Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 800069319 | Steering Head WR model Only for U.S.A. | ||
| 8C0069319 | Steering Head CR model | ||
| 800062796 | SCREW TEF M8X1.25X40 CH12 | ||
| 800083395 | RING NUT, STERING STEM WR model Only for U.S.A. | ||
| 8A0087717 | NUT, STEERING STEM CR model | ||
| 800090334 | STEERING HEAD BASE WR model Only for U.S.A. | ||
| 800089930 | Steering Crown With Pin CR model | ||
| 800091507 | L.H. Slider Assy | ||
| 80A091507 | L.H. Slider Assy Upon request | ||
| 800091506 | FORK INNER TUBE, RIGHT | ||
| 80A091506 | R.H. Slider Assy Upon request | ||
| 800091473 | PIPE | ||
| 80A091473 | Pipe Upon request | ||
| 800070328 | BUSH Gasket are also supplied in bag ref. Ndeg 55 | ||
| 800086385 | Cup | ||
| 800085930 | OIL SEAL, FORK Gasket are also supplied in bag ref. Ndeg 55 | ||
| 800081161 | Stop Ring | ||
| 800081162 | SEAL, DUST FRONT FORK Gasket are also supplied in bag ref. Ndeg 55 | ||
| 800091474 | FORK OUTER TUBE ASSY | ||
| 800084702 | SCREW | ||
| 800091475 | BALL | ||
| 800091476 | SPRING | ||
| 800091477 | Dowel | ||
| 800091478 | O-Ring Gasket are also supplied in bag ref. Ndeg 55 | ||
| 800091479 | ADJUSTER SET | ||
| 800077373 | CUP | ||
| 800091511 | Spring K= 4,0 N/Mm WR model Only for U.S.A. | ||
| 800091508 | SPRING, FORK K=4,5 N/MM CR model | ||
| 800091515 | Damping Element Compl. WR model Only for U.S.A. | ||
| 800093078 | Damping Element Compl. CR model | ||
| 800089238 | Nut | ||
| 800091482 | Spring Guide | ||
| 800091512 | Pipe WR model Only for U.S.A. | ||
| 800091483 | Pipe CR model | ||
| 800091484 | Nut WR model Only for U.S.A. | ||
| 800093074 | Nut CR model | ||
| 800091485 | Seeger Ring | ||
| 800091486 | Pad WR model Only for U.S.A. | ||
| 800093075 | Pad CR model | ||
| 800091487 | Spacer WR model Only for U.S.A. | ||
| 800093076 | Spacer CR model | ||
| 800091488 | Housung WR model Only for U.S.A. | ||
| 800093077 | Housung CR model | ||
| 800091490 | Internal Rod | ||
| 800091489 | Rod Assy | ||
| 800089241 | Spring | ||
| 800089245 | Plate | ||
| 800091491 | Plate | ||
| 800091492 | Plate | ||
| 800081181 | Plate | ||
| 800089243 | PISTON RING Gasket are also supplied in bag ref. Ndeg 55 | ||
| 800089244 | R.H. Piston WR model Only for U.S.A. | ||
| 800091493 | R.H. Piston CR model | ||
| 800091494 | Plate WR model Only for U.S.A. | ||
| 800091500 | Plate WR model Only for U.S.A. | ||
| 800091501 | Plate WR model Only for U.S.A. | ||
| 800091502 | Plate WR model Only for U.S.A. | ||
| 800091514 | Plate WR model Only for U.S.A. | ||
| 800091500 | Plate CR model | ||
| 800074310 | Nut | ||
| 800091497 | BUSHING-FRONT FORK, SLIDE LOW Gasket are also supplied in bag ref. Ndeg 55 | ||
| 800062729 | SCREW TEF M6X1X25 CH8 | ||
| 800091516 | Valve WR model Only for U.S.A. | ||
| 800091510 | Valve CR model | ||
| 800091718 | Valve Upon request/WR model Only for U.S.A. | ||
| 800095265 | Valve Upon request/CR model | ||
| 800089252 | Nut | ||
| 800089242 | Plate | ||
| 800040409 | OR RING Gasket are also supplied in bag ref. Ndeg 55 | ||
| 800091499 | Piston WR model Only for U.S.A. | ||
| 800091509 | Piston CR model | ||
| 800091496 | Plate WR model Only for U.S.A. | ||
| 800091501 | Plate CR model | ||
| 800091495 | REED VALVE CR model | ||
| 800091496 | Plate CR model | ||
| 800091503 | Valve | ||
| 800091480 | CAP, FRONT FORK | ||
| 800089875 | L.H. Fork Leg Assy WR model Only for U.S.A. | ||
| 800090004 | L.H. Fork Leg Assy CR model | ||
| 800089874 | R.H. Fork Leg Assy WR model Only for U.S.A. | ||
| 800090003 | R.H. Fork Leg Assy CR model | ||
| 80C069981 | LEFT PLATE | ||
| 8A0067997 | SCREW TEF M5X0.8X16 | ||
| 800061355 | NUT M5X0.8 CH8 | ||
| 800080260 | FORK OIL | ||
| 800091519 | FRONT FORK OVERHAUL SET | ||
| 8A0065503 | WASHER 34.5X26 WR model Only for U.S.A. | ||
| 800087736 | WASHER 40.5X29.5X2 CR model | ||
| 800069315 | NUT, STEERING STEM M24X1 CH30 WR model Only for U.S.A. | ||
| 8A0069315 | NUT, STEERING STEM M26X1 CH30 CR model | ||
| 800073141 | Hub | ||
| 800060233 | CUSHION | ||
| 800060234 | WASHER 28X22X10.5X2.5 | ||
| 800053155 | SPACER 12X10.1X34 | ||
| 60N101219 | SCREW TE M10X1.5X65 | ||
| 800061314 | SELF LOCKING NUT M10X1.5 | ||
| 800068516 | Hub | ||
| 800062733 | SCREW TE M8X1.25X35 CH12 | ||
| 80C069337 | GUARD FORK TUBE, LH | ||
| 80C069338 | GUARD FORK TUBE, RH | ||
| 800067997 | SCREW TE M5X0.8 CH8 | ||
| 800069282 | BUSH 14X7X5.25 | ||
| 800093283 | CLAMP | ||
| 8B0066525 | SCREW TEF M5X1X30 CH8 | ||
| 800040718 | NUT, SELF LOCKING M5X0.8 | ||
| 800087745 | GASKET CR model | ||
| 800091607 | Spring K=3,8 N/Mm Upon request | ||
| 800091608 | Spring K=4,0 N/Mm Upon request | ||
| 800091609 | Spring K=4,2 N/Mm Upon request | ||
| 800091610 | FORK SPRING K=4.5 N/MM Upon request | ||
| 800091611 | Spring K=4,8 N/Mm Upon request | ||
| 800095263 | SPRING K=5,0 N/MM Upon request | ||
| 800091717 | Fork Travel Kit Upon request/WR model Only for U.S.A. |
