Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 6010701324420A | FUEL TANK L/S CPL. WHITE 09 09 | ||
| 6010711323320A | FUEL TANK R/S CPL. WHITE 08 08 | ||
| 4 | 60007024000 | CONNECT.PIECE F.OVERFLOW M7 03 03 | 4 |
| 4 | 60007024050 | GASKET FOR CONNECTING PIECE 03 03 | 4 |
| 2 | 58507003000 | FUEL COCK CPL. SM. RALLYE'96 '96 | 2 |
| 2 | 0770020130 | O-RING 1,78x10,82x14,38 2-013 | 2 |
| 6 | 0025060126 | HH collar screw M6x12 TX30 TX30 | 6 |
| 1 | 58207080000 | GAS-LEVEL SENSOR ADV. 2002 2002 | 1 |
| 2 | 0912050163 | AH SCREW DIN0912-M 5X16 | 2 |
| 60107020051 | COVER PUSH BUTTON | ||
| 1 | 60107020052 | PUSH BUTTON | 1 |
| 2 | 60107020053 | COIL SPRING | 2 |
| 1 | 60107020054 | PUSH BUTTON SUPPORT | 1 |
| 2 | 60007062000 | BEAR.BUSH.INSIDE L=15,5MM 03 03 | 2 |
| 12 | 60007065000 | TANK RUBBER BUSHING 03 03 | 12 |
| 6 | 60007060000 | BEARING BUSHING OUTSIDE 03 03 | 6 |
| 4 | 0912080553 | AH SCREW DIN912 M8X55 | 4 |
| 8 | 0984060163 | AH SCREW DIN6912-M 6X16 | 8 |
| 2 | 0912080503 | AH SCREW DIN912 M8X50 | 2 |
| 2 | 60007061000 | BEARING BUSHING INSIDE 03 03 | 2 |
| 2 | 0912080403 | SHCS DIN 912 M8x40 | 2 |
| 2 | 60007008051 | SEAL. FLANGE F.TANK INSERT 03 03 | 2 |
| 2 | 60007008150 | TANK INSERT 05 05 | 2 |
| 2 | 60007008052 | SEAL. RING F. TANK INSERT 03 03 | 2 |
| 2 | 60007108000 | TANK PLUG | 2 |
| 6 | 0912050303 | AH SCREW DIN0912-M 5X30 | 6 |
| 6 | 0912050083 | SHCS DIN 912 M5x8 | 6 |
| 2 | 0912050123 | AH SCREW DIN0912-M 5X12 | 2 |
| 2 | 58031005000 | CLAMP YDNAC 10128 12MM | 2 |
| 60011057000 | HOSE HOLDER TRIPLE 03 03 | ||
| 4 | 0081050181 | SCREW FOR PLASTIC K50X18 T20 | 4 |
| 2 | 57013072100 | WIRING HOLDER 16MM | 2 |
| 1 | 55011022100 | CLAMP D=6/8MM, BLACK | 1 |
| 60107013050 | TANK PROTECTOR L/S 06 06 | ||
| 1 | 60107113050 | TANK PROTECTOR R/S 06 06 | 1 |
| 1 | 60007095100 | THERMAL PROTECT. FOIL TANK 07 07 | 1 |
| 1 | 60007216640 | HOSE 6X13 L=640 MM 09 09 | 1 |
| 1 | 78015019000 | HOSE EPA D=6/10 L=2000MM (As required) | 1 |
| 1 | 60107023000 | STORAGE BOX BOTTOM PART | 1 |
| 2 | 0081030103 | SCREW K30X10 T10 | 2 |
| 2 | 0081030163 | SCREW K30X16 T10 | 2 |
| 1 | 6010701900033 | STOR.BOX CENT.PART BLACK 09 09 | 1 |
| 1 | 60107020070 | COVER GASKET | 1 |
| 6 | 60007020040 | PLASTIC WASHER 03 03 | 6 |
| 1 | 6010702000033 | COVER FOR STORAGE BOX 09 09 | 1 |
| 60107019082 | LOCK BOLT STORAGE COMPARTMENT | ||
| 60107019080 | SUPPORT F. LOCK BOLT | ||
| 60107032000 | STORAGE BOX CABLE | ||
| 1 | 58312085100 | EDGE PROTECTOR PER METER (As required) | 1 |
| 1 | 6000704020030 | SEAT BLACK 05 05 | 1 |
| 1 | 6000704025030 | SEAT COVER BLACK 05 05 | 1 |
| 6010804100033C | SIDE COVER L/S REAR BLACK 09 09 | ||
| 6010804200033C | SIDEPART RI. BACK BLACKMATT 09 09 | ||
| 1 | 60008041150 | THER.PROT.FOIL SI. CO. L/S 07 07 | 1 |
| 1 | 60008042150 | THER.PROT.FOIL SI. COV. R/S 07 07 | 1 |
| 8 | 60008045000 | SPECIAL WASHER D=16,5MM 03 03 | 8 |
| 1 | 60107053000 | RUBBER SLEEVE F.SEAT LOCK 09 09 | 1 |
| 2 | 41001052000 | RUBBER SLEEVE D=12MM | 2 |
| 2 | 60012008002 | COLLAR BUSHING 8,2X12X20X9 03 03 | 2 |
| 6 | 0017060203 | EJOT PT SCREW K60X20 WS=6 WS=6 | 6 |
| 60107050000 | SEAT LOCK | ||
| 2 | 0738060301 | COU.SUNK SCR. AH ISO7380 M6X30 | 2 |
| 60008013050 | DISTANCE BUSH. 7X12X18X3,7 03 03 | ||
| 1 | 40011166100 | KEY BLANK LC4/DUKE/LC8 (As required) | 1 |
| 40011166150 | KEY MILLED (As required) | ||
| 1 | 60107023080 | STORAGE COVER BOX SPRING | 1 |
