Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 278001732 | STEERING HARNESS ASSY Includes 1 - 11. | 1 |
| 1 | 278000736 | Male Connector, 6 Circuits | 1 |
| 6 | 278000632 | Female Terminal | 6 |
| 1 | 278000737 | MALE LOCK, 6 CIRCUITS | 1 |
| 278001586 | BUZZER | ||
| 278001733 | START/STOP SWITCH | ||
| 1 | 278001734 | Emergency Switch | 1 |
| 1 | 278001755 | SET/MODE SWITCH | 1 |
| 1 | 278000635 | Female Housing, 4 Circuits | 1 |
| 4 | 278000631 | Male Terminal | 4 |
| 1 | 278000636 | Female Wedge, 4 Circuits | 1 |
| 1 | 278000508 | Safety Switch Nut | 1 |
| 278001702 | Cluster Harness Ass’Y Includes 13 - 25. | ||
| 1 | 409015900 | Female Terminal Housing, 12 Circuits | 1 |
| 1 | 409015700 | Female Lock, 12 Circuits | 1 |
| 1 | 278000739 | Male Connector, 4 Circuits | 1 |
| 1 | 278000738 | Male Lock, 4 Circuits | 1 |
| 16 | 278000632 | Female Terminal | 16 |
| 278000890 | FEMALE CONNECTOR, 4 CIRCUITS | ||
| 1 | 278000217 | Female Housing, 2 Circuits | 1 |
| 6 | 278000218 | Wire Seal | 6 |
| 6 | 278000222 | Male Terminal | 6 |
| 1 | 515175588 | FEMALE TERMINAL HOUSING, 2 CIRCUITS | 1 |
| 2 | 278000998 | Female Terminal | 2 |
| 2 | 278000999 | Wire Seal | 2 |
| 2 | 293750026 | Tie Rap Mount | 2 |
| 2 | 414115200 | Tie-Rap 180 mm | 2 |
| 2 | 241141360 | Hex. Flange Screw K40 X 13 | 2 |
| 278001607 | Main Harness Includes 29 - 71. | ||
| 278000993 | Male Connector, 26 Circuits Includes 30 - 31. | ||
| 1 | 278001307 | WIRE SEAL | 1 |
| 278000995 | FEMALE TERMINAL | ||
| 2 | 409011700 | FEMALE TERMINAL | 2 |
| 278001223 | Seal | ||
| 278000996 | WIRE SEAL | ||
| 3 | 278000994 | FEMALE TERMINAL | 3 |
| 278001062 | Male Terminal Housing, 26 Circuits Includes 37 - 38. | ||
| 1 | 409013900 | SEAL | 1 |
| 13 | 293000070 | SEALING CAP | 13 |
| 4 | 278001392 | Open Barrel Terminal | 4 |
| 1 | 278001473 | Female Terminal Housing, 4 Circuits | 1 |
| 2 | 515175260 | FEMALE TERMINAL | 2 |
| 1 | 278001474 | Female Lock, 4 Circuits | 1 |
| 1 | 278000220 | Male Connector, 2 Circuits | 1 |
| 5 | 278000223 | Female Terminal | 5 |
| 5 | 278000218 | Wire Seal | 5 |
| 13 | 278000632 | Female Terminal | 13 |
| 1 | 293000052 | Sealing Cap | 1 |
| 1 | 278001673 | Female Terminal Housing, 2 Circuits | 1 |
| 1 | 278001671 | Female Lock, 2 Circuits | 1 |
| 2 | 515175567 | Female Terminal | 2 |
| 1 | 409207000 | Male Housing, 3 Circuits | 1 |
| 1 | 409207600 | Male Lock, 3 Circuits | 1 |
| 11 | 278000631 | Male Terminal | 11 |
| 1 | 270000137 | Female Connector, 6 Circuits | 1 |
| 1 | 278000735 | Female Lock, 6 Circuits | 1 |
| 2 | 278000739 | Male Connector, 4 Circuits | 2 |
| 2 | 278000738 | Male Lock, 4 Circuits | 2 |
| 1 | 278001308 | MALE CONNECTOR, 4 CIRCUITS | 1 |
| 4 | 278001114 | Female Terminal | 4 |
| 1 | 278000273 | Male Housing, 3 Circuits | 1 |
| 1 | 409207400 | Female Housing, 3 Circuits | 1 |
| 1 | 409207200 | Female Lock | 1 |
| 3 | 278000632 | Female Terminal | 3 |
| 278001751 | MALE HOUSING, 41 CIRCUITS | ||
| 11 | 278001750 | Female Terminal | 11 |
| 278001752 | Female Terminal | ||
| 1 | 219704453 | Was 293550004 Dielectric Grease, 150 g | 1 |
| 1 | 293550015 | Deoxit Lubricant, Spray | 1 |
| 1 | 278001543 | Safety Lanyard | 1 |
