Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 2850300100030 | frame, black | ||
| 2850300200030 | Subframe, black | ||
| 4 | 0035080206S | SHCS M8x20 TX45 | 4 |
| 90103041033 | footrest front right cpl. | ||
| 90103040033 | footrest front left cpl. | ||
| 1 | 2850303900030S | Front footrest, right | 1 |
| 1 | 2850303800030S | Front footrest, left | 1 |
| 1 | 2850304900030S | Rear footrest, right | 1 |
| 1 | 2850304800030S | Rear footrest, left | 1 |
| 1 | 90103051033 | footrest rear right cpl. | 1 |
| 1 | 90103050033 | footrest rear left cpl. | 1 |
| 2 | 90103038001 | footrest support holder, front | 2 |
| 1 | 90104070000 | chainguide | 1 |
| 2 | 90104066010 | spacer chainguide | 2 |
| 1 | 0025060126 | HH collar screw M6x12 TX30 | 1 |
| 2 | 90103040001 | PLAIN WASHER 6,4X12X1 | 2 |
| 2 | J029060103S | CAP SCREW M6X10 SS | 2 |
| 4 | 60003044100 | footrest bolt, rear | 4 |
| 2 | 61003042000 | SPRING FOOTREST FRONT 05 | 2 |
| 4 | 0799060003 | retaining washer DIN 6799 - 6 | 4 |
| 2 | 90103053000 | footrest lock plate 2 | 2 |
| 2 | 90103052000 | footrest lock plate 1 | 2 |
| 4 | 0025080506 | HH collar screw M8x50 TX40 | 4 |
| 1 | 28503001083 | fuel tank holder, plate, right, cpl. | 1 |
| 28503001053 | fuel tank holder, plate, left, cpl. | ||
| 1 | 28503007000 | Hex fing screw M10X280 SW13 | 1 |
| 2 | 54603013000 | engine brac.scr. M10x105 WS13 | 2 |
| 1 | 77203014000 | engine brac.scr. M10x115 | 1 |
| 1 | 2850301400030S | Engine brace, right | 1 |
| 1 | 2850301300030S | Engine brace, left | 1 |
| 4 | 0025080206S | HH collar screw M8x20 TX40 SL | 4 |
| 3 | 60036078200 | hex collar nut M10 WS13 | 3 |
| 1 | 0025101366 | HH collar screw M10x136 TX | 1 |
| 4 | 0025050106 | HH collar screw M5x10 TX30 | 4 |
| 1 | 28535002000 | radiator retaining bracket, right | 1 |
| 1 | 28535001000 | radiator retaining bracket, left | 1 |
| 1 | 28503093000 | Frame cover, front electrics | 1 |
| 2 | 69008021160 | special screw M5x12 | 2 |
| 4 | 77307040041 | Isolation pad | 4 |
| 2 | 28507049000 | fuel tank holder plate screw | 2 |
| 2 | 0025080126 | HH collar screw M8x12 TX40 | 2 |
| 4 | 0025060106 | HH collar screw M6x10 TX30 | 4 |
| 1 | 58413049000 | washer 10.2x20x2.5 mm | 1 |
| 1 | 2850300108430 | Tank holder cast part | 1 |
| 2 | 0025080256 | HH collar screw M8x25 | 2 |
| 1 | 2850508800030S | Exhaust bracket | 1 |
| 1 | 90111045050 | CABLE BRACKET | 1 |
| 1 | 28507052000 | Cover, seat lock | 1 |
| 1 | 0025060166 | HH collar screw M6x16 TX30 | 1 |
| 2 | 54603048700 | Range change metal nut M6 | 2 |
| 1 | 28542032000 | ABS modulator cover | 1 |
| 2 | 93007047033 | Seat support complete | 2 |
| 2 | 0025080356 | HH collar screw M8x35 TX40 | 2 |
