Список запчастей
| № | Артикул | Название | Кол-во |
|---|---|---|---|
| 1 | 1337232 | ASM-GEARCASE,REAR,DIFF [INCLUDES ALL] | 1 |
| 1 | 3234756 | SOCKET HEAD W/ MAG PLUG 18 MM X | 1 |
| 2 | 3234309 | SCREW, TORX PAN HD M6 X 1 X 16 | 2 |
| 13 | 3234898 | HEX HEAD FLANGE SCREW 8MMX1.25M | 13 |
| 6 | 3235206 | SCREW | 6 |
| 2 | 3235207 | SCREW | 2 |
| 1 | 3235208 | SCREW, 6 MM X 1.0 MM 40 MM | 1 |
| 6 | 3235332 | SOCKET HEAD SCREW, 6 MM X 1 MM | 6 |
| 8 | 3236169 | SCREW CAP, 8 MM X 1.25 MM X 20 | 8 |
| 1 | 3235210 | HEXFLANGE NUT, NYLON, 8 MM X 1. | 1 |
| 1 | 3235211 | WASHER | 1 |
| 1 | 3235212 | WASHER | 1 |
| 1 | 3235991 | WASHER 22.7 X 32 X 1.5 | 1 |
| 1 | 3236410 | WASHER 22.5 X 30 X 1.5 | 1 |
| 2 | 3234330 | PIN, DOWEL, 6 X 20 | 2 |
| 1 | 7043746 | SPRING-SLOTTED PIN,6MM | 1 |
| 1 | 3236286 | DOWEL PIN, 3 X 40 | 1 |
| 2 | 3236295 | PIN,DOWEL 8X10 | 2 |
| 2 | 7710434 | SNAP RING | 2 |
| 1 | 3233106 | SNAP RING | 1 |
| 1 | 3233834 | RETAINING RING | 1 |
| 1 | 3233364 | RETAINING RING | 1 |
| 1 | 3234269 | RING,RETAININGBASICINTRNL2.047 | 1 |
| 2 | 3234205 | RETAINING RING | 2 |
| 1 | 3239594 | RING,RETAINING BASIC,EXTERNAL | 1 |
| 1 | 3235214 | RETAINING RING | 1 |
| 1 | 3235216 | RETAINING RING | 1 |
| 1 | 3233378 | THRUST WASHER | 1 |
| 1 | 3234642 | THRUST WASHER, .446 X .88 X .02 | 1 |
| 2 | 3233014 | NEEDLE BEARING | 2 |
| 2 | 3233019 | BEARING | 2 |
| 1 | 3233020 | BEARING | 1 |
| 2 | 3233268 | BALL BEARING | 2 |
| 3 | 3234065 | BALL BEARNING | 3 |
| 1 | 3233384 | NEEDLE BEARING | 1 |
| 1 | 3235218 | BALL BEARING | 1 |
| 2 | 3234652 | BALL BEARING | 2 |
| 3 | 3235807 | BALL BEARING, 17 X 30 X 7 | 3 |
| 1 | 3236118 | BALL BEARING | 1 |
| 1 | 3239595 | BEARING,BALL,6800 10X19X5 | 1 |
| 1 | 3239596 | BEARING,BALL,6802 15X24X5 | 1 |
| 1 | 3239597 | BEARING,PLAIN FLANGED,28X32X13 | 1 |
| 1 | 3234276 | TORSION RETURN SPRING | 1 |
| 1 | 3234277 | SPRING,COMPRSSN.54ODX.44IDX.05 | 1 |
| 1 | 3235327 | SPRING WASHER | 1 |
| 2 | 3239598 | SPRING WAVE,53IDX61OD | 2 |
| 1 | 3239599 | SPRING TORSION | 1 |
| 1 | 3239600 | SPRING COMPRESSION,DETENT | 1 |
| 1 | 3236120 | SNORKLE TUBE, MACHINED | 1 |
| 1 | 3239601 | COVER-SECTOR GEARS,MACH | 1 |
| 1 | 3236287 | DIFFERENTIAL CARRIER, MACHINED | 1 |
| 1 | 3233839 | SECTOR GEAR, 16 TOOTH | 1 |
