Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 17936-921-000 | WASHER, PIVOT | 1 |
| 17940-ZV4-013 | SEE PART DETAILS - PRI; CABLE, NEUTRAL STARTING | ||
| 1 | 17951-921-030 | KNOB, CHOKE | 1 |
| 17953-921-010 | GUIDE, CHOKE KNOB | ||
| 18221-ZV4-000 | PLATE, EX. | ||
| 18222-ZV4-000 | BAND, EX. SEAL | ||
| 1 | 18231-ZV4-000ZA | SEE PART DETAILS - SUP; COVER, EX. CHAMBER *NH8* (DARK GRAY) Use up to Frame SN 1400056. | 1 |
| 18231-ZV4-010ZA | SEE PART DETAILS - PRI; COVER, EX. CHAMBER *NH8* (DARK GRAY) Use from Frame SN 1400057. | ||
| 18232-ZV4-000 | PLATE, EX. CHAMBER Use up to Frame SN 1400056. | ||
| 18232-ZV4-010 | PLATE, EX. CHAMBER Use from Frame SN 1400057. | ||
| 18233-ZV4-610 | SEE PART DETAILS - PRI; GASKET, EX. CHAMBER | ||
| 24210-ZV4-650 | SPRING, CLICK | ||
| 1 | 24221-ZV4-010 | SEE PART DETAILS - PRI; SPRING, CLICK ASSIST | 1 |
| 1 | 24611-ZV4-000 | SHAFT, SHIFT | 1 |
| 24612-ZV4-000 | ARM, SHIFT | ||
| 24613-ZV4-010 | ROD, LINK | ||
| 24614-ZV4-651 | LEVER, SHIFT | ||
| 1 | 24615-ZV4-030 | LINK A, SHIFT | 1 |
| 24616-ZV4-000 | LINK, SHIFT (B) | ||
| 1 | 24621-ZV4-010 | BUSH, SHAFT | 1 |
| 24623-ZV4-650 | RUBBER, SHIFT SHAFT | ||
| 32114-ZV4-000 | BRACKET, WIRE HARNESS CLIP | ||
| 35150-ZV4-812 | SWITCH ASSY., STARTER (STATIONARY PTO SWITCH) | ||
| 1 | 37210-ZV4-003 | SEE PART DETAILS - PRI; LAMP ASSY., INDICATOR | 1 |
| 1 | 40100-ZV4-651ZA | CASE, OIL *NH282MU* (OYSTER SILVER METALLIC-U) | 1 |
| 40106-ZV4-000 | GROMMET, OIL CASE (B) | ||
| 40108-ZV4-000 | GROMMET, OIL CASE (D) | ||
| 1 | 40109-ZV4-010 | SEE PART DETAILS - PRI; GROMMET, OIL CASE (E) | 1 |
| 50281-ZV4-651ZB | HANDLE, CARRYING *NH282MU* (OYSTER SILVER METALLIC-U) | ||
| 63100-ZV4-000ZB | COVER, ENGINE *NH282MU* (OYSTER SILVER METALLIC-U) | ||
| 63102-ZV4-300 | SEAL, ENGINE COVER | ||
| 1 | 63201-ZV1-841ZB | LEVER, COVER LOCK *NH282MU* (OYSTER SILVER METALLIC-U) | 1 |
| 63105-ZV4-000 | HANDLE, TILT | ||
| 63202-ZV4-000 | HOOK, COVER LOCK | ||
| 1 | 63205-920-000 | BUSH, COVER LOCK | 1 |
| 82873-ZV4-003 | GROMMET, WATER CHECK | ||
| 1 | 90011-ZW9-000 | SEE PART DETAILS - PRI; BOLT, FLANGE (6X14) (CT200) | 1 |
| 1 | 90013-ZV4-010 | SEE PART DETAILS - PRI; BOLT, FLANGE (6X20) | 1 |
| 1 | 90105-ZVA-000 | SEE PART DETAILS - PRI; BOLT, OIL CHECK | 1 |
| 1 | 90105-ZV4-650 | SEE PART DETAILS - SUP; BOLT, OIL CHECK (8X8) | 1 |
| 7 | 90120-ZV4-010 | SEE PART DETAILS - PRI; BOLT, HEX. (6X40) | 7 |
| 90125-ZV4-000 | BOLT, FLANGE (6X35) | ||
| 3 | 90304-881-010 | SEE PART DETAILS - PRI; NUT (6MM) | 3 |
| 2 | 90302-921-000 | NUT, HEX. (16MM) DUAL QTY = (2) (SINGLE) | 2 |
| 2 | 90452-GK4-600 | SEE PART DETAILS - PRI; WASHER, PLAIN (5MM) | 2 |
| 3 | 90506-ZV4-000 | WASHER, PLAIN (6MM) Use up to Frame SN 4800342. | 3 |
| 1 | 90505-ZV1-000 | WASHER (14MM) | 1 |
| 1 | 90506-ZV1-000 | WASHER, WAVE (14MM) | 1 |
| 7 | 90506-ZV4-000 | WASHER, PLAIN (6MM) Use up to Frame SN 4800342. | 7 |
| 1 | 90507-921-000 | WASHER, NYLON (8MM) | 1 |
| 4 | 90512-921-010 | SEE PART DETAILS - PRI; WASHER (6MM) | 4 |
| 2 | 90507-ZV4-000 | WASHER, PLAIN (8MM) Use up to Frame SN 4800712. | 2 |
| 1 | 90605-ZV4-000 | CLIP, TUBE (B12.5) | 1 |
| 1 | 90660-ZA0-600 | CLIP, ENGINE STOP SWITCH CORD (Honda Code 2081271). | 1 |
| 1 | 90687-ZV4-003 | CLIP, WIRE HARNESS | 1 |
| 2 | 90756-881-000 | SEE PART DETAILS - SUP; PIN, SPLIT | 2 |
| 2 | 90759-ZV1-000 | SEE PART DETAILS - PRI; PIN, SPLIT (2.0) | 2 |
| 2 | 90757-ZV1-000 | PIN, LOCK (5MM) | 2 |
| 2 | 91255-ZV4-651 | SEAL, WATER (14X26X6) | 2 |
| 91551-ZV4-000 | COLLAR, DISTANCE (6MM) | ||
| 1 | 92101-06016-0B | SEE PART DETAILS - PRI; BOLT, HEX. (6X16) | 1 |
| 3 | 90127-ZV4-000 | BOLT, HEX. (6X16) | 3 |
| 90102-ZV4-000 | SEE PART DETAILS - PRI; BOLT, HEX. (8X30) | ||
| 2 | 90509-ZV4-000 | WASHER, SHIFT | 2 |
| 2 | 94301-08140 | SEE PART DETAILS - PRI; PIN A, DOWEL (8X14) (Honda Code 0069310). | 2 |
| 1 | 94305-40203 | PIN, SPRING (4X20) | 1 |
| 4 | 95701-06016-02 | BOLT, FLANGE (6X16) | 4 |
