Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 602512 | WELDMT FRONT AXLE | 1 |
| 1 | 70942G03 | ASSEMBLY,SPINDLE,RH PASSENGER SIDEINCLUDES ITEMS 4 - 13 | 1 |
| 70940G02 | SPINDLE, MACHINED RH PASSENGER SIDE | ||
| 1 | 70648G01 | BEARING DP4 * BOTTOM FLANGED | 1 |
| 1 | 70749G01 | BEARING DP4* TOP, WITHOUT FLANGE | 1 |
| 1 | 25146G1 | SEAL-GREASE | 1 |
| 2 | 51141G1 | BEARING RACE | 2 |
| 1 | 70589G01 | HUB-WHEEL | 1 |
| 4 | 19862G1 | BOLT, WHEEL | 4 |
| 1 | 12093G1 | NUT-HEX-SLOTTED-17/32 | 1 |
| 1 | 00798G8 | PIN-COTTER 5/32 X 1 3/4 | 1 |
| 2 | 11750G2 | BEARING ROLLER-1 | 2 |
| 2 | 12091G2 | CAP-SPINDLE | 2 |
| 1 | 70673G03 | ASSEMBLY, SPINDLE LH DRIVER SIDEINCLUDES ITEMS 5 - 13 & 17 | 1 |
| 1 | 70742G02 | SPINDLE, MACHINED LH DRIVER SIDE | 1 |
| 2 | 00407G6 | SCREW-1/2-13 X 6* | 2 |
| 4 | 00560G3 | WASHER-FLAT-1/2 | 4 |
| 2 | 70745G01 | KINGPIN | 2 |
| 2 | 70754G01 | WASHER, THRUST SS* STAINLESS STEEL | 2 |
| 2 | 14390G6 | NUT-LOCK-1/2-13-NYLON INSERT | 2 |
| 2 | 76419G01 | SHOCK ABSORBER W/INTERNAL BUMPER | 2 |
| 2 | 70509G01 | SVC - BOOT,SHOCK ABSORBER,YELLOW | 2 |
| 4 | 31539G1 | CLAMP-NYLON-15.5 | 4 |
| 8 | 10435G1 | WASHER-SHOCK | 8 |
| 8 | 10194G1 | BUSHING-SHOCK | 8 |
| 4 | 00532G6 | NUT-3/8-24-HEX-CP | 4 |
| 2 | 10044G01 | VINYL CAP | 2 |
| 2 | 70664G03 | SPRING,FRONT,185,SILVER HEAVY DUTY | 2 |
| 2 | 70989G03 | SPRING,FRONT,150-PINK HEAVY DUTYSEE PART NUMBER ON SPRING | 2 |
| 4 | 70163G03 | PNT,PLATE,SPRING | 4 |
| 11 | 00734G1 | NUT-HEX-LK 7/16-14 | 11 |
| 11 | 00463G11 | SCREW, CAP-HEX HEAD 7/16-14 UNC-2A | 11 |
| 1 | 74605G01 | ASSEMBLY STEERING BOX COMPLETEINCLUDES ITEMS 42 - 65 | 1 |
| 1 | 70965G01 | ASSY,STEERING RACK COVER W/BEARING | 1 |
| 1 | 70750G01 | RING RETAINING EXTERNAL* EXTERNAL | 1 |
| 1 | 15112G1 | BEARING-AXLE-REAR (6004-RS) | 1 |
| 1 | 70603G01 | PINION | 1 |
| 1 | 70751G01 | RING RETAINING INTERNAL* INTERNAL | 1 |
| 1 | 70638G01 | SEAL, PINION* | 1 |
| 1 | 70604G01 | RACK | 1 |
| 01053G01 | SET SCREW | ||
| 1 | 70590G01 | RACK LOADER | 1 |
| 1 | 70666G01 | SPRING, COMPRESSION | 1 |
| 1 | 70645G01 | GASKET, RACK LOADER COVER | 1 |
| 70591g01 | LOADER COVER | ||
