Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 8A0088853 | Frame Front Side Assy WR model | ||
| 8A0088897 | Frame Front Side Assy CR model | ||
| 8C0088853 | Frame Front Side Assy WR (U.S.A.) model | ||
| 800091535 | Rear Frame Side | ||
| 800069056 | SCREW TE M8X1.25X20 CH12 | ||
| 800062795 | SCREW TEF M8X1.25X50 CH12 | ||
| 800073140 | PIN, CLEVIS | ||
| 8A0089882 | SPRING LEFT FOOT-REST | ||
| 800073830 | PLATE, ENGINE MOUNT | ||
| 8A0075160 | Rivet CR model | ||
| 80A089953 | FOOTREST, FRONT RH | ||
| 80A089962 | FOOTREST, FRONT LH | ||
| 800089882 | SPRING RIGHT. FOOT-REST | ||
| 64N120068 | SPLIT PIN 18X1.8 | ||
| 62N115507 | WASHER 18X10X2 | ||
| 800069150 | BRACKET, SEAT | ||
| 800062796 | SCREW TEF M8X1.25X40 CH12 | ||
| 800033373 | RIVET 3.3X14 | ||
| 800069111 | SCREW M8X130 MM | ||
| 800071091 | U-BOLT Not for U.S.A./Not for CR/ To issue | ||
| 151307001 | CONICAL ROLLERS BEARING 25-50- WR model/WR (U.S.A.) model | ||
| 800087243 | CONICAL ROLLERS BEARING 29-48- | ||
| 8A0073458 | AXLE, ENGINE FIXING M8X1.25X11 CR model | ||
| 8B0073458 | AXLE, ENGINE FIXING M8X1.25X13 | ||
| 800043391 | LOCK, STEERING Not for U.S.A./Not for CR | ||
| 800043928 | SELF LOCKING NUT M8X1.25 | ||
| 800035531 | KEY, BRANK Not for U.S.A./Not for CR | ||
| 800071086 | FOOTREST KIT Not for U.S.A./Not for CR/ To issue | ||
| 800059433 | ROLLER, CHAIN TENSIONER | ||
| 4 | 800063312 | BEARING, RADIAL BALL 608 2RS | 4 |
| 2 | 800059434 | SPACER 12X8.25X15.5 | 2 |
| 800071088 | R.H. Support Not for U.S.A./Not for CR/To issue | ||
| 800066652 | FOOTREST, REAR RH Not for U.S.A./Not for CR/To issue | ||
| 800071087 | REAR FOOT REST BRACKET LEFT Not for U.S.A./Not for CR/To issue | ||
| 800066651 | FOOTREST, REAR LH Not for U.S.A./Not for CR/To issue | ||
| 800041459 | SCREW Not for U.S.A./Not for CR/To issue | ||
| 62N115504 | WASHER 6.4X12X1 Not for U.S.A./Not for CR/To issue | ||
| 64N120048 | PIN, COTTER 1.3X12 Not for U.S.A./Not for CR/To issue | ||
| 800069056 | SCREW TE M8X1.25X20 CH12 Not for U.S.A./Not for CR/To issue | ||
| 8B0073877 | SIDE STAND Not for CR | ||
| 800084177 | Screw M8x22mm Not for U.S.A./Not for CR | ||
| 800075957 | Screw M8x25mm WR (U.S.A.) model/Not for CR | ||
| 800062676 | SPRING, SIDE STAND INNER Not for CR | ||
| 800062675 | STAND OUTER SPRING Not for CR | ||
| 800084176 | HOLDER, SPRING Not for CR |
