Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 204390361 | HELM ASS'Y Single HO Engine Models | ||
| 277000384 | WOODRUFF KEY | ||
| 277000383 | Support Single HO Engine Models | ||
| 211000050 | HEX. SCREW 1/4-20 X 3/4?, SCOTCH GRIP Single HO Engine Models | ||
| 3 | 234062600 | Flat Washer M6, Stainless Single HO Engine Models | 3 |
| 3 | 234481608 | Serrated Lock Washer 8 mm Single HO Engine Models | 3 |
| 1 | 207065060 | Hex. Screw M6 X 50 Single HO Engine Models | 1 |
| 2 | 207164060 | Hex. Screw M6 X 40 Single HO Engine Models | 2 |
| 6 | 234061600 | Stainless Flat Washer M6 Single HO Engine Models | 6 |
| 3 | 232561600 | Hex. Elastic Stop Nut M6 Single HO Engine Models | 3 |
| 204390577 | HELM FASCIA Single HO Engine Models | ||
| 4 | 204100058 | Phillips Tapping Screw Single HO Engine Models | 4 |
| 277001868 | SHIM STEERING Single HO Engine Models | ||
| 204390543 | Steering Wheel Ass'y 210 CHALL | ||
| 204390549 | CENTER CAP 210 CHALL | ||
| 211200006 | FLAT WASHER, STAINLESS Single HO Engine Models | ||
| 211100021 | LOCK NUT 1/2-20 Single HO Engine Models | ||
| 2 | 293730040 | Mount Dart | 2 |
| 277001693 | THROTTLE CABLE | ||
| 2 | 293750002 | Tie Wrap 142 mm | 2 |
| 1 | 277001694 | SENSOR BRACKET | 1 |
| XXXX | Not Available As Spare Part - Cotter Pin | ||
| XXX | Not Available As Spare Parts | ||
| 1 | 277001727 | SENSOR_POSITION THROTTLE | 1 |
| 1 | 270000544 | O-Ring | 1 |
| 2 | 205455060 | SOCKET HEAD SCREW M5 X 50 | 2 |
| 204390638 | SPACER | ||
| 3 | 207152060 | Hex. Screw M5 X 20 | 3 |
| 3 | 234052600 | Flat Washer 5 mm, Stainless | 3 |
| 277000458 | CABLE SUPPORT Single HO Engine Models | ||
| 2 | 211200025 | Lock Washer 1/4” Single HO Engine Models | 2 |
| 211100024 | LOCK NUT Single HO Engine Models | ||
| 1 | 234001600 | Flat Washer 10 mm, Stainless Single HO Engine Models | 1 |
| 1 | 293350014 | Flanged Bushing Single HO Engine Models | 1 |
| 277000461 | PIVOT 3/8? Single HO Engine Models | ||
| 204390053 | HEX. JAM NUT 5/8-18 Single HO Engine Models | ||
| 204390465 | STEERING CABLE Single HO Engine Models | ||
| 277000456 | PIVOT Single HO Engine Models | ||
| 277000439 | HEX. NUT 5/16-24 Single HO Engine Models | ||
| 204130095 | BUSHING Single HO Engine Models | ||
| 211200019 | FLAT WASHER Single HO Engine Models | ||
| 212000005 | NUT-STOP ELASTIC MS-17830 Single HO Engine Models | ||
| 211000054 | HEX. SCREW 1/4-20 X 1?, SCOTCH GRIP Single HO Engine Models | ||
| 1 | 211200025 | Lock Washer 1/4” Single HO Engine Models | 1 |
| 1 | 234062600 | Flat Washer M6, Stainless Single HO Engine Models | 1 |
| 204390040 | ARM Single HO Engine Models | ||
| 277000440 | SEAL SWIVEL | ||
| 1 | 277000441 | Terminal Wiper | 1 |
| 1 | 204120074 | BALL JOINT | 1 |
| 1 | 207063560 | Hex. Screw M6 X 35 | 1 |
| 1 | 234061600 | Stainless Flat Washer M6 | 1 |
| 1 | 232561600 | Hex. Elastic Stop Nut M6 | 1 |
