Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 274000927 | Head Pipe Includes 1 - 5. | ||
| 1 | 293710037 | Male Connector | 1 |
| 293710048 | Elbow Fitting 90° | ||
| 293700016 | Elbow Fitting | ||
| 1 | 293710021 | Male Connector | 1 |
| 1 | 219704454 | Was 293800013 Loctite 56765 | 1 |
| 274000658 | Exhaust Cone | ||
| 250300008 | STUD M10 X 5.1 X 55, SCOTCH GRIP | ||
| 1 | 211200051 | Flat Washer | 1 |
| 1 | 233101600 | Hex. Flange Nut M10 | 1 |
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 3 | 244003560 | SOCKET HEAD SCREW M10 X 35, SCOTCH GRIP | 3 |
| 3 | 211200051 | Flat Washer | 3 |
| 1 | 420931990 | EXHAUST GASKET | 1 |
| 274000862 | PICK UP ENVELOPE | ||
| 1 | 293750002 | Tie Wrap 142 mm | 1 |
| 1 | 274000839 | Rubber Isolator | 1 |
| 1 | 274000511 | SEALING RING | 1 |
| 1 | 293800090 | Sealant, Loctite, 80 ml | 1 |
| 274000510 | EXHAUST CLAMP | ||
| 1 | 219704412 | Polyurethane Hose 8 MM 3000MM Long | 1 |
| 274000890 | Pipe Support | ||
| 3 | 244083060 | Socket Head Screw M8 X 30, Scotch Grip | 3 |
| 3 | 250200012 | FLAT WASHER M8.4 | 3 |
| 1 | 245004060 | HEX. SCREW M10 X 40, SCOTCH GRIP | 1 |
| 1 | 234002600 | Flat Washer 10 mm, Stainless | 1 |
| 274000861 | BUSHING | ||
| 293830065 | RUBBER BUSHING | ||
| 274000777 | Pipe Support | ||
| 2 | 244083060 | Socket Head Screw M8 X 30, Scotch Grip | 2 |
| 2 | 250200012 | FLAT WASHER M8.4 | 2 |
| 1 | 244004060 | Hex. Screw M10 X 40, Scotch Grip | 1 |
| 274000896 | Exhaust Hose | ||
| 2 | 293650064 | Tridon Clamp | 2 |
| 274000948 | Expension Tube | ||
| 274001053 | Muffler | ||
| 274000811 | Front Muffler Cover | ||
| 274000812 | Rear Muffler Cover | ||
| 1 | 293750020 | WRAP_TIE 828 X 9 | 1 |
| 2 | 293850021 | Rubber Strap | 2 |
| 293850076 | STRAP CLIP 90 | ||
| 2 | 293850024 | STRAP CLIP | 2 |
| 8 | 293150037 | Avdel Rivet 3/16" | 8 |
| 293830089 | Rubber Pad | ||
| 4 | 414644300 | Black, Dart | 4 |
| 1 | 278001016 | Temperature Sensor | 1 |
| 1 | 219704456 | Était/Was 293800038 Loctite 518, 50 ml | 1 |
| 1 | 274001055 | EXHAUST HOSE | 1 |
| 1 | 293650064 | Tridon Clamp | 1 |
| 1 | 293650107 | Tridon Clamp | 1 |
| 1 | 274000700 | LH UPPER RESONATOR | 1 |
| 293850026 | Fuel Tank Strap Includes 57 - 58. | ||
| 1 | 293850024 | STRAP CLIP | 1 |
| 4 | 293150037 | Avdel Rivet 3/16" | 4 |
| XXXX | Not Available As Spare Part - Foam pad | ||
| 1 | 293730006 | Black, Dart | 1 |
| 274000784 | Adapter Hose | ||
| 1 | 204000079 | Tridon Clamp | 1 |
| 1 | 274000843 | Exhaust Outlet | 1 |
| 1 | 274000835 | NUT 72 MM | 1 |
| 274000225 | STABILIZING WASHER | ||
| 1 | 293250041 | GASKET | 1 |
| 1 | 296000309 | Silicone Sealant 51388, 300 ml | 1 |
| 1 | 293250107 | GASKET | 1 |
| 1 | 274000892 | SUPPORT NUT | 1 |
| 4 | 241141660 | Hex. Flange Screw K40 X 16 | 4 |
| 1 | 274000885 | BRACKET | 1 |
