Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 800091570 | Cylinder Head Assy. (250) | ||
| 800099826 | HEAD, CYLINDER | ||
| 800049792 | THREADED INSERT HELI-COIL | ||
| 8A0085071 | SCREW TCEI M6X1X25 | ||
| 161795501 | BUSH 8X6.4X6 | ||
| 8A00A0567 | VALVE GUIDE | ||
| 8B00A0567 | Valve Guide (250) Dia10,55 | ||
| 8A00A1041 | GUIDE-VALVE 10.525 MM | ||
| 8B00A1041 | Valve Guide (450) Dia10,55 | ||
| 800074836 | STUD BOLT M8X51MM | ||
| 800098167 | SEAL VALVE STEM | ||
| 800099713 | Inlet Valve (250) | ||
| 8000A1942 | Inlet Valve (450) | ||
| 8000A0341 | Exhaust Valve (250) | ||
| 8000A0342 | EXHAUST VALVE | ||
| 800092433 | COTTER, VALVE | ||
| 800091577 | RETAINER, VALVE SPRING | ||
| 800091578 | VALVE SPRING SEAT | ||
| 800091579 | SPRING, VALVE | ||
| 8000A0568 | SPRING, VALVE | ||
| 800091568 | ROCKER ARM | ||
| 800091580 | Pin (250) | ||
| 800099833 | Pin (450) | ||
| 800091582 | SPACER, SPRING | ||
| 8A0091582 | SPACER, SPRING 25.8MM | ||
| 8B0091582 | SPACER, SPRING 27.8MM | ||
| 800099711 | PLUG DIN 908 M14X1.5 | ||
| 800047763 | WASHER 17.9X14.2X1.5 | ||
| 800091583 | HOSE, OIL | ||
| 800099834 | HOSE, OIL | ||
| 800091584 | O-RING 2018 1.78 D4.48 | ||
| 800034317 | BEARING 12X28X8 | ||
| 80A091548 | COVER, CYLINDER HEAD | ||
| 80A099836 | COVER, CYLINDER HEAD | ||
| 800091586 | PIPE, BREATHER | ||
| 800091566 | GASKET, HEAD COVER | ||
| 800099837 | GASKET, HEAD COVER | ||
| 800091587 | SCREW | ||
| 800091588 | SEAL WASHER GM2000 M10,7X8,1X1 | ||
| 800054700 | NUT | ||
| 800062730 | SCREW TE M6X1X30 CH8 | ||
| 800091589 | NUT | ||
| 800023374 | WASHER | ||
| 800047708 | SPRING PIN 12X10 UNI 6874 | ||
| 8000A0232 | HOSE, OIL DELIVERY | ||
| 8A00A0232 | HOSE, OIL DELIVERY | ||
| 8000A0574 | BOLT UNION | ||
| 8000A0575 | WASHER | ||
| 8000A2141 | PAD, VALVE ADJUSTING 1.60MM | ||
| 8A00A2141 | PAD, VALVE ADJUSTING 1.65MM | ||
| 8B00A2141 | PAD, VALVE ADJUSTING 1.70MM | ||
| 8C00A2141 | PAD, VALVE ADJUSTING 1.75MM | ||
| 8D00A2141 | PAD, VALVE ADJUSTING 1.80MM | ||
| 8E00A2141 | PAD, VALVE ADJUSTING 1.85MM | ||
| 8F00A2141 | PAD, VALVE ADJUSTING 1.90MM | ||
| 8G00A2141 | PAD, VALVE ADJUSTING 1.95MM | ||
| 8H00A2141 | PAD, VALVE ADJUSTING 2.00MM | ||
| 8J00A2141 | PAD, VALVE ADJUSTING 2.05MM | ||
| 8K00A2141 | PAD, VALVE ADJUSTING 2.10MM | ||
| 8L00A2141 | PAD, VALVE ADJUSTING 2.15MM | ||
| 8M00A2141 | PAD, VALVE ADJUSTING 2.20MM | ||
| 8N00A2141 | PAD, VALVE ADJUSTING 2.25MM | ||
| 8P00A2141 | PAD, VALVE ADJUSTING 2.30MM | ||
| 8R00A2141 | PAD, VALVE ADJUSTING 2.35MM | ||
| 8S00A2141 | PAD, VALVE ADJUSTING 2.40MM | ||
| 8T00A2141 | PAD, VALVE ADJUSTING 2.45MM | ||
| 8U00A2141 | PAD, VALVE ADJUSTING 2.50MM | ||
| 8V00A2141 | Pad (2,55 mm) | ||
| 8W00A2141 | PAD, VALVE ADJUSTING 2.60MM | ||
| 800099664 | JOINT, CARBURETOR | ||
| 8000A2121 | JOINT, CARBURETOR | ||
| 8000A0031 | JOINT, CARBURETOR | ||
| 3 | 800062728 | SCREW TEF M6X1X20 CH8 | 3 |
| 800019965 | O-RING 44.12X2.62 | ||
| 800091553 | GUIDE, TIMING CHAIN | ||
| 161535902 | SCREW | ||
| 800045194 | WASHER 14X8.2X1 | ||
| 800099687 | SPRING | ||
| 800044298 | ROLLER 19.8X4 | ||
| 800023107 | O-RING 8.73-1.78 | ||
| 800096835 | LEVER, SHAFT | ||
| 8000A0303 | CABLE, DECOMPRESSION | ||
| 800099684 | LEVER, VALVE LIFTER | ||
| 8G0099475 | CLAMP NEMO 30/60 MM |
