Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 11221-LBA7-900 | TUBE MISSION BREATHER | 1 |
| 1 | 12431-LBA7-E00 | GEAR TACHOMETER | 1 |
| 1 | 21201-LBA7-600 | CASE MISSION | 1 |
| 1 | 21395-LBA7-900 | GASKET MISSION CASE | 1 |
| 1 | 23211-LBA7-900 | SHAFT MAIN | 1 |
| 1 | 23411-LBA7-900 | SHAFT DRIVE | 1 |
| 1 | 23420-LBA7-900 | GEAR COMP COUNTER | 1 |
| 1 | 23431-LBA7-600 | SHAFT FINAL | 1 |
| 1 | 23441-LBA7-900 | GEAR FORWARD | 1 |
| 1 | 23451-LBA7-900 | GEAR BACKWARD | 1 |
| 1 | 23472-LBA7-900 | COLLAR 20*25*11 | 1 |
| 1 | 23473-LBA7-900 | COLLAR 20*22*11 | 1 |
| 1 | 23481-LBA7-900 | SHIFT MAIN | 1 |
| 1 | 23801-LBA7-900 | SPROCKET DRIVE 14T | 1 |
| 1 | 23803-LBA7-900 | STAY CHAIN | 1 |
| 1 | 23811-LBA7-900 | PLATE A2 FIXING | 1 |
| 1 | 24221-LBA7-900 | FORK GEAR SHIFT | 1 |
| 1 | 24241-KGB4-C00 | SHAFT GEAR SHIFT FORK GUIDE | 1 |
| 2 | 24305-LBA7-900 | SPRING DRUM | 2 |
| 1 | 2431A-LBA7-900 | DRUM ASSY GEAR SHIFT | 1 |
| 1 | 24610-LLB1-900 | SPINDLE ASSY DRUM SHIFT | 1 |
| 1 | 24701-LBA7-900 | GEAR CHANGE HANDLE | 1 |
| 1 | 24702-LBA7-900 | BAR CHANGE HANDLE | 1 |
| 1 | 24703-LLB1-900 | PIN CHANGE HANDLE | 1 |
| 1 | 24704-LBA7-900 | SPRING CHANGE HANDLE | 1 |
| 1 | 24707-LBA7-900 | BRKT CHANGE HANDLE | 1 |
| 1 | 24710-LBA7-900 | STAY CHANGE HANDLE ASSY | 1 |
| 1 | 24711-LBA7-900 | SHAFT COMP CHANGE HANDLE | 1 |
| 1 | 24720-LBA7-900 | ROD ASSY CHANGE HANDLE | 1 |
| 1 | 24781-LBA7-900 | COVER CHANGE HANDLE | 1 |
| 1 | 40510-LBA7-900 | CHAIN COVER | 1 |
| 1 | 40530-LCA5-E00 | CHAIN DRIVE | 1 |
| 1 | 53702-LAC5-900 | BALL JOINT R | 1 |
| 1 | 53703-LAC5-900 | BALL JOINT L | 1 |
| 1 | 90101-LBA7-900 | BOLT SOCKET 5*20 | 1 |
| 2 | 90106-LBA7-900 | BOLT FLANGE 8*25 | 2 |
| 2 | 90451-0A01-001 | WASHER THRUST 14MM | 2 |
| 1 | 90451-LBA7-900 | WASHER THRUST 20MM | 1 |
| 1 | 90452-LBA7-900 | WASHER THRUST 25MM | 1 |
| 2 | 90454-1G07-001 | WASHER THRUST 20MM | 2 |
| 1 | 90455-LBA7-900 | WASHER SPLINE 25MM | 1 |
| 1 | 90458-LBA7-E00 | THRUST WASHER 8MM | 1 |
| 1 | 90474-3C33-001 | WASHER 8MM | 1 |
| 1 | 9052A-GFY6-950 | BOLT DRAIN PLUG SPECIAL | 1 |
| 1 | 90605-KED9-900 | SET RING 28MM | 1 |
| 1 | 91101-LCA5-E0B | BRG NEEDLE 30*42*23 | 1 |
| 1 | 91107-LBA7-900 | BRG NEEDLE 25*33*16 (NK25/16R) | 1 |
| 1 | 91107-LBA7-90A | BRG NEEDLE 25*33*16 | 1 |
| 1 | 91201-9A51-004 | OIL SEAL 12*18*3 | 1 |
| 91206-2F86-014 | OIL SEAL 14*28*7 | ||
| 1 | 91256-LLB1-900 | OIL SEAL 24.8*52.2*7 | 1 |
| 1 | 91509-LBA7-E00 | BOLT TACHOMETER | 1 |
| 2 | 92000-06010-0H | BOLT HEX 6*10 | 2 |
| 2 | 92101-06020-0H | BOLT HEX 6*20 | 2 |
| 2 | 93903-35360 | SCREW TAPPING 5*16 | 2 |
| 1 | 94001-08080-0S | NUT HEX 8MM | 1 |
| 1 | 94001-LAC5-900 | NUT HEX 8MM L | 1 |
| 1 | 94002-06080-0S | NUT HEX 6MM | 1 |
| 4 | 94050-08080 | NUT FLANGE 8MM | 4 |
| 2 | 94102-08000 | WASHER PLAIN 8*16*1.2 | 2 |
| 2 | 94111-08800 | WASHER SPG 8MM | 2 |
| 1 | 94201-20150 | YIN SPLIT 2*15 | 1 |
| 2 | 94301-10160 | DOWEL PIN 10*16 | 2 |
| 2 | 94510-25000 | CIR CLIP EX 25 | 2 |
| 1 | 94520-52000 | CIR CLIP IN 52 | 1 |
| 4 | 94540-12028 | E RING 12 | 4 |
| 1 | 95002-02150 | CLIP B14.5 TUBE | 1 |
| 1 | 95701-08012-08 | BOLT FLANGE 8*12 | 1 |
| 2 | 95701-08028-06 | BOLT FLANGE 8*28 | 2 |
| 7 | 95701-08035-08 | BOLT FLANGE 8*35 | 7 |
| 2 | 95701-08040-08 | BOLT FLANGE 8*40 | 2 |
| 1 | 96001-06016-08 | BOLT FLANGE SH 6*14 | 1 |
| 3 | 96001-06020-08 | BOLT FLANGE SH 6*20 | 3 |
| 1 | 96100-62040-00 | BEARING BALL RADIAL 6204 | 1 |
| 1 | 96100-62050-00 | BEARING BALL RADIAL 6205 | 1 |
| 1 | 96100-63040-00 | BRG BALL RADIAL 6304 | 1 |
