Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 71151G03 | I/P ASSY MODIFIED ! | 1 |
| 1 | 71413G01 | SPLASH PANEL | 1 |
| 5 | 16816G2 | RIVET,RATCHET,.25X.887 | 5 |
| 70662G01 | UPPER FLOORPAN | ||
| 1 | 70451G01 | LOWER FLOORBOARD | 1 |
| 16 | 14601G11 | RIVET-3/16 X 9/16 ALUMINUM | 16 |
| 1 | 70452G01 | COVER-MICRO ACCESS | 1 |
| 1 | 35968G01 | DECAL,T-HOLDER COVER TEE HOLDER COVER | 1 |
| 1 | 70823G01 | OBS-FLOOR PANEL, REAR, MS | 1 |
| 5 | 10570G10 | RIVET-.156 X .55-TYPE D-SS STAINLESS STEEL | 5 |
| 1 | 70995G02 | FLOOR MAT W/ HORN HOLES | 1 |
| 606534G0 | COWL xx | ||
| 74183G01 | NAMEPLATE E-Z-GO OVAL | ||
| 7 | 71055G01 | RIVET-3/16 X .38 GRIP | 7 |
| 6 | 71055G01 | RIVET-3/16 X .38 GRIP | 6 |
| 1 | 71338G01 | FENDER FLARE, FRONT,IM (LH) TPO COWL DRIVER SIDE | 1 |
| 1 | 71338G02 | FENDER FLARE, FRONT,IM (RH) TPO COWL DRIVER SIDE | 1 |
| 1 | 71101G02 | BRACKET COWL SUPPORT | 1 |
| 3 | 71102G02 | SCREW-CAP-1/4-20X.5 | 3 |
| 1 | 71055G01 | RIVET-3/16 X .38 GRIP | 1 |
| 2 | 71115G01 | TRIM - LDPE,12.90'' | 2 |
| 10 | 71055G01 | RIVET-3/16 X .38 GRIP | 10 |
| 2 | 00571G2 | WASHER-FLAT-TYPE A (WIDE-PLATED) DRIVER SIDE | 2 |
| 1 | 605694 | WELDMENT, SEAT FRAME TS-2 | 1 |
| 2 | 00715G2 | SC-TH'D RLG 5/16-18X.80 HWH | 2 |
| 1 | 70244G03 | OBS-SPLASH PAN,PAINTED DRIVER SIDE | 1 |
| 8 | 00715G2 | SC-TH'D RLG 5/16-18X.80 HWH | 8 |
| 71090G | COWL XX | ||
| 608124 | - Notched RH Fender, ST PASSENGER SIDE | ||
| 1 | 608125 | Notched LH Fender, ST DRIVER SIDE | 1 |
| 8 | 16816G2 | RIVET,RATCHET,.25X.887 | 8 |
| 1 | 601781 | LABEL, CONSOLE, PICTOGRAM | 1 |
| 2 | 14601G17 | RIVET | 2 |
| 71912G | REAR BODY ASSEMBLY Without TAILLIGHTSINCLUDES ITEMS 42, 43Indicates consult Customer Service Department for additional information | ||
| 1 | 71318G01 | LINER-BAGWELL-TXT (1 PC)-POA | 1 |
| 20 | 16816G1 | RIVET,RATCHET,.25X.680 | 20 |
| 2 | 71609G01 | PLATE-SEAT HINGE | 2 |
| 4 | 10570G11 | RIVET,3/16,DOMED, BREAK STAINLESS STEEL | 4 |
| 1 | 71316G01 | PLUG HOLE 1.12 FNR | 1 |
| 1 | 71320G01 | ACCESS COVER-BLACK-INJ MOLDED | 1 |
| 5 | 01107G01 | SC PLASTITE PH TORX #8 | 5 |
| 1 | 71364G02 | SPEED NUT, J TYPE, #8 TAPPING | 1 |
| 4 | 10570G12 | RIVET-1/4 X 1/2-TYPE D-ALU ALUMINUM | 4 |
| 6 | 10570G10 | RIVET-.156 X .55-TYPE D-SS STAINLESS STEEL | 6 |
| 2 | 18436G1 | RIVET-DRIVE | 2 |
| 2 | 74111G01 | SUPPORT-SEAT BCK | 2 |
| 1 | 71451G02 | BUMPER,REAR,ECON INCLUDES ITEMS 69 & 70 | 1 |
| 4 | 71398G01 | SCREW-1/4-20 X 1 1/4 | 4 |
| 4 | 00571G2 | WASHER-FLAT-TYPE A (WIDE-PLATED) | 4 |
| 4 | 71455G01 | PLUG--REAR BUMPER | 4 |
| 2 | 71102G03 | BOLT-1/4-20X1.15 | 2 |
| 2 | 71554G01 | J TYPE RETAINER NUT,BARBED | 2 |
