Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 504154090 | Gearbox Case Ass'y | 1 |
| 1 | 504154136 | Plate Ass'y | 1 |
| 5 | 233261434 | Flange Elastic Nut M6 | 5 |
| 3 | 293150148 | Rivet Magna-Grip 6,4 X 50,8 | 3 |
| 3 | 293150149 | Collar Huck Magna-Grip 6.4 | 3 |
| 1 | 504082900 | Washer | 1 |
| 1 | 250000740 | Torx Screw M8 X 20, Scotch Grip | 1 |
| 2 | 233261434 | Flange Elastic Nut M6 | 2 |
| 1 | 293200168 | Oil Seal | 1 |
| 1 | 504153686 | Sprocket 23 Teeth | 1 |
| 1 | 293370133 | External Snap Ring | 1 |
| 1 | 293350131 | Ball Bearing | 1 |
| 1 | 504153793 | Oil Deflector | 1 |
| 2 | 207561644 | Hex. Flange Screw M6 X 16, Scotch Grip | 2 |
| 2 | 234061410 | Flat Washer 6 mm | 2 |
| 1 | 504154125 | Shaft Gearbox In Ass'y Includes 600 to 600b | 1 |
| 1 | 293370055 | Circlip | 1 |
| 1 | 504154126 | Shaft Gearbox Selection Ass'y | 1 |
| 1 | 504154127 | Shaft Gearbox Out Ass'y | 1 |
| 1 | 293350053 | Ball Bearing | 1 |
| 1 | 293350115 | Ball Bearing | 1 |
| 1 | 293350117 | Ball Bearing | 1 |
| 1 | 504153165 | Ball Bearing | 1 |
| 1 | 293200159 | Oil Seal | 1 |
| 1 | 293350059 | Ball Bearing | 1 |
| 1 | 504152582 | Circlip | 1 |
| 1 | 504154108 | Sprocket 45 Teeth Includes 1130 to 1130a | 1 |
| 1 | 504152572 | Circlip | 1 |
| 1 | 293300201 | O-Ring | 1 |
| 1 | 504154019 | Magnetic Cap Includes 1160 to 1160a | 1 |
| 1 | 504154043 | Cap | 1 |
| 1 | 504153679 | Drive Chain 96 Links | 1 |
| 1 | 414575600 | Hair Pin | 1 |
| 1 | 504153627 | Adjustment Screw | 1 |
| 1 | 250500012 | Allen Drive Plug 1/8-27 PTF | 1 |
| 1 | 504153704 | Magnetic Plug | 1 |
| 1 | 293300202 | O-Ring | 1 |
| 1 | 267000469 | Black, Plastic Plug | 1 |
| 1 | 504153559 | Tensioner | 1 |
| 1 | 504153312 | Slider Chain | 1 |
| 1 | 293370105 | Circlip | 1 |
| 1 | 414036300 | Grommet | 1 |
| 1 | 207588544 | Hex. Flange Screw M8 X 85, Scotch Grip | 1 |
| 1 | 504153937 | Gearbox Cover Ass'y Includes 1700 to 1700c | 1 |
| 1 | 504152896 | Rotation Sensor | 1 |
| 1 | 515178223 | Clip Connector | 1 |
| 1 | 415130141 | Braided Sleeve | 1 |
| 1 | 293300197 | O Ring | 1 |
| 12 | 250001012 | Torx T-30 Pan HD Taptite M6X20 | 12 |
| 1 | 414580700 | Male Connector | 1 |
| 1 | 250001015 | Hex. Flange Screw M6 X 35 | 1 |
| 1 | 504153662 | Speed Selector Support | 1 |
| 2 | 207562034 | Hex. Flange Screw M6 X 20, Scotch Grip | 2 |
| 1 | 207584544 | Hex. Flange Screw M8 X 45, Scotch Grip | 1 |
| 1 | 504153648 | Spacer | 1 |
| 1 | 207664544 | Hex. Flange Screw M6 X 45 | 1 |
| 1 | 504153593 | Actuating Rod Ass'y | 1 |
| 1 | 504154100 | Axle Fork | 1 |
| 1 | 504154101 | Fork | 1 |
| 2 | 250400045 | Spring Pin M5 X 16 | 2 |
| 1 | 207563034 | Hex. Flange Screw M6 X 30, Scotch Grip | 1 |
| 1 | 233261414 | Hex. Flange Elastic Nut M6 x 1.0 | 1 |
| 2 | 504153735 | Bushing | 2 |
| 1 | 504153664 | Extrusion | 1 |
| 1 | 707000965 | Lever Button | 1 |
| 1 | 232180491 | Hex. Jam Nut M8 | 1 |
| 1 | 504154013 | Threaded Bar | 1 |
| 1 | 504153984 | Lever Arm Spring | 1 |
| 1 | 504153977 | Ball Joint | 1 |
| 2 | 232081414 | Hex. Nut M8 | 2 |
| 1 | 504153695 | Bearing Housing Ass'y Includes 2500 to 2500a | 1 |
| 1 | 250300028 | Clinch Stud, M8 X 25 | 1 |
| 1 | 233281414 | Hex. Flange Elastic Nut M8 | 1 |
| 1 | 504153980 | Plate | 1 |
| 1 | 707000310 | Spring | 1 |
| 1 | 207664044 | Hex. Flange Screw M6 X 40 | 1 |
| 1 | 504153981 | Sapcer | 1 |
| 1 | 504154177 | Drive Axle Ass'y Track 1,5 pitch | 1 |
| 1 | 504154001 | Drive Axle Ass'y Track 1,8 pitch | 1 |
| 1 | 504153886 | Retaining Ring | 1 |
| 1 | 504153973 | Track 20'' X 154'' X 1.5'' TR20X154X1.5CST | 1 |
| 1 | 504153974 | Track 20'' X 154'' X 1.5'' TR20X154X1.5ICST | 1 |
| 1 | 504154041 | Track 20'' X 154'' X 1.8'' TR20X154X1.8CST8 | 1 |
| 1 | 415129528 | Track Guide | 1 |
| 1 | 415129529 | Cleat | 1 |
| 1 | 250000764 | Hex. Button Head Screw M8 X 1.25 X 35 | 1 |
