Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 8AA099587 | Frame (Te) | ||
| 8EA099587 | Frame (Tc) | ||
| 8R0099587 | Frame (Smr) | ||
| 8000A3104 | REAR FRAME | ||
| 800062732 | SCREW TEF M8X1.25X25 CH12 TE model/TC model | ||
| 800069056 | SCREW TE M8X1.25X20 CH12 SMR model | ||
| 800060898 | SCREW TTEI M6X1.00X15 To issue | ||
| 800073140 | PIN, CLEVIS | ||
| 800096907 | SPRING, FOOTREST, LH | ||
| 8000A0865 | PROTECTOR, ENGINE TE model/TC model/To issue | ||
| 8A0066661 | SPACER 20X12X8.5 | ||
| 80A089953 | FOOTREST, FRONT RH | ||
| 80A089962 | FOOTREST, FRONT LH | ||
| 800096908 | SPRING, FOOTREST, RH | ||
| 64N120068 | SPLIT PIN 18X1.8 | ||
| 8A0001815 | WASHER 16X10X1 | ||
| 8B0069056 | SCREW TEF M8X1.25X15 CH12 TE model/TC model | ||
| 8000A4395 | FRAME PROTECTION, LEFT TE model/TC model | ||
| 800069429 | BUSH 9X7X4.8 TE model/TC model | ||
| 8A0066661 | SPACER 20X12X8.5 TE model/TC model | ||
| 800069150 | BRACKET, SEAT | ||
| 800062796 | SCREW TEF M8X1.25X40 CH12 | ||
| 800033373 | RIVET 3.3X14 | ||
| 800069111 | SCREW M8X130 MM | ||
| 8A0071091 | U-BOLT To issue/Not for U.S.A. | ||
| 800069056 | SCREW TE M8X1.25X20 CH12 | ||
| 8000A7237 | U-BOLT To issue/Not for U.S.A. | ||
| 151307001 | CONICAL ROLLERS BEARING 25-50- TE model/SMR model | ||
| 800087243 | CONICAL ROLLERS BEARING 29-48- TC model | ||
| 800062796 | SCREW TEF M8X1.25X40 CH12 To issue/Not for U.S.A. | ||
| 8G0073458 | SCREW M8X150 | ||
| 800043391 | LOCK, STEERING TE model/SMR model | ||
| 800024350 | SPACER 18X8.5X19 To issue/Not for U.S.A. | ||
| 800043928 | SELF LOCKING NUT M8X1.25 | ||
| 800035531 | KEY, BRANK TE model/SMR model | ||
| 8000A7238 | FOOTREST BRACKET KIT To issue | ||
| 8A0059433 | ROLLER, CHAIN GUIDE | ||
| 4 | 800063312 | BEARING, RADIAL BALL 608 2RS | 4 |
| 8A0059434 | SPACER | ||
| 8000A7239 | R.H. Support (Te, Smr) To issue | ||
| 800066652 | FOOTREST, REAR RH To issue | ||
| 80A0A0675 | BRACKET, REAR FOOTREST LH To issue | ||
| 800066651 | FOOTREST, REAR LH To issue | ||
| 800041459 | SCREW To issue | ||
| 62N115504 | WASHER 6.4X12X1 To issue | ||
| 64N120048 | PIN, COTTER 1.3X12 To issue | ||
| 800062732 | SCREW TEF M8X1.25X25 CH12 To issue | ||
| 80A0A0264 | STAND, SIDE TE model | ||
| 8AA0A0264 | STAND, SIDE SMR model | ||
| 8000A0266 | SCREW M8X25 TE model/SMR model | ||
| 8000A0268 | SPRING, INNER TE model/SMR model | ||
| 8000A0269 | SPRING SIDE STAND OUTER TE model/SMR model | ||
| 8000A0267 | PLATE TE model/SMR model | ||
| 800046893 | CLIP NUT M6 To issue | ||
| 800099613 | BRACKET, SIDE STAND TE model/SMR model | ||
| 800069056 | SCREW TE M8X1.25X20 CH12 TE model/SMR model | ||
| 8000A1427 | GUARD. RH CRANKCASE To issue | ||
| 8A0067207 | SPACER To issue | ||
| 800062730 | SCREW TE M6X1X30 CH8 To issue | ||
| 8B0069056 | SCREW TEF M8X1.25X15 CH12 To issue |
