Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 24800-ZW9-A02 | SEE PART DETAILS - PRI; S/R SW 2 LIGH POW TL | 1 |
| 1 | 24810-ZZ5-D01 | PLATE ASSY. | 1 |
| 1 | 24811-ZZ5-D01 | LEVER, HAND | 1 |
| 1 | 24812-ZZ5-D01 | ARM, NEUTRAL LOCK | 1 |
| 1 | 24813-ZZ5-D01 | GRIP | 1 |
| 1 | 24814-ZZ5-D01 | COVER, LEVER | 1 |
| 1 | 24815-ZZ5-D01 | ARM ASSY., BRAKE | 1 |
| 1 | 24816-ZZ5-D01 | SPRING (2) | 1 |
| 1 | 24817-ZZ5-D01 | CLIP, DETENT | 1 |
| 1 | 24818-ZZ5-D01 | SPACER (1) (LOOSE PARTS) | 1 |
| 1 | 24819-ZZ5-D01 | BRACKET | 1 |
| 1 | 24821-ZZ5-D01 | HOUSING, FR. | 1 |
| 1 | 24822-ZZ5-D01 | HOUSING, RR. | 1 |
| 1 | 24823-ZZ5-D01 | PANEL, BACK | 1 |
| 1 | 24824-ZZ5-D01 | BRACKET, WIRE CLAMP | 1 |
| 1 | 24826-ZZ5-D01 | CAP, RUBBER | 1 |
| 1 | 24827-ZZ5-D01 | ADJUSTER | 1 |
| 1 | 24828-ZZ5-D01 | COVER, POWER TRIM-TILT WIRE (LOOSE PARTS) | 1 |
| 1 | 24829-ZZ5-D01 | SEAL, RUBBER | 1 |
| 1 | 24831-ZZ5-D01 | HOLDER, NEUTRAL LOCK | 1 |
| 1 | 24832-ZZ5-D01 | GROMMET, WIRE (14) | 1 |
| 1 | 24833-ZZ5-D01 | CAP, TROLLING CONTROL SWITCH BLANK | 1 |
| 1 | 24845-ZZ5-D01 | GEAR ASSY., SHIFT | 1 |
| 1 | 24850-ZZ5-D01 | GEAR, DRIVE | 1 |
| 2 | 24855-ZZ5-D01 | TERMINAL, CABLE (LOOSE PARTS) | 2 |
| 1 | 24875-ZZ5-D01 | DRUM ASSY., FREE THROTTLE | 1 |
| 1 | 24876-ZZ5-D01 | SPRING (1) | 1 |
| 1 | 24878-ZZ5-D01 | LEVER, FREE THROTTLE | 1 |
| 5 | 24883-ZZ5-D01 | SPRING, DETENT | 5 |
| 1 | 32530-ZW9-D01 | CABLE ASSY., REMOTE CONTROL (B) | 1 |
| 3 | 32823-ZV5-003 | PLUG, CONNECTOR (INNER) (TROLLING CONTROL) | 3 |
| 1 | 35100-ZV5-013 | SWITCH ASSY., COMBINATION (SINGLE) (DUAL) | 1 |
| 1 | 35370-ZZ5-D02 | SWITCH ASSY., POWER TRIM-TILT | 1 |
| 1 | 35645-ZZ3-A41 | PLATE, SWITCH | 1 |
| 1 | 35701-ZZ5-D01 | BAND, WIRE | 1 |
| 1 | 36180-ZV5-033 | SEE PART DETAILS - PRI; SWITCH ASSY., EMERGENCY STOP | 1 |
| 1 | 36182-ZV4-651 | SEE PART DETAILS - PRI; WIRE, EMERGENCY (SINGLE) (DUAL) | 1 |
| 1 | 37210-ZW9-832 | SEE PART DETAILS - PRI; LAMP ASSY., INDICATOR | 1 |
| 1 | 38403-341-672 | PLATE, TURN SIGNAL BUZZER DUAL QTY = (2) (SINGLE) | 1 |
| 1 | 38410-ZV5-003 | BUZZER, WARNING DUAL QTY = (2) (SINGLE) | 1 |
| 1 | 87701-ZZ5-D00 | MARK, FAST IDLE | 1 |
| 1 | 87702-ZZ5-A00 | MARK, EMERGENCY STOP (US) (LOOSE PARTS) | 1 |
| 1 | 87703-ZZ5-D00 | MARK, EMBLEM | 1 |
| 1 | 87704-ZZ5-D01 | LABEL, SIGP | 1 |
| 7 | 90101-ZZ5-D01 | SCREW (5X18) | 7 |
| 2 | 90102-ZZ5-D01 | SCREW (4X6) | 2 |
| 1 | 90103-ZZ5-D01 | SCREW (5X10) | 1 |
| 2 | 90104-ZZ5-D01 | SCREW (4X10) | 2 |
| 2 | 90106-ZZ5-D01 | SCREW (5X12) | 2 |
| 3 | 90107-ZZ5-D01 | SCREW (6X90) (LOOSE PARTS) | 3 |
| 1 | 90108-ZZ5-D01 | BOLT (8X50) | 1 |
| 1 | 90109-ZZ5-D01 | BOLT (5X25) | 1 |
| 3 | 90301-ZZ5-D01 | NUT (6MM) (LOOSE PARTS) | 3 |
| 1 | 90302-ZZ5-D01 | NUT (5MM) | 1 |
| 1 | 90302-921-000 | NUT, HEX. (16MM) DUAL QTY = (2) (SINGLE) | 1 |
| 1 | 90501-ZZ5-D01 | BEARING (1) | 1 |
| 1 | 90502-ZZ5-D01 | WASHER (3) | 1 |
| 2 | 90503-ZZ5-D01 | WASHER (4) | 2 |
| 1 | 90504-ZZ5-D01 | WASHER (5) | 1 |
| 1 | 90506-ZZ5-D01 | WASHER (8MM) | 1 |
| 3 | 90507-ZZ5-D01 | WASHER (7) (LOOSE PARTS) | 3 |
| 1 | 90508-ZZ5-D01 | WASHER, WAVE | 1 |
| 3 | 90509-ZZ5-D01 | SPACER (2) (LOOSE PARTS) | 3 |
| 2 | 90651-ZZ5-D01 | E-RING (6MM) (LOOSE PARTS) | 2 |
| 1 | 91151-ZZ5-D01 | ROLLER, DRIVE GEAR CAM | 1 |
| 1 | 91152-ZZ5-D01 | ROLLER | 1 |
| 1 | 91153-ZZ5-D01 | BEARING (2) | 1 |
| 2 | 91154-ZZ5-D01 | BEARING (3) | 2 |
| 1 | 91156-ZZ5-D01 | ROLLER, FREE THROTTLE | 1 |
| 1 | 91157-ZZ5-D01 | CLIP, ROLLER | 1 |
| 32570-ZY1-900 | CABLE ASSY., REMOTE CONTROL EXTENSION (4P+6P) (Optional) |
