Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 8A00A5961 | HEAD, STEERING STEM TE model | ||
| 8000A5961 | HEAD, STEERING STEM TC model | ||
| 8B00A5961 | Steering Head SMR model | ||
| 800062796 | SCREW TEF M8X1.25X40 CH12 TE model/SMR model | ||
| 800062733 | SCREW TE M8X1.25X35 CH12 TC model | ||
| 800083395 | RING NUT, STERING STEM TE model/SMR model | ||
| 8A0087717 | NUT, STEERING STEM TC model | ||
| 8000A6010 | UNDER BRACKET ASSY TE model | ||
| 8000A5963 | Steering Crown With Pin TC model | ||
| 8A00A6010 | Steering Crown With Pin SMR model | ||
| 8000A7581 | L.H. Slider Assy TE model/TC model | ||
| 8000A7607 | FORK INNER TUBE LEFT SMR model | ||
| 8000A7582 | R.H. Slider Assy | ||
| 8000A7584 | FORK OUTER TUBE | ||
| 8000A7585 | Cup | ||
| 8000A7594 | Spring K=4,8 N/Mm TE model | ||
| 8000A7586 | Spring K=4,8 N/Mm TC model | ||
| 8000A7608 | SPRING, FRONT FORK K=5.0 N/MM SMR model | ||
| 80B0A5989 | LEFT COVER TE model | ||
| 80A0A5989 | PROTECTION, LEFT TC model | ||
| 80B0A6631 | Guard L.H. (Color Code E) Blue SMR model | ||
| 80A0A6631 | Guard L.H. (Color Code G) Black SMR model | ||
| 80B0A5990 | RIGHT COVER TE model | ||
| 80A0A5990 | RIGHT COVER TC model | ||
| 80B0A6630 | Guard R.H. (Color Code E) Blue SMR model | ||
| 80A0A6630 | Guard R.H. (Color Code G) Black SMR model | ||
| 8000A7595 | SPACER, SPRING TE model | ||
| 8000A7587 | SPACER, SPRING TC model | ||
| 8000A7604 | Pipe SMR model | ||
| 800062729 | SCREW TEF M6X1X25 CH8 | ||
| 8000A7596 | VALVE-ASSY,FORK TE model | ||
| 8000A7588 | Valve TC model | ||
| 8000A7605 | Valve SMR model | ||
| 8000A6051 | PLATE | ||
| 8000A6641 | Kit Starting Hook | ||
| 8000A7597 | CAP, FRONT FORK To issue | ||
| 8000A7589 | BOLT, FORK Not supplied | ||
| 8000A6013 | L.H. Fork Leg Assy TE model | ||
| 8000A5959 | L.H. Fork Leg Assy TC model | ||
| 8000A6043 | FORK LEG ASSY, LEFT SMR model | ||
| 8000A6012 | R.H. Fork Leg Assy TE model | ||
| 8000A5960 | R.H. Fork Leg Assy TC model | ||
| 8000A6044 | R.H. Fork Leg Assy SMR model | ||
| 800061355 | NUT M5X0.8 CH8 | ||
| 800069282 | BUSH 14X7X5.25 | ||
| 8000A7593 | BUSH SET, SLIDE | ||
| 8000A7592 | OIL SEAL SET | ||
| 800062725 | SCREW TEF M6X1.00X10 CH8 | ||
| 800069429 | BUSH 9X7X4.8 | ||
| 800062796 | SCREW TEF M8X1.25X40 CH12 | ||
| 8000A7598 | PISTON, FRONT FORK TE model | ||
| 8000A7591 | PISTON, FRONT FORK TC model | ||
| 8000A7606 | PISTON, FRONT FORK SMR model | ||
| 8A0065503 | WASHER 34.5X26 TE model/SMR model | ||
| 800087745 | GASKET TC model | ||
| 800087736 | WASHER 40.5X29.5X2 TC model | ||
| 800069315 | NUT, STEERING STEM M24X1 CH30 TE model/SMR model | ||
| 8A0069315 | NUT, STEERING STEM M26X1 CH30 TC model | ||
| 8000A5879 | HOLDER, HANDLE UNDER TE model/SMR model | ||
| 8A00A5879 | HOLDER, HANDLE LOWER TC model | ||
| 800053155 | SPACER 12X10.1X34 | ||
| 60N101224 | SCREW TE M10X1.5X90 TE model/TC model | ||
| 60N101220 | SCREW TE M10X1.5X70 SMR model | ||
| 800061314 | SELF LOCKING NUT M10X1.5 | ||
| 800060234 | WASHER 28X22X10.5X2.5 | ||
| 8000A4092 | HOLDER, HANDLE, UPPER TE model/SMR model | ||
| 8A00A4092 | HANDLEBAR BRACKET, UPPER TC model | ||
| 8C0069056 | SCREW TEF M8X1.25X30 CH12 | ||
| 8A0067997 | SCREW TEF M5X0.8X16 | ||
| 8000A7590 | NUT TC model | ||
| 800060233 | CUSHION | ||
| 8000A6683 | SPACER 32X10X19.5 TE model/TC model |
