Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 8 | 103867 | CUSH WSHR,.31.69.06 YS FLT | 8 |
| 7 | 120052 | CUSH LOCKWASHER .194.337.047 | 7 |
| 2 | 300646 | CUSH SCRW.25-20.75 YS HX G5KEGKC | 2 |
| 1 | 838769 | CUSH TERMINAL.SOCKET | 1 |
| 14 | 302288 | CUSH SCREW, HEX HEAD 1/4-20 X 1 | 14 |
| 306320 | CUSH NUT, 5/16-24 YS HX | ||
| 8 | 306325 | CUSH LWSHR .319 .591 .078 YS | 8 |
| 8 | 306375 | CUSH NUT, HEX 1/4-20 | 8 |
| 7 | 306396 | CUSH LOCKWASHER, .255 .493 .062 YS | 7 |
| 1 | 306419 | CUSH SCRW, .25-20.50 HX YS G5 | 1 |
| 4 | 306450 | CUSH SCRW, 5/16 - 18 X 3/4 YS HX G5 | 4 |
| 2 | 306514 | CUSH SCRW,#10-24.50 YS RS (KC) | 2 |
| 7 | 306531 | CUSH NUT, 10-24 YS HEX | 7 |
| 4 | 306932 | CUSH NUT, 5/16 - 18 YS HX | 4 |
| 8 | 308090 | WSHR, FLAT .25 .62 .05 YS | 8 |
| 548910 | NLA CUSH NUT | ||
| 1 | 800017 | CUSH SCRW,.25-20 1.0 YS PR G2 | 1 |
| 2 | 800271 | CUSH SCRW,#10-24.50 YS PR G2 | 2 |
| 3 | 800299 | CUSH SCRW,#10-24 1.0 YS PR G2 | 3 |
| 2 | 800587 | CUSH NUT,#4-40 YS HX w/XT LWSHR (KC | 2 |
| 3 | 814924 | CUSH CLAMP, TUBE 1.438 ID YS | 3 |
| 817719 | BUSHING | ||
| 1 | 825880 | CUSH CONNECTOR,1 CONTACT MALE | 1 |
| 825884 | CLAMP | ||
| 1 | 826005 | CUSH CONNECTOR | 1 |
| 1 | 826006 | CUSH CONNECTOR, 2-CONTACT FEMALE | 1 |
| 1 | 826726 | CUSH CONNECTOR,1 CONTACT FEMALE | 1 |
| 1 | 829164 | CIRCUIT BREAKER, 90 AMP | 1 |
| 1 | 829780 | CIRCUIT BREAKER, 20 AMP | 1 |
| 1 | 830640 | CUSH SWITCH, ROCKER | 1 |
| 1 | 836354 | OBS-REVERSE SWITCH | 1 |
| 839917 | PLUG | ||
| 1 | 839918 | CUSH RECEPTACLE,2-WIRE | 1 |
| 839921 | LOCK | ||
| 1 | 839935 | CUSH LOCK, 2-WIRE RECPT | 1 |
| 1 | 839849 | CUSH PLUG,3-WIRE | 1 |
| 1 | 839850 | CUSH RECEPTACLE,3-WIRE | 1 |
| 840117 | LOCK | ||
| 1 | 840118 | CUSH LOCK,3-WIRE PLUG | 1 |
| 2 | 840273 | CUSH BUS BAR | 2 |
| 4 | 840491 | CUSH BUSHING | 4 |
| 1 | 840496 | SVC-PANEL,DASH,SAFETY YELLOW | 1 |
| 1 | 840526 | CUSH GAUGE, 24V BATTERY CONDTIO | 1 |
| 1 | 840679 | CUSH RECTIFIER, BRIDGE | 1 |
| 2 | 841208 | CUSH MN CONTACT, 24V SOLENOID 835/MM | 2 |
| 841248 | CUS SOLENOID,24V | ||
| 1 | 886425 | CUSH HORN ASSEMBLY | 1 |
| 1 | 829694 | BRACKET, HORN MOUNTING | 1 |
| 880631 | HOUR METER | ||
| 1 | 886311 | CUSH SWITCH AY,IGNITION (SEE TEXT) | 1 |
| 888503 | CUSH SERVICE KIT | ||
| 1 | 890000 | CUSH BUZZER AY. | 1 |
| 524358 | NLA CUSH TERMINAL | ||
| 1 | 892676 | CUSH LIGHT, RED | 1 |
| 1 | 4110440 | CUSH CONTROLLER, SPD 250 AMP | 1 |
| 892942 | HEADLIGHT SET | ||
| 840854 | CUSH, BRACKET, LIGHT | ||
| 1 | 892523 | OBS-RAN HEADLIGHT ASSY | 1 |
| 840860 | CUSH, HEADLIGHT BULB | ||
| 1 | 893142 | CUSH RESISTOR, 250 OHM | 1 |
| 840676 | TERMINAL | ||
| 1 | 825886 | CUSH TERMINAL,1/4 LMALE 14-16AWG | 1 |
| 1 | 825748 | CUSH TERMINAL,1/4 FEMALE 14-16AWG | 1 |
| 7035 | GREASE |
