Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 0 | 606828 | ASSY,SEAT BACK,CST,W/PNG,RED/BLK | 0 |
| 0 | 71751G03 | SEAT BACK ASY-MED/TXT/CC-OYSTR | 0 |
| 0 | 71751G04 | SEAT BACK ASY-MED/TXT/CC-TAN | 0 |
| 0 | 71751G07 | SEAT BACK ASY BLACK | 0 |
| 0 | 604908 | ASSY,SEAT BACK,CST,W/PNG,WHT/BLU | 0 |
| 0 | 604907 | ASSY,SEAT BACK,CST,W/PNG,WHT/RED | 0 |
| 71753 G03 | OYSTER | ||
| 71753 G04 | TAN | ||
| 71753 G07 | BLACK | ||
| 0 | 604916G0103 | ST BACK FRNT/RR CVR-W/PPG CH-WH/R | 0 |
| 0 | 604916G0102 | ST BACK FRNT/RR CVR-W/PPG CH-WH/BL | 0 |
| 0 | 604916G0304 | ST BACK FRNT/RR CVR-W/PPG R/BK | 0 |
| 1 | 71752G01 | COVER-PLASTIC-SEAT BACK | 1 |
| 1 | 71754G01 | FOAM-SEAT BACK-MED/TXT | 1 |
| 23222G01 | FLAT STAPLE | ||
| 1 | 76414G01 | ASM PLYWOOD SEAT BACK WOOD | 1 |
| 4 | 01107G01 | SC PLASTITE PH TORX #8 | 4 |
| 2 | 615730 | WELDMENT,SEAT BACK SUPPORT (TEXT) | 2 |
| 8 | 71204G01 | SCREW-1/4-20 X 7/8-W/PATCH LK | 8 |
| 0 | 621027 | SEAT BOT,TAN,ECON-ASSY | 0 |
| 0 | 621026 | SEAT BOT,OYS,ECON-ASSY | 0 |
| 0 | 621031 | SEAT BOT,WHT/BLU,ECON-ASSY | 0 |
| 0 | 621036 | SEAT BOT,BLK,ECON-ASSY | 0 |
| 0 | 621032 | SEAT BOT,WHT/RED,ECON-ASSY | 0 |
| 0 | 621033 | SEAT BOT,RED/BLK,ECON-ASSY | 0 |
| 0 | 615646 | VINYL,SEAT BOT,OYS,ECON | 0 |
| 0 | 615647 | VINYL,SEAT BOT,TAN,ECON | 0 |
| 0 | 615648 | SVC-COVER,SEAT BOTTOM,BLACK,TXT | 0 |
| 0 | 611126 | VINYL,SEAT BOT,WHT/RED,ECON | 0 |
| 0 | 611125 | VINYL,SEAT BOT,WHT/BLU,ECON | 0 |
| 0 | 611135 | VINYL,SEAT BOT,RED/BLK,ECON | 0 |
| 1 | 617137 | DECK BOARD ASSY,ECON | 1 |
| 5 | 16705G1 | SCREW-SS-1/4 - 20 X 1 | 5 |
| 1 | 617402 | SEAT STRAP,ECON | 1 |
| 1 | 00559G7 | FLAT WASHER, 1/4" | 1 |
| 1 | 615712 | WELDMENT,SEAT FRAME | 1 |
| 1 | 615714 | WELDMENT,FOOTREST | 1 |
| 2 | 615729 | ARMREST,SEAT,REAR FACING | 2 |
| 2 | 615713 | SUPPORT,SEAT FRAME | 2 |
| 1 | 615728 | BRKT,FOOTREST MOUNTING,RH | 1 |
| 1 | 615727 | BRKT,FOOTREST MOUNTING,LH | 1 |
| 4 | 01006G01 | SCREW-CAP-HWH-3/8-16X1.25 (SEE TEXT) | 4 |
