | ||
| 293250200 | NEOPRENE SEAL | ||
| 3 | 293730010 | Black Dart | 3 |
| 219704381 | SEAL 1000MM LONG | ||
| 1 | 291004595 | Front Module | 1 |
| 269002893 | CASE | ||
| 2 | 293150123 | Pop Rivet 3/16" | 2 |
| 291004210 | SEAT PIVOT | ||
| 4 | 293150123 | Pop Rivet 3/16" | 4 |
| 8 | 243163560 | Plastite Hex. Screw M6.8 X 35 | 8 |
| 8 | 234082600 | Flat Washer 8 mm, Stainless | 8 |
| 1 | 291002626 | LH Nonskid | 1 |
| 291002937 | RH NONSKID | ||
| 2 | 293150016 | Rivet 1/8" | 2 |
| 2 | 293000014 | Black, Snap Cap | 2 |
| 1 | 292000933 | U-Clamp | 1 |
| 1 | 291002351 | Hook | 1 |
| 1 | 291001386 | Black, Finition Plate | 1 |
| 2 | 234082600 | Flat Washer 8 mm, Stainless | 2 |
| 2 | 232581200 | Hex. Elastic Nut M8 Brass | 2 |
| 1 | 291004622 | Black Rear Handle Model RXT-X Dragon Red | 1 |
| 1 | 291004622 | Black Rear Handle Model RXT 260, RXT 260 RS | 1 |
| 291004624 | REAR HANDLE ASSY Model RXT-X White | ||
| 1 | 291003878 | Seat Stud | 1 |
| 1 | 232100600 | Hex. Jam Nut M10 | 1 |
| 1 | 234002600 | Flat Washer 10 mm, Stainless | 1 |
| 1 | 271001732 | Elastic Nut M10 Housing | 1 |
| 1 | 219704378 | Gasket 3000Mm Long | 1 |
| 4 | 207065560 | Hex. Screw M6 x 55 | 4 |
| 4 | 234062600 | Flat Washer M6, Stainless | 4 |
| 2 | 232561200 | Elastic Stop Nut M6, Brass | 2 |
| 2 | 207164060 | Hex. Screw M6 X 40 | 2 |
| 4 | 250200022 | Flat Washer M6.6 X 22 | 4 |
| 291002947 | LOWER DECK ASS'Y Includes 750 to 750c | ||
| 4 | 269501166 | Nut Housing Ass'y | 4 |
| 219903184 | CAUTION ENGINE OIL | ||
| 291004234 | FRONT RH COSMETIC ASS Model RXT-X Dragon Red | ||
| 291004434 | FRONT RH COSMETIC ASS Model RXT-X White | ||
| 291004612 | FRONT RH COSMETIC ASS Model RXT 260, RXT 260 RS | ||
| 1 | 291004235 | Front LH Cosmetic Ass Model RXT-X Dragon Red | 1 |
| 291004435 | FRONT LH COSMETIC ASS Model RXT-X White | ||
| 291004613 | FRONT LH COSMETIC ASS Model RXT 260, RXT 260 RS | ||
| 291004170 | LH COSMETIC Model RXT-X Dragon Red | ||
| 291004535 | LH COSMETIC Model RXT 260, RXT 260 RS | ||
| 291004560 | LH Cosmetic Model RXT-X White | ||
| 291004171 | RH COSMETIC Model RXT-X Dragon Red | ||
| 291004536 | RH COSMETIC Model RXT 260, RXT 260 RS | ||
| 291004561 | RH COSMETIC Model RXT-X White | ||
| 1 | 291004275 | Front Bumper | 1 |
| 3 | 250000399 | Hexagonal Cap Screw M6 X35 | 3 |
| 1 | 291004274 | Rear Bumper | 1 |
| 4 | 250000399 | Hexagonal Cap Screw M6 X35 | 4 |
| 291004451 | Black, Side Bumper | ||
| 4 | 291002744 | Bumber Cap | 4 |
| 2 | 513033435 | Grommet | 2 |
| 2 | 414523600 | Elbow Fitting | 2 |
| 1 | 219704356 | Was 275500008 Hose 12 mm | 1 |
| 2 | 293750001 | Tie Wrap 94 mm | 2 |
| 291002756 | FRONT REWINDER CAP | ||
| 291004194 | FOOTREST RH Model RXT-X 300, RXT-X RS 300 | ||
| 4 | 250000710 | Torx Screw M6 X 3 Model RXT-X 300, RXT-X RS 300 | 4 |
| 291004195 | FOOTREST LH Model RXT-X 300, RXT-X RS 300 |
