Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 800001688 | PROTECTOR, INNER TUBE TE model/TXC model | ||
| 800010777 | Rim Strip TC model | ||
| 8B0082879 | BAND, RIM SMR model | ||
| 800054073 | TIRE BLEND CLAMP | ||
| 80C092612 | Rim (4,25 X 17") SMR model | ||
| 8000H2078 | REAR WHEEL RIM TE model/TC model/TXC model | ||
| 8000H2076 | Rim (2,15 X 19") TC model | ||
| 800094757 | REAR WHEEL SPOKE, DISC SIDE SMR model | ||
| 800095341 | REAR WHEEL SPOKE, SPROCKET SID SMR model | ||
| 8000A0085 | SPOKE, REAR WHEEL 194.5 MM TE model/TXC model | ||
| 8000A6206 | SPOKE, REAR WHEEL 194.5 MM TE model/TXC model | ||
| 8A00A0085 | SPOKE, REAR WHEEL 206 MM TC model | ||
| 8A00A6206 | SPOKE, REAR WHEEL 208 MM In alternative/TC model | ||
| 8B00A6206 | SPOKE REAR WHEEL SPROKET SIDE In alternative/TE model/TXC model | ||
| 8C00A6206 | SPOKE REAR WHEEL SPROKET SIDE In alternative/TC model | ||
| 69N429005 | NIPPLE, SPOKE SMR model | ||
| 8000A0086 | Nipple Did TE model/TC model/TXC model | ||
| 8000A6209 | NIPPLE, SPOKE In alternative/TE model/TC model/TXC model | ||
| 8A0096937 | HUB, REAR WHEEL TE model/TC model/TXC model | ||
| 8A0097593 | HUB, REAR WHEEL SMR model | ||
| 800092414 | SPACER, HUB BEARING TE model/TC model/TXC model | ||
| 8A0086938 | Spacer SMR model | ||
| 8B0026846 | BEARING, RADIAL BALL 25X47X16 | ||
| 8D0026846 | BALL BEARING 25X47X16 SMR model/In alternative | ||
| 800092797 | SPACER | ||
| 800096938 | SPACER, OUTER | ||
| 8000H1718 | REAR BRAKE DISC SMR model | ||
| 8000H0195 | DISC, REAR BRAKE TE model/TC model/TXC model | ||
| 800062726 | SCREW TEF M6X1.00X14 CH8 | ||
| 8000A4859 | REAR SPROCKET 42T SMR model | ||
| 8A0096837 | REAR SPROCKET 47T Supplied | ||
| 8D0096837 | REAR SPROCKET 50T Supplied | ||
| 8A00A4859 | REAR SPROCKET 43T Upon request/SMR model | ||
| 8B00A4859 | REAR SPROCKET 44T Upon request/SMR model | ||
| 8G00A4859 | REAR SPROCKET 45T Upon request/SMR model | ||
| 8A0096837 | REAR SPROCKET 47T Upon request | ||
| 8B0096837 | REAR SPROCKET 48T Upon request/TE model/TC model/TXC model | ||
| 8C0096837 | REAR SPROCKET 49T Upon request/TE model/TC model/TXC model | ||
| 8D0096837 | REAR SPROCKET 50T Upon request | ||
| 8000H0158 | SCREW - L28 | ||
| 800043928 | SELF LOCKING NUT M8X1.25 | ||
| 800096940 | AXLE, REAR WHEEL In alternative/TE model | ||
| 8000H1548 | SHAFT TE model | ||
| 800096940 | AXLE, REAR WHEEL TC model/TXC model/SMR model | ||
| 8000H1548 | SHAFT TE model/TC model/TXC model/SMR model | ||
| 8A0026846 | BEARING, RADIAL BALL 6005-2NGK | ||
| 8C0026846 | BEARING BALL RADIAL 6005-2NGK SMR model/In alternative | ||
| 800093072 | NUT M20X1.5 CH27 | ||
| 66N021272 | CIRCLIP 50.5 MM | ||
| 800089572 | STOP RING 32X47X7 MM | ||
| 8B00A6261 | CHAIN REGINA 5/8X1/4-114 | ||
| 8B0079783 | CHAIN DID 5/8X6.5-114 In alternative | ||
| 8000A6261 | CHAIN 135ORC6 REGINA | ||
| 8E0079783 | CHAIN DID 5/8X6.5-112 | ||
| 800056768 | CHAIN REGINA 135RX-114 | ||
| 8B0079785 | CHAIN DID 520DS 5/8X6.5-114 In alternative | ||
| 8C00A6261 | CHAIN 5/8X1/4-106 | ||
| 8L0079783 | Chain 5/8"X1/4" (106 Maglie) Did (Smr) In alternative | ||
| 8000A6262 | CHAIN LINK REGINA TE model/TXC model/SMR model | ||
| 8000A9234 | Coupling Did (Mxv) (Te 310) | ||
| 800079789 | CHAIN LINK DID 520V6 | ||
| 800056767 | CHAIN LINK REGINA 135RX TC model | ||
| 800079790 | Coupling Did (520 Ds) TC model | ||
| 8000A0693 | BUSH |
