Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 6 | 293150013 | Pop Rivet 3/16" | 6 |
| 291001592 | Rear Carpet (Black) | ||
| 291001593 | RH Rear Carpet | ||
| 291001594 | LH Rear Carpet | ||
| 7 | 293150015 | Pop Rivet 1/8” | 7 |
| 2 | 269500716 | FINITION PLATE | 2 |
| 1 | 293450223 | RH INSERT | 1 |
| 1 | 293450224 | LH INSERT | 1 |
| 2 | 516000983 | Bombardier Logo | 2 |
| 80 | 293150036 | RIVET_POP 1/8 X ,750 | 80 |
| 2 | 291001505 | Bumper Corner, Black | 2 |
| 1 | 291001483 | Rear Bumper, Black | 1 |
| 291001612 | REAR BUMPER TRIM GTX DI 5563/5564. | ||
| 291001540 | Rear Bumper Trim GTX DI 5595/5596. | ||
| 291001610 | SIDE BUMPER TRIM GTX DI 5563/5564. | ||
| 291001763 | Side Bumper Trim GTX DI 5595/5596. | ||
| 2 | 291001609 | Side Bumper, Black | 2 |
| 2 | 291001040 | Bumper Plug, Black | 2 |
| 60 | 293150005 | Pop Rivet 3/16" | 60 |
| 4 | 211000021 | PHILLIPS SCREW #10 X 7/8 | 4 |
| 87 | 293000014 | Black, Snap Cap | 87 |
| 4 | 234052600 | Flat Washer 5 mm, Stainless | 4 |
| 1 | 296000309 | Silicone Sealant 51388, 300 ml | 1 |
| 292000685 | DRAIN ASSY | ||
| 2 | 232581650 | Elastic Stop Nut M8 | 2 |
| 1 | 291001386 | Black, Finition Plate | 1 |
| 1 | 291001232 | Hook | 1 |
| 6 | 291000339 | Bumper Plug, Black | 6 |
| 291001853 | Retainer Plate | ||
| 1 | 269500931 | RH GRILL, BLACK | 1 |
| 1 | 269500932 | LH GRILL, BLACK | 1 |
| 3 | 293730006 | Black, Dart | 3 |
| 2 | 293150011 | Pop Rivet 3/16" | 2 |
| 1 | 211400008 | Pin | 1 |
| 2 | 211100002 | Push Nut | 2 |
| 1 | 269500553 | Latch, Black | 1 |
| 211000037 | Phillips Screw 10-14 X 7/8” | ||
| 291001519 | Bumper Plug, Black | ||
| 291001035 | NOSE BUMPER, BLACK | ||
| 1 | 269501031 | Cover Trim, Black | 1 |
| 1 | 269500968 | GLOVE BOX | 1 |
| 1 | 292000011 | U-CLAMP | 1 |
| 1 | 291001758 | RH ANTI-SKID | 1 |
| 291001759 | LH Anti-Skid | ||
| 2 | 232361600 | Nut M6 | 2 |
| 292000778 | Stair Tube Ass’Y Includes 40 - 41. | ||
| 1 | 292000781 | PROTECTIVE SLEEVE | 1 |
| 6 | 250000076 | Socket Head Screw M6 X 25, Scotch Grip | 6 |
| 6 | 234062600 | Flat Washer M6, Stainless | 6 |
| 1 | 219704460 | Was 293800066 Sealant Loctite 5900, 300 ml | 1 |
| 292000539 | Support Ass’Y | ||
| 292000540 | RH Support Cap | ||
| 292000548 | LH Support Cap | ||
| 2 | 292000541 | RECALL SPRING | 2 |
| XXXX | Not Available As Spare Part - Plastic Tube | ||
| 211000186 | Phillips Screw | ||
| 211100061 | NUT-LOCKING 1/4-20 | ||
| 2 | 205063560 | Socket Head Screw M6 X 35 | 2 |
| 1 | 293800060 | Loctite 243, 10 ml | 1 |
| 291001595 | RH Center Carpet | ||
| 291001596 | LH Center Carpet | ||
| 291001597 | RH Front Carpet | ||
| 291001598 | LH Front Carpet | ||
| 269501135 | Glove Box Door GTX DI 5563/5564. | ||
| 269501144 | Box Door GTX DI 5595/5596. | ||
| 1 | 291000922 | Latch Spring | 1 |
| 293250126 | GASKET | ||
| 293250127 | GASKET | ||
| 269501036 | Rear Tray | ||
| 293250008 | GASKET PAC = 1.0m | ||
| 1 | 269000788 | COVER | 1 |
| 1 | 269000810 | COVER SEAL | 1 |
| 295500783 | Owners Tool Kit | ||
| 14 | 293150036 | RIVET_POP 1/8 X ,750 | 14 |
| 4 | 241141660 | Hex. Flange Screw K40 X 16 | 4 |
| 4 | 293730006 | Black, Dart | 4 |
| 2 | 293730010 | Black Dart | 2 |
