Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 8000B0170 | SEAT ASSY | ||
| 80C0A4216 | FRONT NUMBER PLATE TC model/TXC model | ||
| 80C0H0873 | FENDER, FRONT TE model/TC model/TXC model | ||
| 80C0H0525 | FENDER, FRONT SMR model | ||
| 800061313 | NUTM6X1 | ||
| 8000B1274 | GUARD RH SMR model | ||
| 80A0A4198 | FRONT MUDGUARD BRACKET | ||
| 800069149 | WASHER 17X9X1 | ||
| 80A065535 | SCREW TCEI M5X0.8X14 | ||
| 80C0B0164 | COVER, FRAME RH TE model/TC model/TXC model | ||
| 80C0B1244 | COVER, FRAME RH SMR model | ||
| 80C0B0163 | COVER, FRAME LH | ||
| 8B00A8421 | SCREW M5X16 | ||
| 8000B1772 | FENDER, REAR SMR model | ||
| 80B0B0162 | FENDER. REAR TE model/TC model/TXC model | ||
| 800061355 | NUT M5X0.8 CH8 | ||
| 4 | 800062728 | SCREW TEF M6X1X20 CH8 SMR model | 4 |
| 800062729 | SCREW TEF M6X1X25 CH8 TE model/TC model/TXC model | ||
| 800069148 | PIN, SADDLE | ||
| 80C0H0198 | COWLING TE model/SMR model | ||
| 2 | 800062728 | SCREW TEF M6X1X20 CH8 | 2 |
| 800062727 | SCREW TE M6X1X16 CH8 | ||
| 800062729 | SCREW TEF M6X1X25 CH8 | ||
| 8C0069429 | BUSH TE model | ||
| 8C0069429 | BUSH SMR model | ||
| 800048814 | WASHER 18X6.4X2 | ||
| 8000B0171 | COVER SEAT | ||
| 8000A4609 | PLATE TC model/TXC model | ||
| 8000H0722 | EMBLEM, RIGHT WR250 TE model/To issue | ||
| 8000H0722 | EMBLEM, RIGHT WR250 SMR model/Upon request | ||
| 8000H0219 | Racing Licence Plate Kit TXC model/Upon request | ||
| 8E0067997 | SCREW TEF M5X0.8X10 TC model/TXC model | ||
| 800046893 | CLIP NUT M6 TC model/TXC model | ||
| 800062726 | SCREW TEF M6X1.00X14 CH8 TC model/TXC model | ||
| 8000A6644 | BRACKET, COWLING | ||
| 80A0A4610 | CLAMP, BRAKE HOSE TC model/TXC model | ||
| 800069429 | BUSH 9X7X4.8 TC model/TXC model | ||
| 8000A8423 | BOLT, FLANGE M6X8 TC model/TXC model | ||
| 86610191A | CUSHION RUBBER | ||
| 1 | 800062728 | SCREW TEF M6X1X20 CH8 TC model/TXC model | 1 |
| 800072494 | GUIDE, CABLE TE model/SMR model | ||
| 8000B0167 | SHIELD, HEAT Not for TC | ||
| 62N115548 | WASHER 15X5.3X1 | ||
| 8000A0864 | GUIDE, FRONT BRAKE HOSE TE model/SMR model | ||
| 8A0037283 | SCREW SELF-TAPPING AB 3.5X9.5 TE model/SMR model | ||
| 800088602 | RUBBER TE model/SMR model | ||
| 800073834 | REFLEX REFLECTOR | ||
| 800073834 | REFLEX REFLECTOR TE model/SMR model | ||
| 800040717 | NUT FLANGE M4X0.7 TE model/SMR model | ||
| 62N115547 | WASHER 12X4.3X0.8 TE model/SMR model | ||
| 800094038 | BRACKET LICENSE TE model/SMR model | ||
| 800094595 | PLATE HOLDER NUMBER TE model/SMR model | ||
| 8A0067997 | SCREW TEF M5X0.8X16 TE model/SMR model | ||
| 62N115548 | WASHER 15X5.3X1 TE model/SMR model | ||
| 800056443 | NUT, SELF-LOCKING M5X0.8 CH8 TE model/SMR model | ||
| 8000A7860 | REAR STAY COMP. TE model/SMR model | ||
| 8A00A5377 | BRACKET, LUGGAGE CARRIER TE model | ||
| 8000H0542 | BRACKET, LUGGAGE CARRIER SMR model | ||
| 80A045495 | BUSH | ||
| 800044240 | SELF LOCKING NUT M6X1 CH10 | ||
| 8B00A8423 | BOLT FLANGE M6X16 TC model/TXC model | ||
| 800069282 | BUSH 14X7X5.25 | ||
| 8000B1564 | EMBLEM, CONTROL | ||
| 800055703 | SCREW TCEI M6X1.00X14 | ||
| 800056444 | CLAMP 188 MM | ||
| 8A00A8421 | BOLT, FLANGE M5X12 TE model/SMR model | ||
| 800055134 | NUT 5X0.8 TE model/SMR model | ||
| 800069429 | BUSH 9X7X4.8 SMR model |