| 1 | 3233832 | SECTOR GEAR, 31 TOOTH CUT TO 11 | 1 |
| 1 | 3235455 | FORK SHIFT | 1 |
| 1 | 3239602 | DETENT STAR | 1 |
| 1 | 3239815 | PLATE,PARK 6-FACE | 1 |
| 1 | 3235223 | IDLER SHAFT, 29 TOOTH | 1 |
| 1 | 3236290 | GEAR,OUTPUT 14T MACH | 1 |
| 1 | 3236291 | GEAR,53T OUTPUT | 1 |
| 1 | 3236411 | OUTPUT SHAFT, FRONT | 1 |
| 1 | 3236289 | GEAR,OUTPUT 14T DISCONNECT MAC | 1 |
| 1 | 3239675 | SLEEVE,PARK | 1 |
| 1 | 3239676 | SLEEVE,HIGH | 1 |
| 1 | 3239606 | SHAFT,REVERSE,25T | 1 |
| 1 | 3239607 | BELLCRANK,ZEUS,RC SHIFTING | 1 |
| 1 | 3234230 | TUBE-VENT,90-1/4 HOSE | 1 |
| 1 | 3235236 | STAGE 3 GEAR, 46 TOOTH | 1 |
| 1 | 3235450 | GEAR, 48 TOOTH | 1 |
| 1 | 3236132 | GEAR, LOW, 25 TOOTH | 1 |
| 1 | 3235986 | IDLER GEAR, 39T | 1 |
| 1 | 3236292 | DIFFERENTIAL PIN | 1 |
| 1 | 3236412 | SNORKEL GEAR, 13 TOOTH | 1 |
| 1 | 3236293 | DOG, ENGAGEMENT | 1 |
| 1 | 3239608 | SHIFT DOG,PARK | 1 |
| 3 | 3239609 | SHIFT DOG | 3 |
| 1 | 3239610 | GEAR,LOW,67T | 1 |
| 1 | 3239611 | DRUM-SHIFT,MACH | 1 |
| 1 | 3239612 | RAIL-SHIFT SHAFT | 1 |
| 1 | 3239613 | SHAFT-SHIFT | 1 |
| 1 | 3239614 | PARK CAM | 1 |
| 1 | 3239615 | GEAR-REVERSE 56T | 1 |
| 1 | 3239616 | GEAR-HIGH 52T | 1 |
| 1 | 3236342 | MOUNT BRACKET WELD, REAR | 1 |
| 2 | 3236288 | BEVEL PINION, 10T | 2 |
| 1 | 3236285 | DIFFERENTIAL SUBASSEMBLY | 1 |
| 1 | 3236691 | SHAFT,INPUT 43T/22T/25T | 1 |
| 1 | 3239617 | SUBASSEMBLY,LH CASE | 1 |
| 1 | 3239618 | SUBASSEMBLY,RH CASE | 1 |
| 1 | 3239619 | SUBASSEMBLY,ROLLER PAWL | 1 |
| 1 | 3239519 | SHAFT,PINION,11T | 1 |
| 1 | 3239620 | SUBASSEMBLY,SHIFT FORK | 1 |
| 1 | 3239621 | SUBASSEMBLY,SHIFT FORK | 1 |
| 2 | 3234934 | FORK RETAINER | 2 |
| 1 | 3235241 | CENTER DRIVE BEARING COVER | 1 |
| 2 | 3236294 | WASHER,THRUST 40.83X56.25X0.38 | 2 |
| 1 | 3236343 | MOUNT BRACKET, REAR | 1 |
| 1 | 3235478 | SOLENOID | 1 |
| 1 | 7662299 | RESISTIVE 2 PIN ROTARY SWITCH | 1 |
| 1 | 4082135 | SENSOR,SPEED (INCLUDES 101) | 1 |
| 1 | 3234755 | PLUG, M18 X 1.5 | 1 |
| 1 | 3236279 | O-RING -16 (560496) | 1 |
| 1 | 3236141 | VITRON TRIPLE LIP SEAL, 32 X 49 | 1 |
| 1 | 3233836 | O-RING | 1 |
| 1 | 3233828 | O-RING | 1 |
| 2 | 3235052 | VITON TRIPLE LIP SEAL, 40 X 70 | 2 |
| 1 | 3236135 | SEAL, TRIPLE LIP, 25 X 55 X 8 | 1 |
| 1 | 3236136 | O-RING, 2.989 X .070 | 1 |