| 16 | 00427G4 | SCREW-3/8-16X1-1/2-C-HEX-CP | 16 |
| 2 | 00429G2 | SCREW-3/8-16 X 3 1/4 | 2 |
| 4 | 16705G9 | SCREW-SS-1/4 - 20 X 1 1/4 | 4 |
| 32 | 614221 | NLA 3/8 GRADE 8 FLW | 32 |
| 4 | 01110G01 | WASHER FLAT A N 1/4 | 4 |
| 14 | 11098G5 | NUT-LOCK-LIGHT-3/8-16 | 14 |
| 4 | 11027G5 | NUT-LOCK (3/8-16 UNC 2B) | 4 |
| 4 | 14390G4 | NUT-LOCK-1/4-20 | 4 |
| 2 | 19853G1 | CAP-TUBE-1 | 2 |
| 0 | 71611G07 | SEAT BOTTOM ASSY, TAN (ELEC) | 0 |
| 0 | 71611G05 | SEAT BOTTOM ASSY,OYSTER | 0 |
| 0 | 71611G35 | SEAT BTTM ASM,RED ON BLK | 0 |
| 0 | 71611G17 | ASSEMBLY, SEAT BOTTOM - BLACK | 0 |
| 0 | 608714 | SEAT BTM ASSY, WHT/RED | 0 |
| 0 | 71611G36 | SEAT BOTTOM ASM,WHT ON BLU | 0 |
| 0 | 71602G03 | COVER SEAT BTM OYSTER | 0 |
| 0 | 71602G04 | COVER SEAT BTM TAN | 0 |
| 0 | 71602G06 | COVER SEAT BTM BLACK | 0 |
| 0 | 604912G0102 | ST BTM CVR FRNT/RR-W/PIPING CH-WH/BL | 0 |
| 0 | 604912G0304 | ST BTM CVR FRNT/RR-W/PIPING R/BK | 0 |
| 0 | 604912G0103 | ST BTM CVR FRNT/RR-W/PIPING CH-WH/R | 0 |
| 1 | 71603G02 | PADDING (FOAM), SEAT BOTTOM MED/TXT SEAT BOTTOM | 1 |
| 1 | 76411G01 | OBS-ASSY,BASE,SEAT BOTTOM WOOD | 1 |
| 2 | 71610G01 | HINGE-SEAT | 2 |
| 6 | 00720G08 | SCREW-WD-FP-ZP #12 X 1 STAINLESS STEEL | 6 |
| 2 | 17074G1 | SOILING SLAB - SEAT BTM | 2 |
| 1 | 71012G01 | TRIM-SEAT BOTTOM SEAT BOTTOM | 1 |
| 110 | 23222G1 | STAPLES | 110 |
| 36 | 23223G1 | STAPLE,FLAT | 36 |
| 1 | 71702G01 | ARMREST/HIP RESTRAINT-LH DRIVER SIDE | 1 |
| 1 | 71701G01 | ARMREST/HIP RESTRAINT-RH PASSENGER SIDE | 1 |
| 8 | 71204G01 | SCREW-1/4-20 X 7/8-W/PATCH LK STAINLESS STEEL | 8 |
| 1 | 617901 | KIT,HAND RAIL,ECON,FLIP FLOP SEAT INCLUDES ITEMS 55 - 60 | 1 |
| 1 | 615721 | WELDMENT,FOOTREST HANDLE | 1 |
| 2 | 19859G1 | CAP-TUBE-3/4 | 2 |
| 1 | 610631 | DECAL, CLAYS BED | 1 |
| 4 | 00427G8 | SCREW-HEX-3/8-16X2-CP | 4 |
| 8 | 614221 | NLA 3/8 GRADE 8 FLW | 8 |
| 4 | 11098G5 | NUT-LOCK-LIGHT-3/8-16 | 4 |
| 4 | 00664G7 | WASHER-LK-SS-.255/.263 | 4 |
| 4 | 00661G8 | SC-1/4-20 X 1 C-HEX SS | 4 |
