Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 17210-MFN-D02 | ELEMENT, AIR CLEANER | 1 |
| 1 | 17213-MFG-D03 | RESONATOR, AIR CLEANER | 1 |
| 1 | 17215-MFG-D03 | RESONATOR, R. AIR DUCT | 1 |
| 1 | 17216-MFG-D00 | TUBE, AIR CLEANER RESONATOR | 1 |
| 1 | 17218-MFG-D00 | TUBE, R. AIR DUCT RESONATOR | 1 |
| 1 | 17219-MFN-L60 | CLAMP, BREATHER TUBE | 1 |
| 1 | 17225-MFN-D01 | FUNNEL, R. AIR CLEANER | 1 |
| 1 | 17226-MFN-D01 | FUNNEL, L. AIR CLEANER | 1 |
| 1 | 17229-MFG-D00 | SEAL, R. AIR CLEANER DUCT | 1 |
| 1 | 17235-MFN-D01 | DUCT, L. AIR CLEANER | 1 |
| 1 | 17236-MFG-D02 | DUCT, R. AIR CLEANER | 1 |
| 1 | 17238-MW4-003 | DIAPHRAGM, CONTROL VALVE | 1 |
| 1 | 17240-MFN-D00 | CASE A, AIR CLEANER | 1 |
| 1 | 17241-MFA-D00 | SEAL A, AIR CLEANER | 1 |
| 1 | 17242-MFN-D00 | SEAL, AIR CLEANER HOUSING | 1 |
| 2 | 17243-MFA-D00 | SEAL, AIR CLEANER | 2 |
| 1 | 17244-MFA-D00 | SEAL, AIR CLEANER DUCT | 1 |
| 1 | 17250-MFN-D00 | CASE B, AIR CLEANER | 1 |
| 1 | 17260-MFN-L60 | COVER, AIR CLEANER | 1 |
| 1 | 17261-MFN-D00 | STAY, CHAMBER | 1 |
| 1 | 17358-MZ8-G20 | TUBE, DRAIN | 1 |
| 1 | 17554-MFN-D00 | TUBE, BREATHER | 1 |
| 1 | 32123-MFN-D00 | STAY, VACUUM TANK | 1 |
| 1 | 36138-PR7-A01 | FILTER ASSY., SOLENOID VALVE | 1 |
| 1 | 36163-PV0-004 | VALVE ASSY., BYPASS CONTROL SOLENOID | 1 |
| 1 | 36625-P0A-A01 | TANK, VACUUM | 1 |
| 1 | 37830-MEL-003 | SENSOR ASSY., MAP | 1 |
| 1 | 37880-P05-A00 | SENSOR ASSY., AIR TEMPERATURE | 1 |
| 2 | 50352-GS6-000 | RUBBER, LINK STOPPER | 2 |
| 1 | 90111-KFB-000 | NUT, SPECIAL (6X1.0) | 1 |
| 1 | 90114-MEL-000 | SCREW, SPECIAL (5X11) | 1 |
| 2 | 90646-657-000 | CLIP, AIR HOSE (16MM) | 2 |
| 1 | 91303-PK2-005 | O-RING (7.5X1.5) (Honda Code 2684819) | 1 |
| 6 | 91508-MM5-000 | SCREW, PAN (5MM) | 6 |
| 1 | 93404-06030-08 | BOLT-WASHER (6X30) | 1 |
| 1 | 93500-05016-0A | SCREW, PAN (5X16) | 1 |
| 3 | 93901-25420 | SCREW, TAPPING (5X20) | 3 |
| 1 | 93903-24480 | SCREW, TAPPING (4X16) | 1 |
| 3 | 93903-25280 | SCREW, TAPPING (5X12) | 3 |
| 2 | 93903-25380 | SCREW, TAPPING (5X16) | 2 |
| 3 | 93903-25480 | SCREW, TAPPING (5X20) | 3 |
| 8 | 93903-25580 | SCREW, TAPPING (5X25) | 8 |
| 1 | 93913-24220 | SCREW, TAPPING (4X12) | 1 |
| 2 | 93913-25420 | SCREW, TAPPING (5X16) | 2 |
| 1 | 94050-06070 | NUT, FLANGE (6MM) | 1 |
| 1 | 94103-05000 | WASHER, PLAIN (5MM) | 1 |
| 1 | 95002-41250-00 | CLAMP, TUBE (D12.5) | 1 |
| 1 | 95005-35001-20M | BULK HOSE, VACUUM (3.5X1000) (3.5X130) (BULK HOSE: 95005-35008-10M) | 1 |
| 1 | 95005-35008-10M | BULK HOSE, VACUUM (3.5X8000) (3.5X1000) | 1 |
| 1 | 95701-06012-07 | BOLT, FLANGE (6X12) | 1 |
| 1 | 96001-06012-07 | BOLT, FLANGE (6X12) (L. SIDE ONLY) | 1 |
