Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 60711175033 | Main wiring harness R cpl. | 1 |
| 1 | 60711085000 | Wiring harness | 1 |
| 1 | 60311079000 | WIRING HARNESS HEAD LIGHT | 1 |
| 1 | 60311076000 | REAR WIRING HARNESS | 1 |
| 1 | 60311053050 | BATTERIE HOUSING | 1 |
| 1 | 60341031050 | ECU RUBBER BRACKET | 1 |
| 1 | 61341031300 | Control unit EFI | 1 |
| 1 | 60311057050 | BRACKET ELECTRIC | 1 |
| 1 | 60416031000 | ELECTRONIC CONTROL UNIT SAFE | 1 |
| 1 | 58211058000 | STARTER RELAY 12V '99 '99 | 1 |
| 2 | 0024060136 | HH collar screw M6x13 TX30 TX30 | 2 |
| 1 | 60342090000 | SLOPING POSITIONS SENSOR | 1 |
| 3 | 62142041000 | DAMP. COMPONENT ABS MODUL | 3 |
| 2 | 69008021160 | special screw M5x12 | 2 |
| 1 | 60711048000 | Connector support front | 1 |
| 1 | 60411078050 | Wiring harness | 1 |
| 3 | 0738060201 | FLAT HEAD SCREW ISO7380 M6X20 | 3 |
| 3 | 76508043050 | COLLAR BUSHING | 3 |
| 1 | 60711033050 | Rubber band | 1 |
| 1 | 60711060033 | Direct current horn complete | 1 |
| 1 | 58011109140 | FUSE 40 A As Required | 1 |
| 1 | 58011109130 | FUSE 30 A As Required | 1 |
| 1 | 58011109125 | FUSE 25 A As Required | 1 |
| 1 | 58011109115 | FUSE 15 A As Required | 1 |
| 1 | 58011109110 | FUSE 10 A 2000 2000, As Required | 1 |
| 1 | 60316029000 | RUBBER EDS-CONTROL UNIT | 1 |
| 2 | 0902060083 | AH OVAL SCREW ISO 7380 M 6X8 | 2 |
| 1 | 60711066000 | Ignition lock Race-on 868MHz | 1 |
| 2 | 0025080306S | HH COLLAR SCREW M8X30 TX40 TX40 | 2 |
| 2 | 0021080003 | WASHER DIN9021-A 8,4 | 2 |
| 1 | 60311059050 | BATTERIE CABLE | 1 |
| 1 | 60711042050 | Cable | 1 |
| 1 | 60714013033B2 | Power socket complete silver | 1 |
| 1 | 60711033000 | Control unit MCU 3.0 | 1 |
| 1 | 69011168000 | Antenna keyless | 1 |
| 1 | 60708019010 | Support | 1 |
| 4 | 0081050181 | SCREW FOR PLASTIC K50X18 T20 | 4 |
| 1 | 60312032000 | RECEIVER AIR PRESSURE SENSOR | 1 |
| 7 | 0081050121 | EJOT PT screw K50x12 | 7 |
| 1 | 60311047000 | CABLE CHANNEL R/S | 1 |
| 1 | 60711042000 | Power socket 12V | 1 |
| 60311049200 | Plug board rear | ||
| 1 | 60311034000 | VOLTAGE REGULATOR | 1 |
| 2 | 0025060206 | HH collar screw M6x20 TX30 TX30 | 2 |
| 1 | 60342090040 | BRACKET SLOPING POSITIONS SENS | 1 |
| 1 | 60011053000 | BATTERY 12V/11AH 03 | 1 |
| 1 | 60308017000 | BATTERIE COVER | 1 |
| 1 | 61041085050 | RUBBER SUPP. PRESSURE SENS. 05 | 1 |
| 1 | 60311040100 | BRACKET PRESSURE SENSOR | 1 |
| 1 | 0023060123 | COLLAR SCREW M6X12 TX | 1 |
| 2 | 60007020040 | PLASTIC WASHER 03 | 2 |
| 2 | 0025050126 | HH collar screw M5x12 TX30 TX30 | 2 |
| 2 | 54603048200 | RANGE CHANGE METAL NUT M5 | 2 |
| 1 | 58411087050 | RUBBERCOVER F.LOCKHOLDER | 1 |
| 1 | 61111018100 | TEMPERATURE SENSOR | 1 |
| 1 | 44011076140 | CABLE TIE 140/2,5MM BLACK As Required | 1 |
| 1 | 44011076200 | CABLE TIE 200/3,6MM BLACK As Required | 1 |
| 1 | 44011076305 | CABLE TIE 300/4,8MM BLACK As Required | 1 |
| 1 | 60011093045 | RUBBER CABLE TIE 45MM 03 As Required | 1 |
| 1 | 60011093060 | RUBBER CABLE TIE 60MM 03 As Required | 1 |
| 1 | 60011093075 | RUBBER CABLE TIE 75MM 03 As Required | 1 |
| 1 | 60711057050 | Retaining bracket | 1 |
| 2 | 61111057000 | RELAY CM1A-R-12V-H80 07 | 2 |
| 1 | 60311046000 | CABLE CHANNEL L/S | 1 |
| 1 | 60311097000 | GROUND CABLE | 1 |
