Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 8000H6098 | FINGER FOLLOWER PIN | ||
| 8000H6099 | FINGER FOLLOWER | ||
| 62N015676 | WASHER 17X10.2X1 | ||
| 8000H6293 | FIXING SCREW FOR INTAKE EXHAUS | ||
| 8000H6294 | FIXING SCREW FOR INTAKE FINGER | ||
| 8000A2141 | PAD, VALVE ADJUSTING 1.60MM | ||
| 8A00A2141 | PAD, VALVE ADJUSTING 1.65MM | ||
| 8B00A2141 | PAD, VALVE ADJUSTING 1.70MM | ||
| 8C00A2141 | PAD, VALVE ADJUSTING 1.75MM | ||
| 8D00A2141 | PAD, VALVE ADJUSTING 1.80MM | ||
| 8E00A2141 | PAD, VALVE ADJUSTING 1.85MM | ||
| 8F00A2141 | PAD, VALVE ADJUSTING 1.90MM | ||
| 8G00A2141 | PAD, VALVE ADJUSTING 1.95MM | ||
| 8H00A2141 | PAD, VALVE ADJUSTING 2.00MM | ||
| 8J00A2141 | PAD, VALVE ADJUSTING 2.05MM | ||
| 8K00A2141 | PAD, VALVE ADJUSTING 2.10MM | ||
| 8L00A2141 | PAD, VALVE ADJUSTING 2.15MM | ||
| 8M00A2141 | PAD, VALVE ADJUSTING 2.20MM | ||
| 8N00A2141 | PAD, VALVE ADJUSTING 2.25MM | ||
| 8P00A2141 | PAD, VALVE ADJUSTING 2.30MM | ||
| 8R00A2141 | PAD, VALVE ADJUSTING 2.35MM | ||
| 8S00A2141 | PAD, VALVE ADJUSTING 2.40MM | ||
| 8T00A2141 | PAD, VALVE ADJUSTING 2.45MM | ||
| 8U00A2141 | PAD, VALVE ADJUSTING 2.50MM | ||
| 8V00A2141 | Pad (2,55 mm) | ||
| 8W00A2141 | PAD, VALVE ADJUSTING 2.60MM | ||
| 8000H5895 | VALVE SPRING RETAINER | ||
| 8000H6219 | SPRING TC 250 model | ||
| 8000H5894 | WASHER | ||
| 8000H5941 | VALVE COTTER | ||
| 8000H5401 | CYLINDER HEAD | ||
| 8538521 | VALVE TE 310 model /TXC 310 model/TXC 250 model/TE 250 model | ||
| 8539056 | INTAKE VALVE - DEL WEST TC 250 model | ||
| 8000H5947 | VALVE SEALING CORCOS VA3 5-7 | ||
| 8000H5958 | EXHAUST VALVE DEL WEST TC 250 model | ||
| 8538522 | VALVE TE 310 model /TXC 310 model/TXC 250 model/TE 250 model | ||
| 8000A6939 | DOWEL PIN D5 | ||
| 8000A6564 | BOLT CYLINDER HOLDING TXC 250 model/TC 250 model | ||
| 8B00A6564 | STUD BOLT TE 310 model /TXC 310 model | ||
| Z00023374 | WASHER | ||
| 8A0042700 | O-RING 23.52X1.78 | ||
| 8000H5896 | VALVE SPRING (INTERNAL AND EXT TC 250 model | ||
| 8000H6133 | BLOW BY PLATE | ||
| 2 | Z00062728 | SCREW TEF M6X1-CH8-L20 | 2 |
| 8000H7283 | STICK COIL SAFETY PLATE | ||
| 8000H6571 | PLUG M10 X 1 | ||
| ZC0065535 | SCREW | ||
| 8000H6582 | BOLT FOR CYLINDER HEAD COVER | ||
| 8000H5410 | SPARKPLUG BUSH | ||
| 8000H6078 | SPARKPLUG HOLE GASKET | ||
| 8000H6077 | HEAD COVER GASKET | ||
| 80A0H6337 | CYLINDER HEAD COVER | ||
| 800091588 | SEAL WASHER GM2000 M10,7X8,1X1 | ||
| 8000H6581 | BOLT FOR CYLINDER HEAD COVER | ||
| 8000A7039 | PIPE BLOW-BY | ||
| 800001199 | O-RING 11.11X1.78 | ||
| 8000H5896 | VALVE SPRING (INTERNAL AND EXT TE 310 model /TXC 310 model/TXC 250 model/TE 250 model |
