Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| J55-K8116-00-00 | Cowl, Front Upper | ||
| J38-7811A-01-00 | Trim, Upper Cowl | ||
| 4 | 90267-48051-00 | Rivet, Blind (4.8X18.7 Black) | 4 |
| 90201-046J3-00 | Washer, Plate | ||
| J55-K811E-00-00 | Stay, Upper Cowl (L.H.) (J38-78 | ||
| J55-K811F-00-00 | Stay, Upper Cowl (R.H.) (J38-78 | ||
| 90151-06039-00 | Screw, Countersunk | ||
| 4 | 92990-06200-00 | Washer, Plain | 4 |
| 4 | 95380-06800-00 | Nut | 4 |
| J38-7811G-00-00 | Bolt, Cowl Fitting | ||
| J38-7811H-00-00 | Retainer, Cowl Fitting | ||
| 4 | 90201-065F3-00 | Washer, Plate | 4 |
| 4 | 95601-06100-00 | Nut, U | 4 |
| 4 | 90201-062G3-00 | Washer, Plate | 4 |
| J55-K835A-00-00 | Holder, Ball | ||
| 2 | 90267-63047-00 | Rivet, Blind | 2 |
| J55-K8115-01-00 | Cowl, Front (J38-78115-02-00) | ||
| J55-K8231-00-00 | Mat, Main Floor 1 (J38-78231-01 | ||
| J55-K8232-00-00 | Mat, Main Floor 2 (J38-78232-01 | ||
| J55-K8236-00-00 | Mat, Pedal Floor (J38-78236-01- | ||
| 18 | 90267-63047-00 | Rivet, Blind | 18 |
| 1 | J38-24161-00-00 | Emblem 1 | 1 |
| 2 | 90152-04015-00 | Screw, Countersunk | 2 |
| 2 | 92906-04200-00 | Washer, Plain | 2 |
| 2 | 95606-04100-00 | Nut, U | 2 |
| J38-7811L-00-00 | Trim, Cowl Side (L.H.) | ||
| J38-7811M-00-00 | Trim, Cowl Side (R.H.) | ||
| 4 | J38-7811K-00-00 | Nut, Trim Fitting | 4 |
| J38-7812E-01-00 | Support, Upper Cowl (L.H.) | ||
| J38-7812F-01-00 | Support, Upper Cowl (R.H.) | ||
| 2 | 97022-08016-00 | Bolt | 2 |
| 2 | 92990-08600-00 | .Washer, Plate | 2 |
| 4 | 95701-08500-00 | Nut, Flange (95702-08500-00) | 4 |
| J55-K835E-00-00 | Holder, Beverage (J38-7835E-03- | ||
| J55-K835G-00-00 | Housing, Holder (J38-7835G-01-0 | ||
| 2 | 90151-06040-00 | Screw, Countersunk | 2 |
| J38-78145-00-00 | Nut, Rear Body Mounting | ||
| 2 | 90202-06008-00 | Washer, Plate | 2 |
| J38-7834A-00-00 | Reinf., Holder | ||
| 2 | 90267-48086-00 | Rivet, Blind (4.8X19 Black) | 2 |
| 2 | 97780-50120-00 | Screw, Tapping | 2 |
| 2 | 90201-05556-00 | Washer, Plate | 2 |
| 90480-07241-00 | Grommet | ||
| 1 | J55-77768-10-00 | Label, Warning (J38-77768-10-00 | 1 |
| J38-78273-00-00 | Cover, Hole | ||
| 2 | 90269-11042-00 | Rivet | 2 |
| 4 | 92580-06020-00 | Screw, Pan Head | 4 |
| 4 | 92995-06100-00 | Washer, Spring | 4 |
| 4 | 90201-06697-00 | Washer, Plate | 4 |
| 1 | 98580-06016-00 | Screw, Pan Head | 1 |
| 1 | 92995-06100-00 | Washer, Spring | 1 |
| 1 | 90201-06049-00 | Washer, Plate | 1 |
| J55-K8141-00-00 | Panel, Intermediate Body | ||
| J22-77765-00-00 | Label, Warning 5 | ||
| J38-7814N-00-00 | Plate, Ornament | ||
| 7 | 90201-04325-00 | Washer, Plate | 7 |
| 7 | 90267-40054-00 | Rivet, Blind | 7 |
| J41-77458-10-00 | Label, Warning (J41-77458-00-00 | ||
| J56-K8121-00-00 | Reinforcement 1 (J41-78121-01-0 | ||
| 4 | 98980-06016-00 | Screw, Bind | 4 |
| 2 | 90338-06169-00 | Plug | 2 |
| 2 | 90183-06011-00 | Nut, Spring | 2 |
| J55-K8143-00-00 | Hinge, Intermediate Body 1 | ||
| J55-K8144-00-00 | Hinge, Intermediate Body 2 | ||
| 91790-06125-00 | Pin, Clevis | ||
| 2 | 91490-20015-00 | Pin. Cotter | 2 |
| 4 | 97003-06012-00 | Bolt (97001-06012-00) | 4 |
| 4 | 92990-06600-00 | Washer, Plate | 4 |
| 4 | 97023-06020-00 | Bolt (3Xf) | 4 |
| 90891-60024-00 | Panel, Rear Body (J38-78142-01) | ||
| 3 | 92580-06020-00 | Screw, Pan Head | 3 |
| 3 | 92995-06100-00 | Washer, Spring | 3 |
| 90201-06M08-00 | Washer, Plate | ||
| 2 | 98980-06016-00 | Screw, Bind | 2 |
| 2 | 90201-065F3-00 | Washer, Plate | 2 |
| 90183-06028-00 | Nut, Spring | ||
| J55-K8272-00-00 | Cover, Fuel Inlet | ||
| 1 | J51-77764-00-00 | Label, Warning 4 | 1 |
| 98511-04012-00 | Screw, Pan Head | ||
| 2 | 92901-04600-00 | Washer | 2 |
| J38-78276-00-00 | Nut, Inlet Fitting | ||
| J55-K8241-00-00 | Mat, Rear Floor (J38-78241-00-0 | ||
| 6 | 90267-63047-00 | Rivet, Blind | 6 |
| J55-K8243-00-00 | Mat, Rear Body Side (Lh) | ||
| J55-K8244-00-00 | Mat, Rear Body Side (Rh) | ||
| 12 | 90267-63047-00 | Rivet, Blind | 12 |
| J41-78274-01-00 | Cover, Hole 2 | ||
| J38-77741-10-00 | Indicator 1 J41-000201~016100 |
