Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 270000573 | Rotax Engine 947-Di Includes 1 - 17. | ||
| 707000031 | Adaptor Ass'y Includes 2 - 6. | ||
| 1 | 270000137 | Female Connector, 6 Circuits | 1 |
| 270000138 | Adaptor | ||
| 293300033 | Gasket | ||
| 293200055` | Gasket | ||
| 1 | 293710066 | MALE CONNECTOR | 1 |
| 1 | 278000987 | Starter Ass'y | 1 |
| 273000123 | Silencer Support | ||
| 2 | 205063560 | Socket Head Screw M6 X 35 | 2 |
| 2 | 234061600 | Stainless, Flat Washer M6 | 2 |
| 2 | 234161601 | Lock Washer Helical M6 | 2 |
| 1 | 278001662 | GROUND PLATE | 1 |
| 293700016 | Elbow Fitting | ||
| 293710082 | STRAIGHT FITTING | ||
| 205003060 | Socket Screw M10 X 30 | ||
| 2 | 232001600 | HEX. NUT M10 | 2 |
| 1 | 219704454 | Was 293800013 Loctite 56765 | 1 |
| 293550010 | Synthetic Grease, 400 G | ||
| 1 | 293800005 | Loctite 271, 10 ml | 1 |
| 4 | 207184060 | Hex. Screw M8 X 40 | 4 |
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 4 | 234081600 | Stainless, Flat Washer 8 mm | 4 |
| 270000122 | Shim 0.3 mm | ||
| 270000123 | SHIM 1.3 MM | ||
| 5 | 205582560 | Socket Head Screw M8 X 25, Scotch Grip | 5 |
| 5 | 234081600 | Stainless, Flat Washer 8 mm | 5 |
| 2 | 270000453 | BUSHING | 2 |
| 270000421 | Rubber Mount, Black | ||
| 2 | 234082600 | Flat Washer 8 mm, Stainless | 2 |
| 207181660 | Hex. Screw M8 X 16 | ||
| 270000515 | Engine Support, Black | ||
| 207182060 | HEX. SCREW M8 X 20 | ||
| 1 | 234082600 | Flat Washer 8 mm, Stainless | 1 |
| 1 | 270000025 | SHIM 1.3 MM | 1 |
| 3 | 270000024 | SHIM 0.4 MM | 3 |
| 270000430 | Rubber Mount, Black | ||
| 2 | 207184060 | Hex. Screw M8 X 40 | 2 |
| 2 | 234081600 | Stainless, Flat Washer 8 mm | 2 |
| 2 | 278001650 | Spark Plug NGK Zfr4f-11 . | 2 |
| 1 | 278001016 | Temperature Sensor | 1 |
| 1 | 219704456 | Était/Was 293800038 Loctite 518, 50 ml | 1 |
| 1 | 270600040 | Pressure Sensor | 1 |
| 1 | 270600019 | VALVE ADAPTOR | 1 |
| 1 | 243041660 | HEX. PLASTITE SCREW M5.28 X 16 | 1 |
| 1 | 211200035 | Flat Washer | 1 |
| 1 | 270600000 | AIR TEMPERATURE SENSOR | 1 |
| 1 | 270000484 | Noise Sensor | 1 |
| 1 | 207183060 | Hex. Screw M8 X 30 | 1 |
| 3 | 414115200 | Tie-Rap 180 mm | 3 |
| 3 | 293730018 | Mount Dart | 3 |
| 270600058 | Throttle Body Includes 51 - 76. | ||
| 1 | 270600069 | LOWER SUPPORT | 1 |
| 270600070 | Support Ass'y Includes 53 - 54. | ||
| 1 | 270600073 | LATCH BRACKET | 1 |
| 11 | 205051060 | Socket Head Screw M5 X 10 | 11 |
| 1 | 270600074 | ADJUSTER SCREW | 1 |
| 270600075 | Spring | ||
| 1 | 270600076 | PRIMARY THROTTLE BODY Includes 58 - 66. | 1 |
| 270600077 | Throttle Lever Ass'y | ||
| 2 | 270600078 | POTENTIOMETER SCREW M4 | 2 |
| 1 | 234161601 | Lock Washer Helical M6 | 1 |
| 1 | 232061600 | Hex. Nut M6 | 1 |
| 2 | 270600079 | GUIDE SPRING | 2 |
| 270600080 | Spring | ||
| 1 | 270000251 | Position Sensor Includes 65 - 66. | 1 |
| 1 | 270000544 | O-Ring | 1 |
| 1 | 270600081 | SECONDARY THROTTLE BODY Includes 67 - 75. | 1 |
| 270600082 | Pick-Up Lever | ||
| 270600083 | Spring | ||
| 1 | 270000251 | Position Sensor Includes 74 - 75. | 1 |
| 1 | 270600084 | IDLE SCREW | 1 |
| 270600085 | Cover, Loctite Ultra Grey | ||
| 1 | 270000546 | Injection Cable Includes 78 - 80. | 1 |
| 3 | 232160600 | Hex. Nut M6 | 3 |
| 4 | 234061600 | Stainless, Flat Washer M6 | 4 |
| 1 | 277001197 | THROTTLE CABLE | 1 |
| 1 | 277000279 | TAB LOCK | 1 |
| 293250065 | O-Ring | ||
| 1 | 278001512 | INSULATOR | 1 |
| 2 | 293650079 | Norma Clamp | 2 |
| 6 | 278000631 | Male Terminal | 6 |
| 1 | 219704453 | Was 293550004 Dielectric Grease, 150 g | 1 |
| 1 | 278000735 | Female Lock, 6 Circuits | 1 |
