Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 8A0096811 | Steering Head TE model | ||
| 800096811 | HEAD, STEERING STEM TC model | ||
| 800095703 | HEAD, STEERING STEM SMR model | ||
| 800062796 | SCREW TEF M8X1.25X40 CH12 | ||
| 800083395 | RING NUT, STERING STEM TE model/SMR model | ||
| 8A0087717 | NUT, STEERING STEM TC model | ||
| 800096897 | Steering Crown With Pin TE model | ||
| 800096813 | Steering Crown With Pin TC model | ||
| 800095702 | Steering Crown With Pin SMR model | ||
| 800098787 | L.H. Slider Assy TE model/TC model | ||
| 800096643 | L.H. Slider Assy To fell out/Supply unitedly to part 8A0094696 Draw.30A No.10 | ||
| 8A0096643 | L.H. Slider Assy SMR model | ||
| 800098786 | FORK INNER TUBE RIGHT | ||
| 8000A3191 | KIT STARTING HOOK To issue/TC model | ||
| 800091474 | FORK OUTER TUBE ASSY | ||
| 800091479 | ADJUSTER SET | ||
| 800077373 | CUP | ||
| 800091610 | FORK SPRING K=4.5 N/MM TE model | ||
| 8000A4876 | Spring K=4,8 N/Mm (450-510) TE model | ||
| 800098789 | FORK SPRING K=4.8 N/MM TC model | ||
| 800098803 | FORK SPRING K=5.0 N/MM SMR model | ||
| 800098552 | Damping Element Compl. TE model | ||
| 800098792 | PLUNGER ASSY TC model | ||
| 800096645 | Damping Element Compl. SMR model | ||
| 800062729 | SCREW TEF M6X1X25 CH8 | ||
| 800098781 | Valve TE model | ||
| 800095260 | VALVE ASSY, BASE TC model | ||
| 800096647 | BOTTOM VALVE ASSY SMR model | ||
| 800091480 | CAP, FRONT FORK Not supplied | ||
| 8A0097015 | L.H. Fork Leg Assy TE model | ||
| 800096839 | L.H. Fork Leg Assy TC model | ||
| 800095699 | L.H. Fork Leg Assy To fell out/Supply unitedly to part 8A0094696 Draw.30A No.10/SMR model | ||
| 8A0095699 | L.H. Fork Leg Assy SMR model | ||
| 8A0097016 | R.H. Fork Leg Assy TE model | ||
| 800096840 | R.H. Fork Leg Assy TC model | ||
| 800095698 | R.H. Fork Leg Assy To fell out/Supply unitedly to part 8A0094696 Draw.30A No.10/SMR model | ||
| 8A0095698 | R.H. Fork Leg Assy SMR model | ||
| 8000A0633 | PLATE TE model/TC model | ||
| 8000A0633 | PLATE SMR model | ||
| 80A0A0633 | PLATE SMR model | ||
| 8A0067997 | SCREW TEF M5X0.8X16 | ||
| 800061355 | NUT M5X0.8 CH8 | ||
| 800080260 | FORK OIL Upon request | ||
| 800091519 | FRONT FORK OVERHAUL SET | ||
| 8A0065503 | WASHER 34.5X26 TE model/SMR model | ||
| 800087736 | WASHER 40.5X29.5X2 TC model | ||
| 800069315 | NUT, STEERING STEM M24X1 CH30 TE model/SMR model | ||
| 8A0069315 | NUT, STEERING STEM M26X1 CH30 TC model | ||
| 800098237 | HOLDER HANDLE LOWER | ||
| 800060233 | CUSHION | ||
| 800060234 | WASHER 28X22X10.5X2.5 | ||
| 800053155 | SPACER 12X10.1X34 | ||
| 60N101219 | SCREW TE M10X1.5X65 | ||
| 800061314 | SELF LOCKING NUT M10X1.5 | ||
| 800098118 | HOLDER, HANDLE UPPER | ||
| 8C0069056 | SCREW TEF M8X1.25X30 CH12 | ||
| 80G069337 | GUARD FORK TUBE, LH TE model/TC model | ||
| 80A095696 | GUARD FORK TUBE, LH SMR model | ||
| 800095696 | GUARD FORK TUBE, LH SMR model | ||
| 80G069338 | GUARD FORK TUBE, RH TE model/TC model | ||
| 80G069338 | GUARD FORK TUBE, RH SMR model | ||
| 80C069338 | GUARD FORK TUBE, RH SMR model | ||
| 800067997 | SCREW TE M5X0.8 CH8 | ||
| 800069282 | BUSH 14X7X5.25 | ||
| 800093283 | CLAMP | ||
| 8B0066525 | SCREW TEF M5X1X30 CH8 | ||
| 800056443 | NUT, SELF-LOCKING M5X0.8 CH8 | ||
| 800087745 | GASKET TC model | ||
| 800097750 | BUSHING SLIDE OVERHAUL SET | ||
| 800097749 | FRONT FORK SEAL OVERHAUL SET | ||
| 800098782 | REED SET 0.1 MM | ||
| 800098783 | Plate Kit (0,2 mm) | ||
| 800098784 | Plate Kit (0,3 mm) | ||
| 800098785 | Plate Kit (0,4 mm) | ||
| 800074842 | REFLEX REFLECTOR, SIDE Not for TC | ||
| 800074842 | REFLEX REFLECTOR, SIDE TC model/Only for TE/U.S.A. |
