Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 4052A-PWA5-900 | GUARD ASSY REAR FORK | 1 |
| 1 | 4054A-LBD4-900 | DRIVE CHAIN ADJUSTER ASSY | 1 |
| 1 | 43156-LLB1-800 | CLAMPER BRAKE HOSE | 1 |
| 1 | 47401-LBD4-900 | SHAFT R STEERING | 1 |
| 1 | 47501-LBD4-900 | SHAFT L STEERING | 1 |
| 2 | 51400-LBD4-900-R8S | (R8S) RED, GLOSS PAINTED STEEL for RR338SA, CUSH ASSY FR | 2 |
| 2 | 51400-LBD4-900-R8S | (R8S) RED, GLOSS PAINTED STEEL for YR110SA, CUSH ASSY FR | 2 |
| 2 | 51400-LBD4-900-R8S | (R8S) RED, GLOSS PAINTED STEEL for NH195SA, CUSH ASSY FR | 2 |
| 2 | 51400-LBD4-900-R8S | (R8S) RED, GLOSS PAINTED STEEL for GG146SA, CUSH ASSY FR | 2 |
| 2 | 51400-LBD4-900-R8S | (R8S) RED, GLOSS PAINTED STEEL for PB089SA, CUSH ASSY FR | 2 |
| 1 | 52000-PVA2-900 | FORK COMP RR | 1 |
| 1 | 52101-LBD4-900 | COLLAR RR FORK DIST | 1 |
| 2 | 52108-LBD4-900 | BUSH REAR FORK | 2 |
| 1 | 52108-KFW6-901 | COLLAR CHAIN SLIDER | 1 |
| 2 | 52144-LBA7-900 | CAP RR FORK DUST SEAL | 2 |
| 1 | 52171-PVA2-900 | SLIDER CHAIN | 1 |
| 2 | 52400-LBD4-900-R8S | (R8S) RED, GLOSS PAINTED STEEL for RR338SA, CUSH ASSY RR | 2 |
| 2 | 52400-LBD4-900-R8S | (R8S) RED, GLOSS PAINTED STEEL for YR110SA, CUSH ASSY RR | 2 |
| 2 | 52400-LBD4-900-R8S | (R8S) RED, GLOSS PAINTED STEEL for NH195SA, CUSH ASSY RR | 2 |
| 2 | 52400-LBD4-900-R8S | (R8S) RED, GLOSS PAINTED STEEL for GG146SA, CUSH ASSY RR | 2 |
| 2 | 52400-LBD4-900-R8S | (R8S) RED, GLOSS PAINTED STEEL for PB089SA, CUSH ASSY RR | 2 |
| 1 | 53400-PVA2-900 | ARM ASSY R SWING | 1 |
| 4 | 53402-LBD4-900 | BUSH SWING ARM | 4 |
| 2 | 53403-LBD4-900 | BUSH SWING ARM BOTTOM | 2 |
| 2 | 53404-LBD4-900 | BUSH SWING ARM UP | 2 |
| 2 | 53406-LBD4-900 | CAP SWING ARM | 2 |
| 2 | 53407-LBD4-900 | SEAL SWING ARM | 2 |
| 1 | 53500-PVA2-900 | ARM ASSY L SWING | 1 |
| 1 | 90121-LBA7-900 | BOLT RR FORK PIVOT | 1 |
| 8 | 90304-GLW0-90A | NUT U FLANGE 10MM | 8 |
| 1 | 90305-MAA1-004-SY | NUT U FLANGE 14MM | 1 |
| 2 | 92101-10040-0H | BOLT HEX 10*40 | 2 |
| 4 | 93404-06016-06 | BOLT WASH 6*16 | 4 |
| 1 | 93901-26110 | SCREW TAPPING 6*12 | 1 |
| 1 | 94001-08080-0S | NUT HEX 8MM | 1 |
| 2 | 94011-12080-0S | NUT CASTLE 12MM | 2 |
| 2 | 94011-LBD4-900 | NUT FLANGE CASTLE 10MM | 2 |
| 1 | 94101-08800 | WASHER PLAIN 8MM | 1 |
| 1 | 94111-08800 | WASHER SPRING 8MM | 1 |
| 4 | 94050-10080 | NUT FLANGE 10MM | 4 |
| 2 | 94201-20200 | PIN SPLIT 2*20 | 2 |
| 2 | 94201-30250 | PIN SPLIT 3.0*25 | 2 |
| 1 | 95701-06010-00 | BOLT FLANGE 6*10 | 1 |
| 4 | 95801-10040-08 | BOLT FLANGE 10*40 | 4 |
| 4 | 95801-10050-06 | BOLT FLANGE 10*50 | 4 |
| 3 | 96201-10000 | NIPPLE GREASE | 3 |
| 3 | 96202-LBD4-900 | BOOT CREASE NIPPLE | 3 |