| 2 | 71102G01 | SCREW-CAP-1/4-20X.90* | 2 |
| 1 | 10389G3 | FITTING-GREASE | 1 |
| 1 | 70695G01 | ROD END-OUTER (important text) INCLUDES ITEMS 59 - 61 | 1 |
| 1 | 50641G1 | BOOT-RUBBER | 1 |
| 1 | 50209G2 | NUT,HEX,SLOTTED | 1 |
| 1 | 10387G2 | PIN-COTTER-.094X1.00 | 1 |
| 1 | 74602G01 | ROD END INNER INNER | 1 |
| 1 | 70961G01 | BELLOWS,RACK COVER | 1 |
| 1 | 12416G2 | CLAMP,NYLON,WEDGE LOCK,11.8 IN | 1 |
| 1 | 11391G8 | HOSE CLAMP,#30 SEE TEXT | 1 |
| 2 | 00464G6 | SC-C-HEX-ZP 7/16-14 X 2 3/4 * | 2 |
| 1 | 01068G01 | SC CAP HEX HEAD 7/16-14 X 3.50* | 1 |
| 2 | 70667G02 | SPACER, STEERING HOUSING *1.210 IN | 2 |
| 1 | 70667G03 | SPACER, STEERING HOUSING* .772 INCH SHORT | 1 |
| 1 | 00532G6 | NUT-3/8-24-HEX-CP | 1 |
| 7 | 00560G2 | WASHER-FL-7/16-CP | 7 |
| 3 | 00734G1 | NUT-HEX-LK 7/16-14 | 3 |
| 1 | 70758G05 | STEERING COLUMN ASSEMBLY INCLUDES ITEMS 77 - 88 | 1 |
| 1 | 70610G03 | ASSY STEERING COLUMN | 1 |
| 1 | 28569G01 | BUSHING (SEE TEXT) | 1 |
| 1 | 01022G01 | SC,HWH,DRIL-KWICK 6-20X5/16 | 1 |
| 1 | 70607G01 | SHAFT, STEERING* | 1 |
| 1 | 70580G01 | ASSEMBLY, SHAFT INTERMEDIATE* | 1 |
| 2 | 01055G01 | SCREW-CAP METRIC M8 X 1.25 - 6G | 2 |
| 1 | 00565G8 | WASHER-LK-SP #5/16 | 1 |
| 1 | 70888G01 | RING, RETAINING EXTERNAL BOWED* EXTERNAL | 1 |
| 1 | 70887G01 | WASHER, WAVE | 1 |
| 1 | 602980 | WHEEL STEERING PREMIUM OPTIONAL | 1 |
| 1 | 607925 | SCORECARD HOLDER ASSY | 1 |
| 1 | 602979 | WHEEL STEERING FLEET (SEE TEXT) | 1 |
| 4 | 01006G01 | SCREW-CAP-HWH-3/8-16X1.25 (SEE TEXT) | 4 |
| 00879 G1 | LOCK WASHER, 3/8" | ||
| 1 | 608529 | DECAL, WARNING, STRG WHEEL | 1 |
| 1 | 14390G2 | NUT-LOCK-5/8-18 | 1 |
| 1 | 70876G02 | ASSY TIE ROD 26.44 INCH SEE TEXT INCLUDES ITEMS 99, 102 - 105 | 1 |
| 1 | 70897G02 | TIE ROD THREADED 24 LONG | 1 |
| 1 | 70604G01 | RACK INCLUDES ITEMS 101 - 105 | 1 |
| 1 | 74603G01 | TIE ROD THREADED 24" LG | 1 |
| 1 | 70902G01 | TIE ROD END-LH (SEE TEXT) LEFT HAND THREADS | 1 |
| 1 | 01069G01 | JAM NUT, M12 X 1.25-05-LH LEFT HAND THREADS | 1 |
| 1 | 70902G02 | TIE ROD END-RH (SEE TEXT) RIGHT HAND THREADS | 1 |
| 1 | 01069G02 | JAM NUT, M12 X 1.25-05-RH RIGHT HAND THREADS | 1 |
| 2 | 00734G1 | NUT-HEX-LK 7/16-14 | 2 |
