Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 8A0097069 | Parteanteriorecompleta WRmodel | ||
| 8A0097029 | Parteanteriorecompleta CR model | ||
| 8C0097069 | FRAME Only for WR/ U.S.A. | ||
| 8000A0350 | REAR FRAME | ||
| 800069056 | SCREW TE M8X1.25X20 CH12 | ||
| 800062795 | SCREW TEF M8X1.25X50 CH12 | ||
| 8A0062797 | SCREW TE M10X1.25 CH14 | ||
| 800073140 | PIN, CLEVIS | ||
| 800096907 | SPRING, FOOTREST, LH | ||
| 800069434 | PLATE, ENGINE MOUNT | ||
| 80A089953 | FOOTREST, FRONT RH | ||
| 80A089962 | FOOTREST, FRONT LH | ||
| 800096908 | SPRING, FOOTREST, RH | ||
| 64N120068 | SPLIT PIN 18X1.8 | ||
| 8A0001815 | WASHER 16X10X1 | ||
| 800069150 | BRACKET, SEAT | ||
| 800062796 | SCREW TEF M8X1.25X40 CH12 | ||
| 800033373 | RIVET 3.3X14 | ||
| 800069111 | SCREW M8X130 MM | ||
| 800071091 | U-BOLT Not for U.S.A./Not for CR/To issue | ||
| 151307001 | CONICAL ROLLERS BEARING 25-50- WRmodel | ||
| 800087243 | CONICAL ROLLERS BEARING 29-48- CR model/Only for WR/ U.S.A. | ||
| 800073458 | AXLE ENGINE FIXING M8X1.25X10 | ||
| 8N0073458 | AXLE, ENGINE FIXING M8X1.25X12 | ||
| 800043391 | LOCK, STEERING Not for U.S.A./Not for CR | ||
| 800043928 | SELF LOCKING NUT M8X1.25 | ||
| 800035531 | KEY, BRANK Not for U.S.A./Not for CR | ||
| 8A0071086 | FOOTREST BRACKET KIT Not for U.S.A./Not for CR/To Issue | ||
| 800059433 | ROLLER, CHAIN TENSIONER | ||
| 4 | 800063312 | BEARING, RADIAL BALL 608 2RS | 4 |
| 2 | 800059434 | SPACER 12X8.25X15.5 | 2 |
| 800071088 | R.H. Support Not for U.S.A./Not for CR/To Issue | ||
| 800066652 | FOOTREST, REAR RH Not for U.S.A./Not for CR/To Issue | ||
| 8A0071087 | BRACKET, REAR LEFT FOOTREST Not for U.S.A./Not for CR/To Issue | ||
| 800066651 | FOOTREST, REAR LH Not for U.S.A./Not for CR/To Issue | ||
| 800041459 | SCREW Not for U.S.A./Not for CR/To Issue | ||
| 62N115504 | WASHER 6.4X12X1 Not for U.S.A./Not for CR/To Issue | ||
| 64N120048 | PIN, COTTER 1.3X12 Not for U.S.A./Not for CR/To Issue | ||
| 800069056 | SCREW TE M8X1.25X20 CH12 Not for U.S.A./Not for CR/To Issue | ||
| 800062732 | SCREW TEF M8X1.25X25 CH12 Not for U.S.A./Not for CR/To Issue | ||
| 800098040 | SIDE STAND Not for CR | ||
| 800097976 | SCREW M8X25 MM | ||
| 8A0097977 | SCREW M8X22.5 MM Only for WR/ U.S.A. | ||
| 800062676 | SPRING, SIDE STAND INNER Not for CR | ||
| 800062675 | STAND OUTER SPRING Not for CR | ||
| 800084176 | HOLDER, SPRING Not for CR | ||
| 8A0094356 | Pad | ||
| 800042022 | NUT M10X1.25 |
