Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 72531001044 | CARBURETOR KEIH. PWK28 | 1 |
| 1 | 54631245000 | STARTER PISTON CPL. | 1 |
| 1 | 72530061000 | CLAMP 45/12 GEMI | 1 |
| 1 | 54531607040 | IDLE JET 40 KEIHIN | 1 |
| 1 | 54531607042 | IDLE JET 42 KEIHIN As Required | 1 |
| 1 | 54531607045 | IDLE JET 45 KEIHIN As Required | 1 |
| 1 | 54531607048 | IDLE JET 48 KEIHIN As Required | 1 |
| 1 | 54531607050 | IDLE JET 50 KEIHIN As Required | 1 |
| 1 | 57331008000 | ARM PIN FLOAT | 1 |
| 1 | 47031009000 | FLOAT CPL. PWK28 03 03 | 1 |
| 1 | 47031010000 | FLOAT CHAMBER GASKET | 1 |
| 1 | 72531011000 | FLOAT CHAMBER COMP. ASSY 14 | 1 |
| 1 | 54531612100 | RETAINING PLATE FOR BLEEDER | 1 |
| 1 | 0770180230 | O-RING 18,00X2,30 NBR 70 | 1 |
| 1 | 54531699000 | PLUG M 18X1 | 1 |
| 1 | 54531615000 | SPRING FOR ADJUSTMENT SCREW | 1 |
| 1 | 54531617000 | ADJUSTMENT SCREW | 1 |
| 1 | 54631118000 | SPRING | 1 |
| 1 | 54631219100 | ADJUSTMENT SCREW M 5 | 1 |
| 1 | 47031020000 | FLOAT NEEDLE CPL. | 1 |
| 1 | 72531022000 | NEEDLE JET HOLDER 14 14 | 1 |
| 1 | 54531621000 | CLAMP | 1 |
| 1 | 54531623110 | MAIN JET 110 KEIHIN | 1 |
| 1 | 54531623115 | MAIN JET 115 KEIHIN As Required | 1 |
| 1 | 54531623118 | MAIN JET 118 KEIHIN As Required | 1 |
| 1 | 54531623120 | MAIN JET 120 KEIHIN As Required | 1 |
| 1 | 54531623122 | MAIN JET 122 KEIHIN As Required | 1 |
| 1 | 54531623125 | MAIN JET 125 KEIHIN As Required | 1 |
| 1 | 54531623128 | MAIN JET 128 KEIHIN As Required | 1 |
| 1 | 54531623130 | MAIN JET 130 KEIHIN As Required | 1 |
| 1 | 52031126000 | HEXAGON NUT M 6X0,75 DIN0439 | 1 |
| 1 | 47031027000 | CARBURETOR COVER PWK28 03 03 | 1 |
| 1 | 47031028000 | CARBURETOR COVER GASKET PWK28 | 1 |
| 1 | 54531629000 | CLIP FOR JET NEEDLE | 1 |
| 1 | 47031030000 | THROTTLE VALVE SPRING | 1 |
| 1 | 47031031000 | SPRING CAP | 1 |
| 1 | 72531034000 | JET NEEDLE KEIHIN JJK As Required | 1 |
| 1 | 72531034100 | JET NEEDLE KEIHIN JJJ As Required | 1 |
| 1 | 72531034200 | JET NEEDLE KEIHIN JJH | 1 |
| 1 | 72531034300 | JET NEEDLE KEIHIN JJG As Required | 1 |
| 1 | 72531034400 | JET NEEDLE KEIHIN JJF As Required | 1 |
| 1 | 72531034500 | JET NEEDLE KEIHIN JJE As Required | 1 |
| 1 | 47031035000 | THROTTLE VALVE 3,5 | 1 |
| 2 | 31007007101 | PVC-HOSE 4X6MM | 2 |
| 4 | 0016040163 | HH COLLAR SCREW M 4X16 WS=6 | 4 |
| 3 | 54531696000 | CLAMP 6 MM | 3 |
| 1 | 72531021000 | NEEDLE JET 14 As Required, 14 | 1 |