| 1 | 74093G01 | DECAL-ENGINE WARNING ! WARNING | 1 |
| 2 | 70364G01 | PLATE-SPACER | 2 |
| 1 | 71642G01 | ROCKER PANEL-LH-FRT-ME/G5/SHTL FRONT, DRIVER SIDE | 1 |
| 1 | 71642G02 | ROCKER PANEL-RH-FRT-ME/G5/SHTL FRONT, PASSENGER SIDE | 1 |
| 1 | 71643G01 | ROCKER PANEL-LH-REAR-ME/G5/SHT REAR, DRIVER SIDE | 1 |
| 1 | 71643G02 | ROCKER PANEL-RH-REAR-ME/G5/SHT REAR, DRIVER SIDE | 1 |
| 1 | 71641G01 | ROCKER PAN/SILL PLT RH PASSENGER SIDE | 1 |
| 1 | 71641G02 | ROCKER PAN/SILL PL LH DRIVER SIDE | 1 |
| 6 | 16705G1 | SCREW-SS-1/4 - 20 X 1 DRIVER SIDE | 6 |
| 6 | 23726G4 | SPACER FOR ROCKER PANEL | 6 |
| 6 | 14390G4 | NUT-LOCK-1/4-20 | 6 |
| 4 | 15058G6 | RIVET ALUMINUM PLAIN ALUMINUM | 4 |
| 2 | 620312 | DECAL, LOGO BASE_E-Z-GO_LARGE | 2 |
| 1 | 70135G01 | COVER-PEDAL PIVOT | 1 |
| 2 | 608431 | DECAL, ST EXPRESS ST EXPRESS | 2 |
| 1 | 75126G01 | SCUFF GUARD-FENDER-LH-TXT DRIVER SIDE | 1 |
| 1 | 75126G02 | SCUFF GUARD-FENDER-RH-TXT PASSENGER SIDE | 1 |
| 2 | 75048G04 | SPACER 1-INCH LONG (HOTWARE) | 2 |
| 2 | 00570G2 | WASHER-FLAT-TYPE A-5/16 | 2 |
| 4 | 00905G8 | OBS-WASHER-LOCK-SP-5/16-BLK | 4 |
| 2 | 75048G01 | SPACER-1/2-TOP/PWR TRAIN | 2 |
| 4 | 01035G02 | SC-M-HEX WASH HEAD 5/16-18 X 2.50 | 4 |
| 604659 | BRUSHGRD BLACK,3 BAR,FRT | ||
| 1 | 70361G03 | FOOTREST ASSY-CLAYS CAR INCLUDES 89 - 95 | 1 |
| 2 | 19853G1 | CAP-TUBE-1 | 2 |
| 1 | 71929G01 | DECAL CLAYS BED WARNING | 1 |
| 1 | 70362G01 | MAT-RUBBER-FOOTREST-4 CAD/SHTL | 1 |
| 1 | 70633G01 | FOOTREST WELDMENT | 1 |
| 1 | 610631 | DECAL, CLAYS BED WARNINGCLAYS CAR | 1 |
| 2 | 19859G1 | CAP-TUBE-3/4 | 2 |
| 2 | 00769G2 | BOLT-CARRIAGE-3/8-16 X 1 1/4 | 2 |
| 6 | 11098G5 | NUT-LOCK-LIGHT-3/8-16 | 6 |
| 14 | 00560G1 | WASHER-3/8-FL-B-CP | 14 |
| 2 | 00427G4 | SCREW-3/8-16X1-1/2-C-HEX-CP | 2 |
| 1 | 74126G01 | REAR FRAME SUPPORT WLDMT LH PASSENGER SIDE | 1 |
| 1 | 74126G02 | REAR FRAME SUPPORT WLDMT RH DRIVER SIDE | 1 |
| 2 | 00426G8 | SCREW-3/8-16X1-CAP-HEX-CP | 2 |
| 1 | 75109G02 | ASHTRAY KIT-MED/TXT (1 PER) INCLUDES ITEMS 107 - 110 | 1 |
| 1 | 27731G01 | ASHTRAY-PLASTIC-FLUSH MTG | 1 |
| 1 | 27736G01 | GASKET-ASHTRAY (FOR 75109G02) | 1 |
| 1 | 75108G02 | ASH TRAY BRACKET | 1 |
| 4 | 00100G4 | SCREW-10-16X.5 (FOR KITS) | 4 |
| 75109G01 | ASHTRAY KIT INCLUDES ITEMS 107-108, 110,112 | ||
| 1 | 75108G02 | ASH TRAY BRACKET E-COAT | 1 |
| 22744G1 | BAGWELL NOISE SUPPRESSOR | ||
| 1 | 606248 | FOAM, SEAT WRAP | 1 |
| 72549G01 | SEATWRAP NOISE SUPPRESSOR | ||
| 72548G01 | FENDER NOISE SUPPRESSOR | ||
| 72551G01 | UTD-SOUND CTRL-FOAM-FNDR LINR-SIDE DRIVER SIDE, FRONT | ||
| 72552G01 | SEATWRAP NOISE SUPPRESSOR DRIVER SIDE, SIDE |
