Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 11 | 7519112 | SCR-TXTH-M6X1.0X20 T40 ZPB | 11 |
| 5452092-293 | DOOR PANEL, OUTER, FRONT, LEFT, [A7] [SUBS TO 5453818-293, REQUIRES INNER PANEL PN 5453822-070] | ||
| 1 | 5452448-266 | DOOR PANEL OUTER FRONT LEFT CR. [AE] | 1 |
| 5452448-689 | PANEL-DOOR,OUT,FRT,LH,V.BLU [AV] | ||
| 1 | 5452093-293 | DOOR PANEL OUTER FRONT RIGHT IN [A7] | 1 |
| 1 | 5452449-266 | OUTER DOOR PANEL FRONT RIGHT HA [AE] | 1 |
| 1 | 5452449-689 | DOOR PANEL, OUTER, RIGHT, VELOC [AV] | 1 |
| 1 | 7082008 | ASM-HANDLE,DOOR,RELEASE,LH,OTR | 1 |
| 1 | 7082017 | ASM-HANDLE,DOOR,RELEASE,RH,OTR | 1 |
| 4 | 7519091 | SCR-#10X1/2-HI/LO-PN-T25,TRX-M | 4 |
| 13 | 7547674 | U-TYPE NUT, M6-1.0 | 13 |
| 1 | 5633422 | FRAME-DOOR,CAST,LH [TO 4/8/16] | 1 |
| 1 | 5633423 | FRAME-DOOR,CAST,RH [TO 4/8/16] | 1 |
| 1 | 5633704 | FRAME-DOOR,CAST,LH [FROM 4/8/16] | 1 |
| 1 | 5633705 | FRAME-DOOR,CAST,RH [FROM 4/8/16] | 1 |
| 1 | 5261425 | BRKT-DOOR LATCH MNT,LH [IF BUILT BEFORE 11/6/15 AND AFTER 1/31/16] | 1 |
| 1 | 5261426 | BRKT-DOOR LATCH MNT,RH [IF BUILT BEFORE 11/6/15 AND AFTER 1/31/16] | 1 |
| 1 | 5262827-329 | BRKT-DOOR LATCH,LH,ECOAT [IF BUILT 11/7/15 - 1/30/16] | 1 |
| 1 | 5262828-329 | BRKT-DOOR LATCH,RH,ECOAT [IF BUILT 11/7/15 - 1/30/16] | 1 |
| 1 | 5338879 | ROD-LATCH,LH | 1 |
| 1 | 5338880 | LATCH ROD, RIGHT | 1 |
| 1 | 7082103 | ROTARY LATCH ASSEMBLY, LEFT | 1 |
| 1 | 7082104 | LATCH ASSEMBLY, ROTARY, RIGHT | 1 |
| 12 | 7518576 | HEX FLANGE SCREW, 6 MM X 20 MM [TO 4/25/16] | 12 |
| 10 | 7518576 | HEX FLANGE SCREW, 6 MM X 20 MM [FROM 4/25/16] | 10 |
| 8 | 7547453 | HEX FLANGE NUT, 6 MM X 1.0 MM | 8 |
| 1 | 5339134 | ROD-LATCH,DOOR,INNER,LH | 1 |
| 1 | 5339135 | DOOR LATCH ROD, INNER, RIGHT | 1 |
| 2 | 7082081 | DOOR HANDLE ASSEMBLY, INNER [IF BUILT BEFORE 1/30/16] | 2 |
| 2 | 7082216 | DOOR HANDLE ASSEMBLY, INNER [IF BUILT AFTER 1/31/16] | 2 |
| 1 | 5452094-070 | DOOR PANEL INNER FRONT LEFT GLO [TO 2/26/16] | 1 |
| 1 | 5453497-070 | DOOR PANEL INNER FRONT LEFT GLO [FROM 2/27/16] | 1 |
| 1 | 5452095-070 | DOOR PANEL INNER FRONT RIGHT GL [TO 2/26/16] | 1 |
| 1 | 5453498-070 | DOOR PANEL INNER FRONT RIGHT GL [FROM 2/27/16] | 1 |
| 1 | 5452290-070 | DOOR TRIM, INNER, LEFT, GLOSS B | 1 |
| 1 | 5452291-070 | DOOR TRIM, INNER, RIGHT, GLOSS | 1 |
| 12 | 7519045 | TORX SCREW, #14 X 3/4 | 12 |
| 4 | 5452517-070 | DOOR HINGE MOUNT COVER, GLOSS B | 4 |
| 4 | 5633461-329 | CAST DOOR HINGE, BLACK [IF BUILT BEFORE 12/14/15] | 4 |
| 4 | 5633642-329 | CAST DOOR HINGE, BLACK [IF BUILT AFTER 12/15/15][TO 8/3/16] | 4 |
| 2 | 5263231-329 | CAST DOOR HINGE, BLACK [FROM 8/3/16] | 2 |
| 8 | 7518576 | HEX FLANGE SCREW, 6 MM X 20 MM | 8 |
| 2 | 7518613 | BOLT-M6X1.0X20,HXFLG,OLIVE D | 2 |
| 2 | 5510789 | SEAL-DOOR [IF BUILT BEFORE 11/6/15] | 2 |
| 2 | 5510895 | DOOR SEAL [IF BUILT AFTER 11/7/15] | 2 |
| 1 | 5452292-070 | GRAB HANDLE DOOR, RIGHT BLACK [IF BUILT BEFORE 1/30/16] | 1 |
| 1 | 5452904-070 | GRAB HANDLE DOOR, RIGHT BLACK | 1 |
| 2 | 7518348 | SCR-SOCHD,M6X50,0600084 [IF BUILT BEFORE 12/7/15] | 2 |
| 2 | 7520482 | SCR-SH-M6X1.0X50 8.8 RIE [IF BUILT AFTER 12/8/15] | 2 |
| 4 | 5262743-329 | DOOR CLAMP BRACKET, BLACK | 4 |
| 2 | 7081305 | U-CLIP SPEED NUT | 2 |
| 2 | 7518613 | BOLT-M6X1.0X20,HXFLG,OLIVE D [FROM 4/25/16] | 2 |
| 2 | 7082214 | SPRING-EXT,9.14 OD X 25.4 [IF BUILT 11/6/15 - 1/30/16] | 2 |
| 2 | 7518280 | SCREW, 1/4-20 X .75 TORX [IF BUILT AFTER 11/7/15] | 2 |
| 4 | 7517301 | SOCKET HEAD SCREW, 6 MM X 30 MM [IF BUILT 11/6/15 - 1/30/16] | 4 |
| 4 | 7546703 | NYLOK NUT [IF BUILT 11/6/15 - 1/30/16] | 4 |
